Each item will be explained as follows:
Item
Add
Edit
Delete
Refresh
Move Up
Move Down
Profile Number Limit
Group
Enable
Comment
H o w t o c r e a t e a n I P
H o w t o c r e a t e a n I P
To build an IP group containing IP filter rules, please follow the steps:
1. Open Firewall>>Filter Setup and click the IP Filter tab.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Group
Enable
Comment
Description
Add a new group profile for IP filter.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Remove the selected profile.
To delete a rule, simply select the one you want to delete
and click the Delete button.
Renew current web page.
Change the order of selected profile by moving it up.
Change the order of selected profile by moving it down.
Display the total number of the profiles to be created.
Display the name of the IP filter group profile.
Display the status of the profile. False means disabled; True
means enabled.
Display the description for such profile.
F i l t e r g r o u p
F i l t e r g r o u p
Description
Type the name of the IP filter group.
Check the box to enable this profile.
Give a brief description for the profile.
