Delete
Move Up / Move Down
Rename
Auto Refresh
Refresh
Profile
Enable
Priority
Protocol
Time Objects
Service Type Objects
Source
Source Port
Destination
Destination Port
Out-going Rule
Mode
Failover to Next Rule
Failback (Quick
Recover)
rule.
Remove the selected rule profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
Move the selected profile up or down.
Allow to modify the selected profile name.
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
Renew current web page.
Display the name of the rule.
Display the status of the profile. False means disabled; True
means enabled.
Display the priority of such rule.
Display the protocol of such rule.
Display the name of time object.
Display the name of service type.
Display the name of the source subnet/IP object/IP group.
Display the source port range.
Display the name of the destination subnet/IP object/IP
group/DNS object.
Display the destination port range.
Display the route way (where the traffic forwarded) selected.
Display the route mode (NAT or Routing) used by such
policy route.
Display the status (enabled or disabled) of the function.
Display the status (enabled or disabled) of the function.
