Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Source IP
Action Policy
Apply
Cancel
4. Enter all the settings and click Apply.
5. A new Application filter profile has been added.
You can click to create another new time object
profile, or you can click the edit icon
existed object profile.
Time Group - Click the triangle icon
profile selection box. Choose a schedule group profile to be
applied on such rule. You can click
new time group profile, or you can click the edit icon
to modify the existed group profile.
Source IP Object / Source IP Group / Source User
Profile / LDAP Group/ Guest Group - Click the triangle
icon to display the profile selection box. Choose one or
more IP object / IP group / user profile / user group / LDAP
group / Guest group profiles from the drop down list. The
selected object will be filtered by the router when such
application filter profile is applied. You can click
create another new object profile, or click the edit icon
to modify the existed group profile.
APP Block - Click the triangle icon
profile selection box. Choose one or more APP object
profiles from the drop down list which will be allowed / not
be allowed to pass through the router. You can click
create another new APP object profile, or you can click the
edit icon to modify the existed object profile.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
207
to modify the
to display the
to create another
to
to display the
to
