Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Item
Add
Edit
Delete
Refresh
Mode
Profile Number Limit
Profile (max length:7)
Enable
Description
Port
IPv4 Protocol Type
IPv6 Protocol Type
VLAN Tag
VLAN ID
Priority(802.1p)
Description
Add a new WAN profile. Such function is available in
Advance mode only.
Modify the selected WAN profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Remove the selected WAN profile. Such function is
available in Advance mode only.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Renew current web page.
Specify the mode for adding /editing (Advance) new WAN
profile or just editing (Basic) existing WAN profile.
Display the total number (50) of the profiles to be created.
Display the profile name.
Display the status of the profile. False means disabled; True
means enabled.
Display a brief explanation for such profile.
Display the physical WAN interface for such profile.
Display the IPv4 protocol selected by the profile.
Display the IPv6 protocol selected by the profile.
Display if the function is enabled or not.
If the data transmitted with tag, Enable will be displayed in
this field. Otherwise, Disable will be shown instead.
Display the VLAN ID of the profile.
Display the level of the priority for such profile.
81
