Type
LDAP Profile
DHCP From
DHCP Relay
Apply
Cancel
4 . 2 . 2 . 3 H i s t o r y
4 . 2 . 2 . 3 H i s t o r y
This page displays records of connection status (up or down) and the connection time and the
name of the user who accesses into PPPoE server of such router.
Each item will be explained as follows:
Item
User Name
Action
type for the users.
It is available when LDAP is selected as User
Authentication Type.
If you choose LDAP as the authentication type, use the drop
down list to specify the LDAP profile.
It is available when RADIUS is selected as User
Authentication Type.
Enable - If you want to use another DHCP server in the
network other than the Vigor Router's, you can let Relay
Agent help you to redirect the DHCP request to the
specified location.
DHCP Server Location – Choose one of the interfaces for
DHCP server.
DHCP Server IP Address - Set the IP address of the DHCP
server you are going to use so DHCP Relay can help to
forward the DHCP request to the DHCP server.
Click it to save and exit the dialog.
Click it to discard current page modification.
Description
Display the user name used to access into the PPPoE server.
Display the connection status (up or down) of the user
account.
130 Vigor3900 Series User's Guide
