RX (Packets)
TX (Packets)
Disconnect
Operation
4 . 9 . 8 . 2 H i s t o r y
4 . 9 . 8 . 2 H i s t o r y
This page displays the history of VPN connection.
Each item will be explained as follows:
Item
VPN
Type
Remote IP
Action
Time
Display the total received packets through this VPN.
Display the total transmitted packets through this VPN.
Terminate the VPN connection.
Display the icons to terminate / view the VPN profile.
Description
Display the name of VPN profile.
Display the connection type used of such VPN.
Display the IP address of the remote end.
Display the connection status (UP or DOWN) of VPN
profile.
Display the time the VPN profile connects/disconnects.
367
