Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Edit
Delete
Refresh
IPSec
PPTP Dial-out
PPTP Dial-in
Profile Number Limit
Profile
Enable
Dial-Out Through
Local IP / Subnet Mask
Remote Host
Remote IP / Subnet
Mask
More Remote Subnet
H H o o w w t t o o c c r r e e a a t t e e a a n n I I P P S S
The IPSec services can provide access control, connectionless integrity, data origin
authentication, rejection of replayed packets that is a form of partial sequence integrity, and
confidentiality by encryption. These objectives are met through the use of two traffic
security protocols, the Authentication Header (AH) and the Encapsulating Security Payload
(ESP), and through the use of cryptographic key management procedures and protocols.
1. Open VPN and Remote Access >>VPN Profiles.
2. Simply click the Add button.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
profile.
Remove the selected profile.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Renew current web page.
Display the LAN to LAN profile with IPSec policy.
Display the LAN to LAN profile with PPTP Dial-out policy.
Display the LAN to LAN profile with PPTP Dial-in policy.
Display the total number (500) of the object profiles to be
created.
Display the name of LAN to LAN profile.
Display the status of the profile. False means disabled; True
means enabled.
Display the WAN interface selected for the profile.
Display the LAN IP address with subnet mask of this
profile.
Display the name of the remote host of this profile.
Display the WAN IP address with subnet mask of this
profile.
Display other LAN IP addresses with subnet mask which
can be used of this profile.
e e c c V V P P N N p p r r o o f f i i l l e e
