H H o o w w t t o o a a d d d d a a n n e e w w p p o o
1. Open Routing>>Policy Route.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Profile
Enable
Priority
Protocol
Time
Service Protocol
Source
l l i i c c y y r r u u l l e e
Description
Type the name of the rule.
Check this box to enable such profile.
Choose the priority for such profile (top, high and normal).
Choose a protocol (ALL, TCP, UDP, TCP/UDP and ICMP)
for such rule applied to load balance. All is the default
setting.
Choose a time object to be applied by such profile.
It is available when TCP/UDP is selected as protocol. Choose
a profile for such rule.
Source Type - Choose the address type (Any, Subnet or
Object) for such rule.
