4 . 2 . 3 . 3 I n t e r f a c e
4 . 2 . 3 . 3 I n t e r f a c e
This page allows you to modify the status (enable / disable), speed(Auto,10M,100M,1000M)
and duplex (Half/Full) for the LAN ports respectively.
Each item will be explained as follows:
Item
Edit
Refresh
Interface
Enable
Duplex
Speed
Flow Control
802.3az
Description
Choose the interface listed below and click the Edit button
to modify the settings. A pop up window will appear for you
to change the settings.
Renew current web page.
Display the profile name of the interface.
Display the status of the profile. False means disabled; True
means enabled.
Display the duplex used (full or half) by such profile.
Display the transmission rate (10M, 100M, 1000M or Auto)
of the date for such profile.
Display the status (enable or disable) of such function.
Display such function is enabled or disabled.
135
