Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Block If No Further Match - A packet matching the rule,
and that does not match further rules, will be dropped.
Accept If No Further Match - A packet matching the rule,
and that does not match further rules, will be passed through.
Next Group When you choose Block If No Further Match or Accept If
No Further Match as Block Action, you have to specify
next IP filter group for further matching.
Syslog Click Enable to make the history of firewall actions
appearing on the System Maintenance >> Syslog/Mail
Alert >> Syslog File.
Input Interface Choose one of the LAN or WAN profiles as data receiving
interface.
Output Interface Choose one of the LAN or WAN profiles as data
transmitting interface.
Time Object - Click the triangle icon
Time Schedule
profile selection box. Choose a schedule object profile to be
applied on such rule. You can click
new time object profile.
Time Group - Click the triangle icon
profile selection box. Choose a schedule group profile to be
applied on such rule. You can click
new time group profile.
Service Protocol Service Type Object –Click the triangle icon
the profile selection box. Choose one or more service type
object profiles from the drop down list. The selected profile
will be treated as service type. You can click
another new service type object profile.
Service Type Group –Click the triangle icon
the profile selection box. Choose one or more service type
group profiles from the drop down list. The selected profile
will be treated as service type. You can click
another new service type group profile.
Source IP Source IPv6 Object - Click the triangle icon
the profile selection box. Choose one or more IP object
profiles from the drop down list. The selected profile will be
treated as source target. You can click
203
to display the
to create another
to display the
to create another
to display
to create
to display
to create
to display
to create another
