Replication

The ETERNUS CS800 provides data replication capabilities that you can use as an integral
part of a disaster recovery plan. Replication allows you to configure the ETERNUS CS800
to create a copy of your data on another system at scheduled intervals (or manually as
needed).
In the event of a disaster in which the original data is lost, you can quickly recover the repli-
cated data on the remote system, allowing your business to resume normal operations.
Once the original system is available again, you can restore all data back to its original
location.
I
See the following sections for more information about the data replication capabilities of the
ETERNUS CS800:

"Understanding Data Replication"

●
"Performing Data Replication"
●
I
Understanding Data Replication
During data replication, data is sent from one system (the source) to another system,
usually in another location (the target). For example, you might replicate data from a branch
office (the source) to a central office (the target).
Sources send replicated data, and targets receive replicated data. A target system can
receive data from up to ten sources. A source system can send data to up to two targets.
Finally, one system can act as both a source and a target.
Replication works only with deduplicated data, and data is compressed before it is repli-
cated. Because of this, the amount of data transmitted between systems during replication
is greatly reduced compared to the original amount of data stored. In addition, a data block
is transmitted only if the target does not already have a copy of the block. Finally, data can
optionally be encrypted before it is transmitted.
U41840-J-Z125-7-76
Fujitsu Technology Solutions recommends that you configure and start replication
before storing large amounts of data on the ETERNUS CS800.
To schedule replication for a share or partition, use the Configuration > Scheduler
page (see "Scheduling a Share or Partition for Replication" on page
the amount of network bandwidth used for replication, enable a constant throttle
(see "Enabling System Throttling" on page
(see "Scheduling Replication Throttling" on page
237), or schedule replication throttling
282).
281). To limit
341
