Page 1 ™ GranDSLAM 4200 ATM Stackable DSLAM User’s Guide Document No. 4200-A2-GB20-00 August 2002...
Page 2 Paradyne worldwide office locations, use one of the following methods: Internet: Visit the Paradyne World Wide Web site at www.paradyne.com. (Be sure to register your warranty at www.paradyne.com/warranty.) Telephone: Call our automated system to receive current information by fax or to speak with a company representative.
Page 3: Table Of Contents
Logging In ..........GranDSLAM 4200 Turn-up Procedure......
Page 4 Related Commands ........August 2002 3-10 3-12 3-13 3-13 3-14 3-14 3-15 3-15 3-16 3-17 3-17 3-18 3-19 3-19 3-20 3-20 3-21 3-22 3-23 3-23 3-24 3-24 3-25 3-25 3-26 3-26 3-27 3-27 4200-A2-GB20-00...
Page 5 Related Command........4200-A2-GB20-00 August 2002...
Page 6 Related Commands ........August 2002 4-10 4-10 4-11 4-11 4-12 4-13 4-14 4-14 4-15 4-15 4-18 4-18 4200-A2-GB20-00...
Page 7 Related Commands ........4200-A2-GB20-00 August 2002...
Page 8 Related Commands ........August 2002 6-10 6-11 6-12 6-12 7-11 7-11 4200-A2-GB20-00...
Page 9 Related Commands ........4200-A2-GB20-00 August 2002...
Page 10 August 2002 9-10 9-10 9-12 9-12 10-1 10-2 10-3 10-4 10-4 10-5 10-6 10-8 10-8 10-9 10-10 10-11 10-11 10-12 10-13 10-14 10-14 10-15 10-16 10-17 10-17 10-18 10-19 10-21 10-21 10-22 10-23 10-24 10-24 10-25 10-26 10-27 10-27 4200-A2-GB20-00...
Page 11 Related Command........4200-A2-GB20-00 August 2002...
Page 12 ..........August 2002 12-6 12-6 12-7 12-7 12-8 12-8 12-9 12-9 12-10 12-10 12-11 12-11 12-12 12-12 12-13 12-13 12-14 12-14 12-15 12-15 13-1 13-2 13-2 13-3 13-3 13-4 13-4 13-5 13-5 13-6 13-6 13-7 13-7 4200-A2-GB20-00...
Page 13 Related Commands ........4200-A2-GB20-00 ..........
Page 14 August 2002 14-21 14-21 14-22 14-22 14-23 14-23 14-24 14-24 14-25 14-25 14-28 14-28 14-29 14-29 14-30 14-30 14-31 14-33 14-34 14-34 14-35 14-35 14-36 14-36 15-1 15-2 15-2 15-3 15-3 15-4 15-5 15-6 15-6 15-7 15-7 15-8 15-8 4200-A2-GB20-00...
Page 15 STP Commands ......... 4200-A2-GB20-00...
Page 16 DS1 MIB (RFC 2495) ........Paradyne Enterprise MIBs ........
Page 17 Paradyne DS1 Config MIB (RFC 2495) ......Paradyne DS1 Extension MIB ......
Page 18 Contents August 2002 4200-A2-GB20-00...
Page 19: About This Guide
About This Guide Document Purpose and Intended Audience This guide contains information necessary for the use of the GranDSLAM 4200 ATM Stackable DSLAM. The successful user of this manual has some experience with the installation and configuration of DSL network devices, and Transaction Language No. (TL1) commands.
Page 20 Appendix B, Command Cross Reference Appendix C, Traps and MIBs Index A master glossary of terms and acronyms used in Paradyne documents is available online at www.paradyne.com. Select Library Technical Glossary Product-Related Documents Complete documentation for this product is available online at www.paradyne.com.
Page 21 To order a paper copy of a Paradyne document: Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396) Outside the U.S.A., call 1-727-530-8623 4200-A2-GB20-00 August 2002 About This Guide...
Page 22 About This Guide August 2002 4200-A2-GB20-00...
Page 23 It is available with or without an integrated POTS splitter and is interoperable with the Hotwire 6390 ReachDSL modem. The GranDSLAM 4200 provides 24 ports for connection to an ATM network. Multiple uplink options are available, including T1 and E1. A user interface is provided via a Transaction Language No.
Page 24 1. Introduction to the Hotwire 4200 GranDSLAM Figure 1-2 Figure 1-2. shows a typical application for the GranDSLAM 4200. GranDSLAM 4200 Sample Application August 2002 4200-A2-GB20-00...
Page 25 Features The GranDSLAM 4200 DSLAM has the following features: Compact size (height = 1U) Shelf-mountable (up to five units high) and rack-mountable Low price per port Up to 24 ports per unit Up to 120 ports per stack Integrated POTS splitter option Multiple uplink options: —...
Page 26 1. Introduction to the Hotwire 4200 GranDSLAM August 2002 4200-A2-GB20-00...
Page 27: Using The Command Line Interface
The system supports multiple simultaneous CLI sessions. TL1 Command Language The GranDSLAM 4200 uses Transaction Language No. 1 (TL1) commands since it is a universal language and is familiar to many network users. The TL1 command is in the following general format: COMMAND_CODE:[STAGING PARAMETERS]::<DATA_PARAMETERS>;...
Page 28: Command Code
Message All) OPR-LPBK-VCL (Operate Loopback VCL) INIT-LOG (Initialize Log) RD-SYNCN (Read Synchronization) REPT-ALM-EQPT (Report Alarm Equipment) RLS-LPBK-T1 (Release Loopback T1) RTRV-COND-T1 (Retrieve Condition T1) SET-DAT (Set Date) STA-LAMPTST (Start Lamptest) STP-LAMPTST (Stop Lamptest) ACT-USER (Activate User) ACT-USER-SECU (Activate User Security) 4200-A2-GB20-00...
Page 29: Parameters
NE, or are autonomous. The response message can be either normal or an error report (see are not a response to an input command are classified as autonomous. 4200-A2-GB20-00 2. Using the Command Line Interface Designate where the verb of the command conducts...
Page 30: Command Entry Features
2. Using the Command Line Interface Command Entry Features The GranDSLAM 4200 uses Transaction Language No. 1 (TL1) language for CLI commands and messages. These commands and messages are used to configure and maintain the system. TL1 offers the following features to help you with command entry: Automatic command completion.
Page 31: T User Access Privilege Levels
SUPER – The user has access to all commands (supervisor level). The GranDSLAM 4200 is shipped with a default user of SUPERUSER and password of ASN#1500. This provides supervisor-level access. It is recommended that you change this default to define the user password(s) and user access...
Page 32 2. Using the Command Line Interface GranDSLAM 4200 Turn-up Procedure You can turn up your GranDSLAM 4200 through the Ethernet connection via a PC or terminal connected to the unit’s CONSOLE port. Then using a series of TL1 commands or an NMS system such as Paradyne’s GrandVIEW Element Management System (EMS), you configure the unit for operation.
Page 33: Turn-Up Procedure For Inband Management
1483 routed encapsulation. Then, configure routers, etc., as necessary to route data from the NOC to the GranDSLAM 4200. 3. Enable security for your GranDSLAM 4200 unit. Using the TL1 command ENT-USER-SECU, change the default login and password. Use the EMS to configure SNMP community strings, the SYSLOG server, and trap managers.
Page 34: Configuring The Unit For Operation
2. Using the Command Line Interface 5. Enable security for your GranDSLAM 4200 unit. Using the TL1 command ENT-USER-SECU, change the default login and password. Use the EMS to configure SNMP community strings, the SYSLOG server, and trap managers. 6. Change the time, if necessary. The Simple Network Time Protocol (SNTP), which maintains the unit’s clock, defaults to enabled for multicast.
Page 35 Activate the ADSL line profiles created Create a Virtual Channel Link (VCL) endpoint for the GranDSLAM 4200 Connect VCL endpoints 4200-A2-GB20-00 GranDSLAM 4200 Configuration Commands Enter this command . . . ENT-EQPT:[tid]:aid_eqpt:[ctag]::eqpt_type: [eqpt_nblk]:[pst]; RTRV-PROFILE-ATMACC:[tid]:atmacc_profile_id: [ctag]::,[profile_scope]; ED-ADSL:[tid]:aid_adsl:[ctag]:::[adsl_nblk]:[ pst];...
Page 36 2. Using the Command Line Interface 2-10 August 2002 4200-A2-GB20-00...
Page 37 REPT EVT ADSL RTRV-ADSL RTRV-ATUR RTRV-PM-ADSL RTRV-PROFILE-ADSL RTRV-PROFILE-ADSLALM RTRV-PROFILE-ADSLDN RTRV-PROFILE-ADSLDNALM RTRV-PROFILE-ADSLUP RTRV-PROFILE-ADSLUPALM 4200-A2-GB20-00 on page 3-2 on page 3-4 on page 3-6 on page 3-8 on page 3-10 on page 3-14 on page 3-16 on page 3-19 on page 3-21...
Page 38: Response Format
Numeric identifier of a profile (1 30). Grouping and ranging are allowed. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 39: Example
42 COMPLD /* ACT-PROFILE-ADSL:TAMPA:6:42 */ Related Commands DLT-PROFILE-ADSL ED-PROFILE-ADSLDN ED-PROFILE-ADSLUP ENT-PROFILE-ADSL RTRV-PROFILE-ADSL 4200-A2-GB20-00 ACT-PROFILE-ADSL Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 40: Response Format
Numeric identifier of a profile (1 30). Grouping and ranging are allowed. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 41: Related Command
42 COMPLD /* ACT-PROFILE-ADSLALM:TAMPA:6:42 */ Related Commands DLT-PROFILE-ADSLALM ED-PROFILE-ADSLDNALM ED-PROFILE-ADSLUPALM ENT-PROFILE-ADSLALM RTRV-PROFILE-ADSLALM 4200-A2-GB20-00 ACT-PROFILE-ADSLALM Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 42: Response Format
Numeric identifier of a profile (2 30). Grouping and ranging are allowed. Profile 1 is a predefined profile and cannot be deleted. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 43: Related Commands
TAMPA 02-01-24 12:30:43 42 COMPLD /* DLT-PROFILE-ADSL:TAMPA:6:42 */ Related Commands ACT-PROFILE-ADSL ENT-PROFILE-ADSL RTRV-PROFILE-ADSL 4200-A2-GB20-00 DLT-PROFILE-ADSL Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 44: Response Format
Numeric identifier of a profile (2 30). Grouping and ranging are allowed. Profile 1 is a predefined profile and cannot be deleted. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 45: Example
TAMPA 02-01-24 12:30:43 42 COMPLD /* DLT-PROFILE-ADSLALM:TAMPA:6:42 */ Related Commands ACT-PROFILE-ADSLALM ENT-PROFILE-ADSLALM RTRV-PROFILE-ADSLALM 4200-A2-GB20-00 DLT-PROFILE-ADSLALM Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 46 Plain Old Telephone Service (POTS) on the DSL line. The default is 3 volts. The values supported are: – 0 to 74 volts, in 1-volt increments (setting to 74 volts disables POTS detection) – Disable (disables POTS detection) August 2002 4200-A2-GB20-00...
Page 47 Table 3-9. ED-ADSL:[tid]:aid_adsl:[ctag]:::[adsl_nblk]:[pst]; adsl_nblk (continued) [pst] 4200-A2-GB20-00 ED-ADSL Command Parameters (2 of 2) MXTXPWRDN: Specifies the maximum transmission power settings for the ATU-C. The maximum transmit power range may be limited according to local guidelines when spectrum management is enabled.
Page 48: Parameter Explanation
Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes August 2002 4200-A2-GB20-00...
Page 49: Example
Edit rack 1, shelf 1, slot 1, circuit 20 to have an ADSL line profile of 4 and be in service. ED-ADSL:TAMPA:ADSL-1-1-1-20:42:::ADSLPROF=4:PST=IS; TAMPA 01-10-20 11:32:43 42 COMPLD /* ED-ADSL:TAMPA:ADSL-1-1-1-20:42:::ADSLPROF=4:PST=IS Related Command RTRV-ADSL 4200-A2-GB20-00 on page 3-32 August 2002 3. ADSL Facility Commands 3-13...
Page 50: Ed-Profile-Adsldn
RAMODE: Rate adaptive mode. Valid value is AT_RUN (Automatically selected at run time). PFBR: Planned fast channel bit rate in kilobits per second (32 2176). The default is 32. If not specified, the values of these parameters remain unchanged. August 2002 4200-A2-GB20-00...
Page 51: Example
Related Commands ACT-PROFILE-ADSL DLT-PROFILE-ADSL ED-PROFILE-ADSLUP ENT-PROFILE-ADSL RTRV-PROFILE-ADSL RTRV-PROFILE-ADSLDN RTRV-PROFILE-ADSLUP 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 52 TL1 autonomous message are sent if the current rate is previous rate minus this threshold (0-2176 kbps in 32 kbps increments, where 0 disables the messages). The default is 0. If not specified, the values of these parameters remain unchanged. August 2002 on page 3-26 for 4200-A2-GB20-00...
Page 53: Response Format
Edit profile 6 to have an Errored Seconds threshold of 2. ED-PROFILE-ADSLDNALM:TAMPA:6:42:::ES-L=2; TAMPA 02-07-24 12:30:43 42 COMPLD /* ED-PROFILE-ADSLDNALM:TAMPA:6:42:::ES-L=2; */ 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 54: Related Commands
3. ADSL Facility Commands Related Commands ENT-PROFILE-ADSLALM RTRV-PROFILE-ADSLDNALM 3-18 on page 3-26 on page 3-47 August 2002 4200-A2-GB20-00...
Page 55: Ed-Profile-Adslup
COMPLD ED-PROFILE-ADSLUP:[tid]:adsl_profile_id:[ctag]:::[adslprof_n blk] */ 4200-A2-GB20-00 on page 3-24 for information on how to create a new Identification of the target NE. TID is optional and has an default value of null. The NE's SID code is the only other valid value.
Page 56: Example
Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes on page 3-2 on page 3-6 on page 3-14 on page 3-24 on page 3-40 on page 3-44 on page 3-50 August 2002 4200-A2-GB20-00...
Page 57 [tid] adsl_profile_id [ctag] [adslprof_nblk] 4200-A2-GB20-00 ENT-PROFILE-ADSLALM Identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Numeric identifier of a profile (1 30).
Page 58: Response Format
INITFAIL: Initialization Failure. Enables or disables InitFailureTrap messages specified in RFC 2662. – Y: Enable Initialization Failure Trap messages only. – N: Disable Initialization Failure Trap messages only (Default). If not specified, the values of these parameters remain unchanged. August 2002 4200-A2-GB20-00...
Page 59: Example
TAMPA 02-07-24 12:30:43 42 COMPLD /* ED-PROFILE-ADSLUPALM:TAMPA:6:42:::SES-L=8; */ Related Commands ACT-PROFILE-ADSLALM DLT-PROFILE-ADSLALM ENT-PROFILE-ADSLALM RTRV-PROFILE-ADSLUPALM 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 60: Ent-Profile-Adsl
The default is 0. Name (1 32 characters) that uniquely identifies the profile Latency of the ADSL line. Only single latency is supported upstream and downstream. The valid value is FAST (only ADSL FAST supported). August 2002 4200-A2-GB20-00...
Page 61: Rtrv-Profile-Adsl
42 COMPLD /* ENT-PROFILE-ADSL:TAMPA:6:42:TAMPA201 */ Related Commands ACT-PROFILE-ADSL DLT-PROFILE-ADSL ED-PROFILE-ADSLDN ED-PROFILE-ADSLUP RTRV-PROFILE-ADSL 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 62: Ed-Profile-Adsldnalm
If no adsl_profile-id is specified, the next available index will be assigned. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. Name (1 32 characters) that uniquely identifies the profile August 2002 4200-A2-GB20-00...
Page 63: Rtrv-Profile-Adslalm
TAMPA 02-07-24 08:23:13 42 COMPLD /* ENT-PROFILE-ADSLALM:TAMPA:6:42:TAMPA201 */ Related Commands ACT-PROFILE-ADSLALM ED-PROFILE-ADSLDNALM ED-PROFILE-ADSLUPALM RTRV-PROFILE-ADSLALM 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 64 LOS: Loss of Signal (Near End only) LPR: Loss of Power (Far End only) Service effect. Valid values are: SA: Service affecting NSA: Not service affecting Date of occurrence in the format mm-dd. Time of occurrence in the format hh-mm. August 2002 4200-A2-GB20-00...
Page 65 REPT ALM ADSL aid_adsl:ntfcde,cond_adsl, srveff,[ocrdat],[ocrtm],[locn], [dirn];[cond_descr]; [locn] [dirn] [cond_descr] 4200-A2-GB20-00 Location of the condition. Valid values are: NEND: Near end FEND: Far end If no value is specified, ALL is assumed. Signal direction. Valid value is RCV (Receive).
Page 66 LPRS-L: Loss Of Power Seconds (line) (Near End only) LOSS-L: Loss Of Signal Seconds (line) (Near End only) The effect of the event on the condition reported. Valid values are: SC: Standing condition raised CL: Standing condition cleared Date of occurrence in the format mm-dd. August 2002 4200-A2-GB20-00...
Page 67 REPT EVT ADSL aid_adsl:cond_adsl,[condeff], [ocrdat],[ocrtm],[locn],[dirn];[cond_descr]; ocrtm [locn] [dirn] [cond_descr] 4200-A2-GB20-00 Time of occurrence in the format hh-mm. Location of the condition. Valid values are: NEND: Near end FEND: Far end If no value is specified, ALL is assumed.
Page 68: Response Format
The default is 0. Primary state filter. Valid values are: IS: Retrieve In-Service entities only OOS: Retrieve Out-Of-Service entities only Grouping is allowed. If no value is specified, this filter is ignored. Secondary state filter. This filter is ignored. August 2002 4200-A2-GB20-00...
Page 69 Parameter yy-mm-dd hh:mm:ss COMPLD DENY /* */ aid_adsl adsl_nblk 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 70: Examples
As described for command parameters (see Command Parameters). Error code (see Appendix A, Error Codes on page 3-6 on page 3-10 on page 3-14 on page 3-19 on page 3-24 on page 3-40 on page 3-44 on page 3-50 August 2002 Table 3-25, RTRV-ADSL 4200-A2-GB20-00...
Page 71: Response Format
DENY /* RTRV-ATUR:[tid]:aid_atur:[ctag] */ errcde 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier for an ADSL line. The value can be preceded with AID=, but this is not required.
Page 72: Example
Named parameter block for ADSL line. The block consists the following parameter and a valid value. CURSWER: Installed version of software (1 32 characters). If equipment is not installed or no software is available, no value is shown. August 2002 Table 3-27, RTRV-ATUR 4200-A2-GB20-00...
Page 73 [monadsl] [monlev] [tmper] [monrdat] 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier for an ADSL line. The value can be preceded with AID=, but this is not required. Grouping and ranging are allowed. Enter...
Page 74: Response Format
The default is the value nearest the current time. Grouping is allowed. Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied August 2002 4200-A2-GB20-00...
Page 75: Example
42 COMPLD RTRV-PM-ADSL:TAMPA:ADSL-1-1-1-9:42:::ES-F,5187-UP,NEND,,15-M IN,06-10,6-30: "ADSL-1-1-1-9:ES-F,2015,,NEND,,15-MIN,06-10,6-30" Related Commands ED-ADSL 4200-A2-GB20-00 Explanation Enclosed are human readable comments – unspecified format As described for command parameters (see RTRV-PM-ADSL Command Parameters), except that ALL is not used. Type of AID. The value is ADSL.
Page 76: Response Format
Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. Scope of the profile. The valid value is LOCAL (local to this stack only). If no value is specified, this parameter is ignored (all values are reported). August 2002 4200-A2-GB20-00...
Page 77: Example
TAMPA 02-07-24 12:30:43 42 COMPLD /* RTRV-PROFILE-ADSL:TAMPA:5:42 */ 5:LOCAL:TAMPA101:CONFIG Related Commands ACT-PROFILE-ADSL DLT-PROFILE-ADSL ENT-PROFILE-ADSL 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 78: Response Format
Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. Scope of the profile. The valid value is LOCAL (local to this stack only). If no value is specified, this parameter is ignored (all values are reported). August 2002 4200-A2-GB20-00...
Page 79: Example
5:LOCAL:TAMPA101:CONFIG Related Commands ACT-PROFILE-ADSLALM DLT-PROFILE-ADSLALM ED-PROFILE-ADSLDNALM ED-PROFILE-ADSLUPALM ENT-PROFILE-ADSLALM RTRV-PROFILE-ADSLALM 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 80: Response Format
The default is 0. The scope of a profile. The valid value is LOCAL (local to this stack only). If no parameter is specified, this value is ignored (all values are reported). August 2002 on page 3-14 for 4200-A2-GB20-00...
Page 81 COMPLD DENY /* */ adsl_profile_id profile_scope profile_name [adslprof_nblk] errcde 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 82: Example
3. ADSL Facility Commands Example Retrieve profile 6. RTRV-PROFILE-ADSLDN:TAMPA:6:42; TAMPA 02-07-24 12:30:43 42 COMPLD /* RTRV-PROFILE-ADSLDN:TAMPA:6 */ 6:LOCAL:TAMPA101:MINNMR=0,MAXNMR=16,TNMR=5,RAMODE=AT_RUN, PFBR=32,MAXFBR=2176,MINFBR=32 Related Commands ED-PROFILE-ADSLDN 3-46 on page 3-14 August 2002 4200-A2-GB20-00...
Page 83: Response Format
DENY RTRV-PROFILE-ADSLDNALM:[tid]:adsl_profile_id:[ctag][::profil e_ scope] */ errcde 4200-A2-GB20-00 ENT-PROFILE-ADSL Identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Numeric identifier of a profile (1 30).
Page 84 TL1 autonomous message are sent if the current rate is previous rate plus this threshold (0-2176 kbps in 32 kbps increments, where 0 disables the messages). The default is 0. August 2002 Table 3-37, Parameters), except that ALL Table 3-37, Parameters). 4200-A2-GB20-00...
Page 85: Example
6:LOCAL:TAMPA101:LOFS-L=0,LPRS-L=0,LOL-L=0,ES-L=120,SES-L=15 UAS-L=0,INCRATE-F=0,DECRATE-F=0 Related Command ED-PROFILE-ADSLDNALM ENT-PROFILE-ADSL 4200-A2-GB20-00 Explanation DECRATE-F: Decreasing Rate (fast channel). SNMP rate change trap and TL1 autonomous message are sent if the current rate is previous rate minus this threshold (0-2176 kbps in 32 kbps increments, where 0 disables the messages). The default is 0.
Page 86: Response Format
The default is 0. The scope of a profile. The valid value is LOCAL (local to this stack only). If no parameter is specified, this value is ignored (all values are reported). August 2002 on page 3-24 for 4200-A2-GB20-00...
Page 87 COMPLD DENY /* */ adsl_profile_id profile_scope profile_name [adslprof_nblk] errcde 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 88: Example
3. ADSL Facility Commands Example Retrieve profile 6. RTRV-PROFILE-ADSLUP:TAMPA:6:42; TAMPA 02-07-24 12:30:43 42 COMPLD /* RTRV-PROFILE-ADSLUP:TAMPA:6 */ 6:LOCAL:TAMPA101:MINNMR=0,MAXNMR=16,TNMR=5,RAMODE=AT_RUN,PFB R=160,MAXFBR=0,MINFBR=32 Related Commands ED-PROFILE-ADSLUP ENT-PROFILE-ADSL 3-52 on page 3-19 on page 3-24 August 2002 4200-A2-GB20-00...
Page 89: Response Format
DENY RTRV-PROFILE-ADSLUPALM:[tid]:adsl_profile_id:[ctag][::profil e_ scope] */ errcde 4200-A2-GB20-00 ENT-PROFILE-ADSLALM Identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Numeric identifier of a profile (1 30).
Page 90 TL1 autonomous message are sent if the current rate is previous rate plus this threshold (0-2176 kbps in 32 kbps increments, where 0 disables the messages). The default is 0. August 2002 Table 3-41, Parameters), except that ALL Table 3-41, Parameters). 4200-A2-GB20-00...
Page 91: Example
6:LOCAL:TAMPA101:LOFS-L=0,LOSS=0,LOLS=0,ES-L=120,SES-L=15, UAS-L=0,INCRATE-F=0,DECRATE-F=0,INIT=N Related Command ED-PROFILE-ADSLUPALM ENT-PROFILE-ADSLALM 4200-A2-GB20-00 Explanation DECRATE-F: Decreasing Rate (fast channel). SNMP rate change trap and TL1 autonomous message are sent if the current rate is previous rate minus this threshold (0-2176 kbps in 32 kbps increments, where 0 disables the messages). The default is 0.
Page 92 3. ADSL Facility Commands 3-56 August 2002 4200-A2-GB20-00...
Page 93 This chapter contains the following DS1 Facility commands: ED-T1 ENT-T1 REPT ALM T1 REPT EVT T1 REPT-OPSTAT-T1 RTRV-PM-T1 RTRV-T1 4200-A2-GB20-00 on page 4-2 on page 4-5 on page 4-8 on page 4-9 on page 4-10 on page 4-12 on page 4-15...
Page 94 PORTID: Port identifier (32 characters maximum). Indicates the user to whom the port is assigned. The following values are reserved and cannot be used: – AVAILABLE: Port is not assigned. – FAILED: Port has failed and cannot be assigned (default is null). August 2002 Table 4-4, T1 Line 4200-A2-GB20-00...
Page 95 DENY /* ED-T1:[tid]:aid_ds1:[ctag]:::[ds1_nblk]:[pst] */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 ED-T1 Command Parameters (2 of 2) For the following parameters if no value is specified, null is assumed. ATMACCPROF: ATM Access Profile index (1). This value determines the range of values for vpi and vci in several other commands. The value cannot be changed while any VPLs or VCLs exist.
Page 96 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes on page 4-15 August 2002 4200-A2-GB20-00...
Page 97 [tid] aid_ds1 [ctag] ds1_nblk 4200-A2-GB20-00 ENT-T1 Command Parameters (1 of 2) Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access Identifier for a DS1 facility. The value can be preceded with AID=, but this is not required.
Page 98 OOS: Out of service. OOS-MA (out of service, management) is implied. If no value is specified, this parameter is set to IS. T1 Line Equalization Values Cable length (feet) 0 133 134 266 267 399 400 533 534 655 August 2002 Equalization (dB) 4200-A2-GB20-00...
Page 99 TAMPA 01-11-24 12:30:43 42 COMPLD /* ENT-T1:TAMPA:NTT1:42:::LINETYPE=T1 */ Related Commands ED-T1 on page 4-2 RTRV-T1 4200-A2-GB20-00 ENT-T1 Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 100 Time of occurrence in the format: hh-mm (hour 0 23 and minute 0 59) Location of condition. The value is NEND (Near End). Direction of condition. Values are: RCV: Receive TRMT: Transmit (for ACTLPBK) Description of alarm condition (40 characters maximum). August 2002 4200-A2-GB20-00...
Page 101 [ocrdat] [ocrtm] [locn] [dirn] [cond_descr] 4200-A2-GB20-00 REPT EVT T1 Response Parameters Alarm code. Identifies the severity of the alarm. Values are: *C: Critical alarm **: Major alarm *^: Minor alarm A^: Automatic message (typically used to report a cleared alarm) Automatic tag that indicates the numerical sequence of messages reported.
Page 102 AID=, but this is not required. Enter in the following format, replacing lower-case parameters with the values given: NTT1-circuit – circuit: DS1 circuit in the NT (1) Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 103 TAMPA 01-11-24 12:30:43 42 COMPLD /* REPT-OPSTAT-T1:TAMPA:NTT1-1:42 */ "NTT1-3:INCELLS,35500" "NTT1-3:OUTCELLS,23300" Related Commands None 4200-A2-GB20-00 REPT-OPSTAT-T1 Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 104 Location of the facility. Valid values are: NEND: Near end FEND: Far end (not supported on G.703 interfaces) If no value is specified, this parameter is not used for filtering responses. Time period. The only valid value is 15-MIN (15 minutes). August 2002 4200-A2-GB20-00...
Page 105 Error Response: sid yy-mm-dd hh:mm:ss DENY RTRV-PM-T1:[tid]:aid_ds1:[ctag]::[monds1],[monlev],[locn],, [tmper],[mondat],[montm] */ errcde 4200-A2-GB20-00 Start date for the monitoring period. Valid values are: mm-dd: Month and day – mm: Month (1 12) – dd: Day (1 31) ALL: All performance monitoring data is retrieved If no value is specified, today's date is assumed.
Page 106 As described for command parameters As described for command parameters, except that ALL is not used As described for command parameters, except that ALL is not used Error code (see Appendix A, Error Codes on page 10-12 August 2002 4200-A2-GB20-00...
Page 107 IP c After the above response, a new command input may be generated. 4200-A2-GB20-00 Identification of the target NE. They default value is null. The NE SID code is the only other valid value. Access Identifier for the DS1 facility. The value can be preceded with AID=, but this is not required.
Page 108 – G703LONG: For E1 model. G.703 long-haul interface (120 ohm connector). Default for E1 models. – T1: T1 power loop. For T1 model. T1 long-haul interface. Default for T1 models. – G703SHORT75: For E1 model. G.703 short-haul interface (75 ohm connector). August 2002 Table 4-4, 4200-A2-GB20-00...
Page 109 Table 4-13. RTRV-T1 Response Parameters (2 of 2) Parameter ds1_nblk (continued) state errcde 4200-A2-GB20-00 Explanation TMG: Timing supply – INT: Internal timing source. Use the NE system timing source (default). – LPD: Loop timing PORTID: Port identifier (32 characters maximum). Indicates the user to whom the port is assigned.
Page 110 4. DS1 Facility Commands Example Retrieve configuration data for circuit 1 on the NT. RTRV-T1:TAMPA:NTT1-1:42::::; TAMPA 01-11-24 12:30:43 42 COMPLD /* RTRV-T1:TAMPA:NTT1-1:42:::: */ NTT1-1::LINETYPE=DSX1,LBO=0,EQLZ=0:IS-NR Related Commands on page 4-2 ED-T1 ENT-T1 on page 4-5 4-18 August 2002 4200-A2-GB20-00...
Page 111: Atm Commands
This chapter contains the following other commands: DLT-PROFILE-TRAFDSC DLT-VCL ED-ATMPORT ENT-PROFILE-TRAFDSC ENT-VCL RTRV-ATMPORT RTRV-PROFILE-ATMACC RTRV-PROFILE-TRAFDSC RTRV-VCL 4200-A2-GB20-00 on page 5-2 on page 5-4 on page 5-6 on page 5-8 on page 5-10 on page 5-13 on page 5-16 on page 5-19 on page 5-21...
Page 112 Numeric identifier of a profile (1 250). Grouping and ranging are allowed. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 113 DLT-PROFILE-TRAFDSC:TAMPA:5:42; TAMPA 01-11-24 12:30:43 42 COMPLD /* DLT-PROFILE-TRAFDSC:TAMPA:5:42 */ Related Commands ENT-PROFILE-TRAFDSC RTRV-PROFILE-TRAFDSC 4200-A2-GB20-00 DLT-PROFILE-TRAFDSC Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 114: Dlt-Vcl
– vpi: Virtual Path Identifier (for LT vpi=0, for NT vpi=0 15) – vci Virtual Channel Identifier (for LT vpi=32 63, for NT vpi=32 1023) Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 115: Example
DLT-VCL:TAMPA:NTVCL-15:42; TAMPA 01-11-24 12:30:43 42 COMPLD /* DLT-VCL:TAMPA:NTVCL-15:42 */ Related Commands ENT-VCL RTRV-VCL 4200-A2-GB20-00 DLT-VCL Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 116: Ed-Atmport
– shelf: Shelf number (1) – slot: LT slot number (1) – circuit: ADSL circuit on the LT (1 24) Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 117: Example
ED-ATMPORT:TAMPA:LTATM-1-1-1-9:42:::SEGID=ALLONES TAMPA 01-11-24 12:30:43 42 COMPLD /* ED-ATMPORT:TAMPA:LTATM-1-1-1-9:42:::SEGID=ALLONES */ Related Commands RTRV-ATMPORT 4200-A2-GB20-00 ED-ATMPORT Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 118: Ent-Profile-Trafdsc
Traffic descriptor type. The valid value is UBR (UBR best effort). Named parameter block for the ATM traffic descriptor profile. The valid value is: DISCARD: Partial packet discard – Yes: Partial packet discard is enabled – No: Partial packet discard is disabled (default) August 2002 4200-A2-GB20-00...
Page 119: Example
ENT-PROFILE-TRAFDSC:TAMPA:5:42; TAMPA 01-11-24 12:30:43 42 COMPLD ENT-PROFILE-TRAFDSC:TAMPA:5:42::TAMPA101,,UBR:DISCARD=YES */ Related Commands DLT-PROFILE-TRAFDSC RTRV-PROFILE-TRAFDSC 4200-A2-GB20-00 ENT-PROFILE-TRAFDSC Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 120: Ent-Vcl
Transmit traffic descriptor profile index (1 250). Transmit traffic descriptor profile name. If a local profile and network profile both match this name, the network profile is used. August 2002 4200-A2-GB20-00...
Page 121: Response Format
Table 5-10. ENT-VCL Response Parameters Parameter yy-mm-dd hh:mm:ss COMPLD DENY /* */ errcde 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 122: Example
Create a VCL for Virtual Path 15, Virtual Channel 207 with a Receive Traffic Descriptor of 13 and a Transmit Traffic Descriptor of 46 ENT-VCL:TAMPA:NTVCL-15-207:42::13,46; TAMPA 01-11-24 12:30:43 42 COMPLD /* ENT-VCL:TAMPA:NTVCL-15-207:42::13,46 */ Related Commands DLT-VCL RTRV-VCL 5-12 on page 5-4 on page 5-21 August 2002 4200-A2-GB20-00...
Page 123: Rtrv-Atmport
COMPLD /* RTRV-ATMPORT:[tid]:aid_atmport:[ctag]::::[pstf][sstf] 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access Identifier for an ATM port. The value can be preceded with AID=, but this is not required.
Page 124 If the first octet is FF, then octets 2 16 must also be FF. If the first octet is 6A, then octets 2 16 must also be 6A. If no value is specified for this field, then this parameter remains the same. August 2002 Table 5-11, Table 5-11, 4200-A2-GB20-00...
Page 125: Example
Example Retrieve parameters for in-service entities in the loopback state on the NTATM port. RTRV-ATMPORT:TAMPA:NTATM:42::::IS_LPBK; TAMPA 01-11-24 12:30:43 42 COMPLD /* RTRV-ATMPORT:TAMPA:NTATM:42::::IS_LPBK */ NTATNM::SEGID="ALLONES":IS,LPBK Related Commands ED-ATMPORT 4200-A2-GB20-00 on page 5-6 August 2002 5. ATM Commands 5-15...
Page 126: Rtrv-Profile-Atmacc
Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. Scope of the profile. The valid value is LOCAL (local to this stack only). If no value is specified, this parameter is ignored (all values are specified). August 2002 4200-A2-GB20-00...
Page 127 DENY /* */ atmacc_profile_id As described for command parameters (see profile_scope profile_name atmacc_nblk errcde 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 128: Example
5. ATM Commands Example Retrieve parameters for profile 6. RTRV-PROFILE-ATMACC:TAMPA:6:42::,LOCAL; TAMPA 01-11-24 12:30:43 42 COMPLD /* RTRV-PROFILE-ATMACC:TAMPA:6:42::,LOCAL */ 6:LOCAL:TAMPA101:MAXVPCS=0,MAXVCCS=4,VPIBITS=1,VCIBITS=6 Related Commands None 5-18 August 2002 4200-A2-GB20-00...
Page 129: Rtrv-Profile-Trafdsc
DENY RTRV-PROFILE-TRAFDSC:[tid]:trafdsc:[ctag]::,[profile_scope] errcde 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. ranging are allowed and ALL may be used. Correlation tag (6 characters maximum) that links an input command with associated output responses.
Page 130: Example
– Yes: Partial packet discard is enabled. – No: Partial Packet discard is disabled. Appendix A, Error Codes Error code (see on page 5-2 on page 5-8 August 2002 Table 5-15, Parameters), except ALL is not Table 5-15, Parameters). 4200-A2-GB20-00...
Page 131: Rtrv-Vcl
IP c After the above response, a new command input may be generated. 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Virtual Circuit Identifier for the Virtual Circuit. The value can be preceded with AID=, but this is not required.
Page 132 As described for command parameters (see Command Parameters). Receive traffic descriptor profile index (1 250). Transmit traffic descriptor profile index (1 250). As described for command parameters. The only valid value is LBPBK (loopback). August 2002 Table 5-17, RTRV-VCL 4200-A2-GB20-00...
Page 133: Example
Example Retrieve VCL for virtual path 15, virtual channel 307. RTRV-VCL:TAMPA:NTVCL-15-307:42; TAMPA 01-11-24 12:30:43 42 COMPLD /* RTRV-VCL:TAMPA:NTVCL-15-307:42 */ NTVCL-15-307:78,66:IS_NR Related Commands ED-ATMPORT 4200-A2-GB20-00 on page 5-6 August 2002 5. ATM Commands 5-23...
Page 134 5. ATM Commands 5-24 August 2002 4200-A2-GB20-00...
Page 135: Cross-Connection Defaults
VPI = 2, VCI = 33, and Port 3 cross connection is VPI = 2, VCI = 34, and so on. The default uplink for inband management for the ATM-1 interface is VPI = 0, VCI = 33, and for the ATM-2 interface is VPI = 0, VCI = 33. 4200-A2-GB20-00 on page 6-2 on page 6-4...
Page 136: Response Format
– vpi: Virtual Path Identifier (for LT vpi=0, for NT vpi=0 15) – vci: Virtual Channel Identifier for the virtual channel link (for LT vpi=32 63, for NT vpi=32 1023) Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 137: Example
TAMPA 01-11-24 12:30:43 42 COMPLD /* DLT-CRS-VC:TAMPA:NTVCL-14-307,LTVCL-1-1-1-4-0-63:42 Related Commands ED-CRS-VC ENT-CRS-VC RTRV-CRS-VC 4200-A2-GB20-00 DLT-CRS-VC Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 138 Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. Desired Primary State. Valid values are: IS: In-Service OOS: Out-Of-Service (OOS-MA is implied) If not specified, the value of this parameter remains unchanged. August 2002 4200-A2-GB20-00...
Page 139: Response Format
Table 6-4. Parameter yy-mm-dd hh:mm:ss COMPLD DENY /* */ errcde 4200-A2-GB20-00 ED-CRS-VC Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 140: Example
(network side) and Rack 1, Shelf 1, LT Slot 1, Circuit 4, Virtual Path 0, Virtual Channel 63 (user side) to be In-Service. ED-CRS-VC:TAMPA:NTVCL-14-307,LTVCL-1-1-1-4-0-63:42::IS; TAMPA 01-11-24 12:30:43 42 COMPLD /* ED-CRS-VC:TAMPA:NTVCL-14-307,LTVCL-1-1-1-4-0-63 :42::IS */ Related Commands DLT-CRS-VC ENT-CRS-VC RTRV-CRS-VC on page 6-2 on page 6-7 on page 6-10 August 2002 4200-A2-GB20-00...
Page 141 [tid] nt_vcl lt_vcl [ctag] [pst] 4200-A2-GB20-00 ENT-CRS-VC Command Parameters RTRV-PROFILE-ATMACC Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Virtual Channel Identifier for the Virtual Channel Link on the NT (network) side.
Page 142: Response Format
Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes August 2002 4200-A2-GB20-00...
Page 143: Example
Channel 63 (user side), and set the primary state to In-Service. ENT-CRS-VC:TAMPA:NTVCL-14-307,LTVCL-1-1-1-4-0-63:42::::IS; TAMPA 01-11-24 12:30:43 42 COMPLD ENT-CRS-VC:TAMPA:NTVCL-14-307,LTVCL-1-1-1-4-0-63:42::::IS */ Related Commands DLT-CRS-VC ED-CRS-VC RTRV-CRS-VC 4200-A2-GB20-00 on page 6-2 on page 6-4 on page 6-10 August 2002 6. Cross Connect Commands...
Page 144 Selects a range of states from the Bellcore state model. Valid values are: IS: Matches IS-NR OOS: Matches OOS-MA, OOS-AU, OOS-AUMA AU: Matches OOS-AU, OOS-AUMA MA: Matches OOS-MA, OOS-AUMA Grouping and ranging are allowed. If no value is specified, ALL is assumed. August 2002 4200-A2-GB20-00...
Page 145: Response Format
COMPLD DENY /* */ errcde nt_vci 4200-A2-GB20-00 RTRV-CRS-VC Response Parameters (1 of 2) Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 146: Example
– vci: Virtual Channel Identifier (for LT vpi=32 63, for NT vpi=32 1023) State of the cross-connection. Values are IS-NR, OOS-AU, OOS-MA (transient state, changes to OOS-MA) OOS-AUMA, OOS-MAANR on page 6-2 on page 6-4 on page 6-7 August 2002 4200-A2-GB20-00...
Page 147 Equipment Commands Overview This chapter contains the following Equipment commands: ED-EQPT REPT ALM EQPT REPT EVT EQPT RTRV-EQPT RTRV-INV-EQPT 4200-A2-GB20-00 on page 7-2 on page 7-4 on page 7-5 on page 7-6 on page 7-9 August 2002...
Page 148 Input is case-sensitive. If not specified, the value of this parameter remains unchanged. The system resets whenever the software version is changed. Desired Primary State (LT or ACU only). Valid value is IS (In-Service). If not specified, the value of this parameter remains unchanged. August 2002 4200-A2-GB20-00...
Page 149 Edit ACU unit in rack 1, shelf 1 to be In-Service. ED-EQPT:TAMPA:ACU-1-1:42::::IS; TAMPA 01-11-24 12:30:43 42 COMPLD /* ED-EQPT:TAMPA:ACU-1-1:42::::IS */ Related Commands RTRV-EQPT 4200-A2-GB20-00 ED-EQPT Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 150 Service effect. Valid values are: – SA: Service affecting – NSA: Not service affecting Date of alarm occurrence in the format mm-dd (month-day). Time of alarm occurrence in the format hh-mm (hour-minute). Description of alarm condition (40 characters maximum). August 2002 4200-A2-GB20-00...
Page 151 [condeff] [ocrdat] [ocrtm] [conddescr] 4200-A2-GB20-00 REPT EVT EQPT Message Parameters Alarm code. Identifies the severity of the alarm. Values are: – *C: Critical alarm – **: Major alarm – *^: Minor alarm – A^: Automatic message (typically reports a cleared alarm) Automatic tag.
Page 152 – LTA-rack-shelf-slot: Line Termination unit A (on main card) – LPCO-rack-shelf-slot: Low-Pass Filter-Central Office (in expansion slot Grouping is allowed. ALL may be used. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 153 /* */ errcde aid_eqpts [eqpt_type] [cur_eqpt] [eqpt_nblk] state [sst] 4200-A2-GB20-00 RTRV-EQPT Response Parameters Explanation Target NE identification Year (two digits), month, and day Hour (00-23), minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 154 7. Equipment Commands Example Retrieve configuration data associated with Shelf 1. RTRV-EQPT:TAMPA:SHELF-1-1:42; TAMPA 01-11-24 12:30:43 42 COMPLD SHELF-1-1:NONE:NONE:,,:IS-NR, /* RTRV-EQPT:TAMPA:SHELF-1-1:42 */ Related Commands ED-EQPT on page 7-2 August 2002 4200-A2-GB20-00...
Page 155 COMPLD /* RTRV-INV-EQPT:[tid]:aid_eqpt:[ctag] */ aid_eqpt:cur_eqpt,manuf,partno,[rev],[serno],clei 4200-A2-GB20-00 RTRV-INV-EQPT Command Parameters Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier of an equipment unit. The value can be preceded with AID=, but this is not required.
Page 156 Parameters), except that NT and LT are not used. Type of the equipment actually installed (8 characters maximum). If the equipment is not installed, no value is displayed. Manufacturer (Paradyne). Unit’s part number. Numeric Item Change Status (ICS) value indicating the revision level of the unit.
Page 157 Example Retrieve inventory for Shelf 1. RTRV-INV-EQPT:TAMPA:SHELF-1-1:42::; TAMPA 02-08-06 12:30:43 42 COMPLD SHELF-1-1:ALTS-A,PARADYNE,,,,, /* RTRV-INV-EQPT:TAMPA:SHELF-1-1:42 */ Related Commands None 4200-A2-GB20-00 August 2002 7. Equipment Commands 7-11...
Page 158 7. Equipment Commands 7-12 August 2002 4200-A2-GB20-00...
Page 159 This chapter contains the following IP Access commands: DLT-ATMARPENT DLT-IPPORT ED-IPPORT ENT-ATMARPENT ENT-IPPORT REPT-OPSTAT-IPPORT RTRV-ATMARPENT RTRV-IPPORT 4200-A2-GB20-00 on page 8-2 on page 8-4 on page 8-6 on page 8-9 on page 8-11 on page 8-14 on page 8-17 on page 8-19...
Page 160 Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. The IP address associated with the port. Valid values are: ddd.ddd.ddd.ddd (where ddd is 1 255). ALL may be used. August 2002 4200-A2-GB20-00...
Page 161 42 COMPLD /* DLT-ATMARPENT:TAMPA:ATM-2:42::123.201.143.71 */ Related Commands ENT-IPPORT ED-IPPORT ENT-ATMARPENT RTRV-IPPORT RTRV-ATMARPENT 4200-A2-GB20-00 DLT-ATMARPENT Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 162 ATM-2: Second IP-over-ATM interface in the NT ETH-1: First Ethernet interface in the NT Grouping is allowed and ALL may be used. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 163 42 COMPLD /* DLT-IPPORT:TAMPA:ATM-2:42 */ Related Commands DLT-ATMARPENT ENT-IPPORT ED-IPPORT ENT-ATMARPENT RTRV-IPPORT 4200-A2-GB20-00 DLT-IPPORT Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 164 PHYADDR: Physical address associated with the port. Used by BOOTP on ETH-1. Valid values are: – xx-xx-xx-xx-xx-xx-xx-xx where each x is a hexadecimal digit (0 F). This must be the MAC address originally assigned to the unit if aid_port is ETH-1. August 2002 4200-A2-GB20-00...
Page 165 DENY; /* ED-IPPORT:[tid]:aid_ipport:[ctag]::cfg_mode: ipport_nblk */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 ED-IPPORT Command Parameters (2 of 2) Desired primary state. Valid values are: IS: In Service (default) OOS: Out Of Service (OOS-MA is implied) If no value is specified, this parameter remains unchanged.
Page 166 If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes on page 8-2 on page 8-9 on page 8-11 on page 8-19 August 2002 4200-A2-GB20-00...
Page 167 Normal Response: sid yy-mm-dd hh:mm:ss c COMPLD ENT-ATMARPENT:[tid]:aid_ipport:[ctag]::ip_addr,[vpi][vci] */ 4200-A2-GB20-00 ENT-ATMARPENT Command Parameters Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier of the IP port to be deleted. The value can be preceded with AID=, but this is not required.
Page 168 If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes on page 8-2 on page 8-11 on page 8-6 on page 8-19 on page 8-17 August 2002 4200-A2-GB20-00...
Page 169 [ctag] cfg_mode ipport_nblk [pst] 4200-A2-GB20-00 ENT-IPPORT Command Parameters Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier of the IP port to be entered. The value can be preceded with AID=, but this is not required.
Page 170 Hour (00-23), minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes August 2002 4200-A2-GB20-00...
Page 171 Configure the SLIP port with a configuration mode of BOOTP and a physical address of 18-00-42-49-09-03-27-22. ENT-IPPORT:TAMPA:SLIP:42::BOOTP:PHYADDR="18-00-42-49-09-03-2 7-22"; TAMPA 00-11-24 12:30:43 42 COMPLD ENT-IPPORT:TAMPA:SLIP:42::BOOTP:PHYADDR="18-00-42-49-09-03-2 7-22" */ Related Commands DLT-ATMARPENT ED-IPPORT ENT-ATMARPENT RTRV-IPPORT 4200-A2-GB20-00 on page 8-2 on page 8-6 on page 8-9 on page 8-19 August 2002 8. IP Access Commands 8-13...
Page 172 ATM-2: Second IP-over-ATM interface in the NT ETH-1: First Ethernet interface in the NT Grouping and ALL are allowed. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 173 COMPLD DENY /* */ errcde aid_ipport [op_ipport] value 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 174 8. IP Access Commands Example Report IP port facility parameters for ETH-1. REPT-OPSTAT-IPPORT:TAMPA:ETH-1 TAMPA 01-11-24 12:30:43 42 COMPLD /* REPT-OPSTAT-IPPORT:TAMPA:ETH-1:42 */ "ETH-1:CURRATE,100000000" "ETH-1:CURDX,4DX" Related Commands None 8-16 August 2002 4200-A2-GB20-00...
Page 175 /* RTRV-ATMARPENT:[tid]:aid_ipport:[ctag]::ip_addr */ errcde /* error description */ 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier of the IP port. The value can be preceded with AID=, but this is not required.
Page 176 The ATM Virtual Channel Identifier associated with the virtual circuit for the entry. The named parameter block for the ARP table containing the following parameter: BITRATE: Bandwidth associated with the ATM VC for the entry. The valid value is 0 (UBR). on page 8-2 on page 8-11 August 2002 4200-A2-GB20-00...
Page 177 COMPLD /* RTRV-IPPORT:[tid]:aid_ipport:[ctag] */ aid_ipport:cfg_mode:[ipport_nblk]::::pst 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier of the IP port. The value can be preceded with AID=, but this is not required.
Page 178 PHYADDR: Physical address associated with the port. Must be unique. The format is: – xx-xx-xx-xx-xx-xx-xx-xx (where each x is a hexadecimal digit 0 F). This is the MAC address originally assigned to the unit if aid_ipport=ETH-1. August 2002 Table 8-15, RTRV-IPPORT 4200-A2-GB20-00...
Page 179 TAMPA 01-11-24 12:30:43 42 COMPLD Related Commands DLT-ATMARPENT ENT-IPPORT 4200-A2-GB20-00 Explanation GATEWAY: IP address of the default IP router (gateway) for this IP interface. Valid values are: – ddd.ddd.ddd.ddd (where ddd is a number 1 255) for ETH-1 only – NONE: No gateway Primary State Filter.
Page 180 8. IP Access Commands 8-22 August 2002 4200-A2-GB20-00...
Page 181 Performance Commands Overview This chapter contains the following Performance commands: REPT-OPSTAT-ADSLCOM REPT-OPSTAT-ADSLDN REPT-OPSTAT-ADSLUP REPT-OPSTAT-VCL 4200-A2-GB20-00 on page 9-2 on page 9-5 on page 9-7 on page 9-10 August 2002...
Page 182: Response Format
– shelf: Shelf number (1) – slot: LT slot number (1) – circuit: ADSL circuit on the LT (1 24) Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 183 COMPLD DENY /* */ errcde aid_adsl op_adsl value 4200-A2-GB20-00 REPT-OPSTAT-ADSLCOM Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 184: Example
9. Performance Commands Examples Report ADSL DMT carrier operations parameters for ADSL-1-1-1-3. REPT-OPSTAT-ADSLCOM:TAMPA:ADSL-1-1-1-3:42; TAMPA 01-10-24 12:30:43 42 COMPLD /* REPT-OPSTAT-ADSLCOM:TAMPA:ADSL-1-1-1-3:42 "ADSL-1-1-1-3:STATUSNE,NORMAL" "ADSL-1-1-1-3:STATUSFE,NORMAL" "ADSL-1-1-1-3:LASTCHNGDATE,11-19" "ADSL-1-1-1-3:LASTCHNGTIME,18-42"; Related Commands None August 2002 4200-A2-GB20-00...
Page 185: Response Format
DENY /* REPT-OPSTAT-ADSLDN:[tid]:aid_adsl:[ctag][:] */ /* error description */ 4200-A2-GB20-00 REPT-OPSTAT-ADSLDN Command Parameters Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier for ADSL lines. The value can be preceded with AID=, but this is not required.
Page 186: Example
PWR: Transmitted signal power n (0 20 dB) RELCAP: Relative capacity operation. Configured bit rate as a percentage of the current bit rate (0 Value of parameter specified by op_adsl on page 9-7 August 2002 Table 9-3, Parameters). 2176 QOSCLASSF: 100) 4200-A2-GB20-00...
Page 187: Response Format
DENY /* REPT-OPSTAT-ADSLUP:[tid]:aid_adsl:[ctag][:] */ /* error description */ 4200-A2-GB20-00 REPT-OPSTAT-ADSLUP Command Parameters Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier for ADSL lines. The value can be preceded with AID=, but this is not required.
Page 188 RELCAP: Relative capacity operation. Configured bit rate as a percentage of the cuurent bit rate (0 UNKCELLSF: Rolling count of received cells discarded during cell header validation with unrecognized VPI/VCI values Value of parameter specified by op_adsl August 2002 Table 9-5, Parameters). 2176 QOSCLASSF: 100) 4200-A2-GB20-00...
Page 189: Example
Example Report upstream operations parameters for ADSL-1-1-1-3. REPT-OPSTAT-ADSLUP:TAMPA:ADSL-1-1-1-3:42; TAMPA 01-10-24 12:30:43 42 COMPLD /* REPT-OPSTAT-ADSLUP:TAMPA:ADSL-1-1-1-3:42 "ADSL-1-1-1-3:RELCAP,70" "ADSL-1-1-1-3:NMR,3" "ADSL-1-1-1-3:PWR,8" "ADSL-1-1-1-3:ATEN,4" "ADSL-1-1-1-3:CURFBR,36600" Related Commands REPT-OPSTAT-ADSLDN 4200-A2-GB20-00 9. Performance Commands on page 9-5 August 2002...
Page 190: Response Format
Enter in the following format, replacing lower-case parameters with the values given: NTVCL-vpi-vci LTVCL-rack-shelf-slot-circuit-vpi-vci Grouping and ranging are allowed. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 191 COMPLD DENY /* */ errcde aid_vcl [op_vcl] value 4200-A2-GB20-00 REPT-OPSTAT-VCL Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 192: Example
9. Performance Commands Example Report VCL operations parameters for NTVCL-0-32. REPT-OPSTAT-VCL:NTVCL-0-32; TAMPA 01-10-24 12:30:43 42 COMPLD /* REPT-OPSTAT-VCL:TAMPA:NTVCL-0-32*/ "NTVCL-0-32:INCELLS,100000" "NTVCL-0-32:OUTCELLS,20000" "NTVCL-0-32:LPBKINCELLS,100000" "NTVCL-0-32:LPBKOUTCELLS,20000" "NTVCL-0-32:LPBKRTDELAY,100000" "NTVCL-0-32:LPBKMXRTDELAY,20000" "NTVCL-0-32:LPBKMNRTDELAY,100000" "NTVCL-0-32:LPBKTYPE,E2E" Related Commands None 9-12 August 2002 4200-A2-GB20-00...
Page 193 RTRV-ALM-EQPT RTRV-ALM-T1 RTRV-ATTR-ADSL RTRV-ATTR-ALL RTRV-ATTR-EQPT RTRV-ATTR-T1 RTRV-COND-ADSL RTRV-COND-ALL RTRV-COND-EQPT RTRV-COND-T1 4200-A2-GB20-00 on page 10-2 on page 10-5 on page 10-9 on page 10-12 on page 10-15 on page 10-18 on page 10-22 on page 10-25 on page 10-28 on page 10-31...
Page 194 Grouping is allowed. If no value is specified, ALL is assumed. Location of the condition. Valid values are: NEND: Near end FEND: Far end If no value is specified, ALL is assumed. Signal direction. The valid value is RCV (Receive ). August 2002 4200-A2-GB20-00...
Page 195: Response Format
COMPLD DENY /* */ errcde aid_adsl [aid_type] ntfncde 4200-A2-GB20-00 RTRV-ALM-ADSL Response Parameters (1 of 2) Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 196: Example
RTRV-ALM-ADSL Command Parameters), except that ALL is not used. As described for command parameters (see RTRV-ALM-ADSL Command Parameters). As described for command parameters (see RTRV-ALM-ADSL Command Parameters). Description of alarm condition August 2002 Table 10-1, Table 10-1, Table 10-1, 4200-A2-GB20-00...
Page 197 [ntfncde] [serveff] [locn] [dirn] 4200-A2-GB20-00 RTRV-ALM-ALL Command Parameters The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Access identifier. The value is ALL.
Page 198: Response Format
Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes Access identifier associated with the alarm. Valid values are: SHELF-rack-shelf LTA-rack-shelf-slot ADSL-rack-shelf-slot-circuit NTT1-circuit The type of Access Identifier. August 2002 4200-A2-GB20-00...
Page 199 Table 10-4. Parameter ntfncde cond serveff [locn] [dirn] [cond_descr] 4200-A2-GB20-00 RTRV-ALM-ALL Response Parameters (2 of 2) Explanation As described for command parameters (see RTRV-ALM-ALL Command Parameters), except that ALL is not used. Condition. Valid values are: ACTLPBK: Facility placed in loopback.
Page 200: Example
10. Fault Commands Example Retrieve all active, critical, service-affecting the TAMPA NE. RTRV-ALM-ALL:TAMPA:ALL:42::CR,,SA; TAMPA 02-06-27 03:38:43 42 COMPLD /* RTRV-ALM-ALL:TAMPA:ALL:42::CR,,SA */ "EQPT, EQPT:CR,INT,SA,,,NEND,RCV,:Unknown error in the module" Related Commands None 10-8 August 2002 4200-A2-GB20-00...
Page 201 [ctag] [ntfncde] [serveff] 4200-A2-GB20-00 RTRV-ALM-EQPT Command Parameters The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Access identifier for the equipment. Each AID format can be preceded with AID=, but this is not required.
Page 202: Response Format
RTRV-ALM-EQPT Command Parameters), except that ALL is not used. The type of Access Identifier. The value is ADSL. As described for command parameters (see RTRV-ALM-EQPT Command Parameters), except that ALL is not used. August 2002 Table 10-5, Table 10-5, 4200-A2-GB20-00...
Page 203: Example
42 COMPLD /* RTRV-ALM-EQPT:TAMPA:NTB:42::CR,SA ":NTB,EQPTS:CR,INT,SA,,,NEND,RCV,:Unknown error in module" Related Commands None 4200-A2-GB20-00 RTRV-ALM-EQPT Response Parameters (2 of 2) Explanation Equipment condition. Valid values are: EQPT: Equipment failed self-test FANALM-1: Fan alarm for fan 1 FANALM-2: Fan alarm for fan 2...
Page 204 SA: Service affecting NSA: Not service affecting Grouping is allowed. If no value is specified, ALL is assumed. Location of the condition. Valid value is NEND (Near End). Direction of the condition. Valid value is RCV (Receive). August 2002 4200-A2-GB20-00...
Page 205: Response Format
COMPLD DENY /* */ errcde aid_ds1 aid_type ntfncde 4200-A2-GB20-00 RTRV-ALM-T1 Response Parameters (1 of 2) Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 206: Example
As described for command parameters (see Command Parameters), except that ALL is not used. Location of the condition. Valid value is NEND (Near end). Direction of the condition. Valid value is RCV (Receive). Description of alarm condition. August 2002 Table 10-7, RTRV-ALM-T1 4200-A2-GB20-00...
Page 207 [ctag] [ntfncde] [cond_adsl] 4200-A2-GB20-00 RTRV-ATTR-ADSL Command Parameters (1 of 2) The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Access Identifier for all ADSL facilities. The value is ADSL.
Page 208: Response Format
Location of the condition. Valid values are: NEND: Near End FEND: Far End Only applicable to conditions supporting location. If no value is specified, ALL is assumed. Direction of the condition. Valid value is RCV (Receive). ALL is not supported. August 2002 4200-A2-GB20-00...
Page 209: Example
Retrieve major attributes for all ADSL facilities. RTRV-ATTR-ADSL:TAMPA:ADSL:42::MJ; TAMPA 02-04-20 10:30:23 42 COMPLD /* RTRV-ATTR-ADSL:TAMPA:ADSL:42::MJ "ADSL,ADSL:MJ,LOS,NEND,RCV" Related Commands None 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 210 LOFS-L: Loss Of Frame Seconds (Line) LOL: Loss Of Link LOLS-L: Loss Of Link Seconds (Line) ES-L: Errored Seconds (Line) SES-L: Severely Errored Seconds (Line) UAS-L: Unavailable Seconds (Line) INCRATE-F: Increasing Rate (Fast channel). There is no corresponding standing condition clear message. August 2002 4200-A2-GB20-00...
Page 211: Response Format
COMPLD /* RTRV-ATTR-ALL:[tid]:aid_all:[ctag]::[ntfncde], [cond_all] */ "aid,aid_type:ntfncde,cond,[locn],[dirn]" 4200-A2-GB20-00 DECRATE-F: Decreasing Rate (Fast channel). There is no corresponding standing condition clear message. LPRS-L: Loss Of Power Seconds (Line) (far-end only) LOSS-L: Loss of Signal Seconds (Line) (near-end only)
Page 212 As described for command parameters (see RTRV-ATTR-ALL Command Parameters), except that ALL is not used. Location of the condition. Valid values are: NEND: Near End FEND: Far End Signal direction. Valid values are: RCV: Receive TRMT: Transmit August 2002 Table 10-11, Table 10-11, 4200-A2-GB20-00...
Page 213: Example
Example Retrieve current attributes for all major conditions maintained by the TAMPA NE. RTRV-ATTR-ALL:TAMPA:ALL:42::MJ; TAMPA 02-04-20 10:30:23 42 COMPLD /* RTRV-ATTR-ALL:TAMPA:ALL:42::MJ "ADSL,ADSL:MJ,LOS,NEND,RCV" Related Commands None 4200-A2-GB20-00 August 2002 10. Fault Commands 10-21...
Page 214 FANALM-2: Fan alarm for Fan 2 PROGVR: Failed to load or find requested software or configuration RMTDLFAIL: Failed to download software or configuration SWROLLBACK: Software version rolled back Grouping is allowed. If no value is specified, ALL is assumed. August 2002 4200-A2-GB20-00...
Page 215: Response Format
COMPLD DENY /* */ errcde equip_type aid_type ntfncde cond_eqpt 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 216: Example
10. Fault Commands Example Retrieve service-affecting critical alarms for equipment. RTRV-ATTR-EQPT:TAMPA:EQPT:42::MJ; TAMPA 02-04-20 10:30:23 42 COMPLD /* RTRV-ATTR-EQPT:TAMPA:EQPT:42::MJ, "EQPT,EQPT:MJ,HITEMP,NEND,RCV" Related Commands None 10-24 August 2002 4200-A2-GB20-00...
Page 217 [cond_ds1] [locn] [dirn] 4200-A2-GB20-00 The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Access Identifier for all T1 (DS1) facilities. The value is T1.
Page 218: Response Format
The type of Access Identifier. The value is T1. As described for command parameters (see RTRV-ATTR-T1 Command Parameters), except that ALL is not used. As described for command parameters (see RTRV-ATTR-T1 Command Parameters). August 2002 Table 10-15, Table 10-15, Table 10-15, 4200-A2-GB20-00...
Page 219: Example
Retrieve critical attributes for T1 conditions. RTRV-ATTR-T1:TAMPA:T1:42::CR; TAMPA 02-04-20 10:30:23 42 COMPLD /* RTRV-ATTR-T1:TAMPA:T1:42::CR "T1,T1:CR,LOF,NEND,RCV" Related Commands None 4200-A2-GB20-00 Explanation Location of the condition. Valid values are: NEND: Near End FEND: Far End Direction of the condition. Valid values are: RCV: Receive TRMT: Transmit August 2002 10.
Page 220 LORATE: Line rate is below planned rate (Loss of Signal Quality) Facility location. Valid values are: NEND: Near end FEND: Far end If no value is specified, ALL is assumed. Signal direction. Valid value is RCV Receive. August 2002 4200-A2-GB20-00...
Page 221 COMPLD DENY /* */ errcde aid_adsl aid_type 4200-A2-GB20-00 Explanation Target NE identification Year (last two digits), month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 222 Service effect. Valid values are: SA: Service affecting NSA: Not service affecting As described for command parameters (see RTRV-COND-ADSL Command Parameters). As described for command parameters (see RTRV-COND-ADSL Command Parameters). Description of alarm condition. August 2002 Table 10-17, Table 10-17, 4200-A2-GB20-00...
Page 223 [ctag] [cond_all] [locn] 4200-A2-GB20-00 The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Access Identifier for all entities. The value is ALL.
Page 224 RCV: Receive TRMT: Transmit If no value is specified, ALL is assumed. Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed August 2002 4200-A2-GB20-00...
Page 225 [ntfncde] cond [serveff] [locn] [dirn] 4200-A2-GB20-00 Explanation Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes Access Identifier of the entity reporting the alarm. Valid values are: SHELF-rack-shelf...
Page 226 10. Fault Commands Example Retrieve current attributes for all near-end conditions maintained by the TAMPA RTRV-COND-ALL:TAMPA:ALL:42::MJ; TAMPA 02-04-20 10:30:23 42 COMPLD /* RTRV-COND-ALL:TAMPA:ALL:42::,NEND, "ALL,ALL:MN,LOS,NSA,,,NEND,,,Loss of Signal" Related Commands None 10-34 August 2002 4200-A2-GB20-00...
Page 227 [ctag] [cond_eqpt] 4200-A2-GB20-00 The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Access Identifier for a piece of equipment. The value can be preceded with aid=, but this is not required.
Page 228 Parameters), except ALL is not used. The type of Access Identifier. The value is EQPT. Notification code. Valid values are: CR: Critical alarm MJ: Major alarm MN: Minor alarm NA: Not alarmed (reported via REPORT EVENT) August 2002 Table 10-21, 4200-A2-GB20-00...
Page 229 RTRV-COND-EQPT:TAMPA:LT:42::; TAMPA 02-04-20 10:30:23 42 COMPLD /* RTRV-COND-EQPT:TAMPA:LT:42:: "LT:MJ,HITEMP,SA,,,,,,Module temperature exceeded limit" Related Commands None 4200-A2-GB20-00 Explanation As described for command parameters (see RTRV-COND-EQPT Command Parameters). Service effect. Valid values are: – SA: Service affecting – NSA: Not service affecting Description of alarm condition.
Page 230 If no value is specified, ALL is assumed. Grouping is allowed. Location of the condition. Valid value is NEND (Near End). Direction of the signal. Valid value is: RCV: Receive If no value is specified, ALL is assumed. August 2002 4200-A2-GB20-00...
Page 231: Response Format
COMPLD DENY /* */ errcde aid_ds1 aid_type 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 232: Example
Location of the condition. Valid values are: NEND: Near End FEND: Far End Service effect. Valid values are: SA: Service affecting NSA: Not service affecting As described for command parameters (see RTRV-COND-T1 Command Parameters), except ALL is not used. August 2002 Table 10-23, Table 10-23, 4200-A2-GB20-00...
Page 233: Log Commands
Log Commands Overview This chapter contains the following Log commands: INIT-LOG RTRV-LOG 4200-A2-GB20-00 on page 11-2 on page 11-4 August 2002 11-1...
Page 234: Response Format
Names of logs to be initialized. Valid values are: UNKCELL [aid_atmport]: Unknown cell log for the ATM interface (see ED-ATMPORT). SYSTEM: System log containing records of all significant system events (alarms, events, database chages, ftp file transfer status, and security messages). ALL: All logs. August 2002 4200-A2-GB20-00...
Page 235: Example
Initialize the SYSTEM log. INIT-LOG:TAMPA::40::SYSTEM; TAMPA 02-07-24 10:30:43 40 COMPLD /* INIT-LOG:TAMPA::40::SYSTEM */ Related Command RTRV-LOG 4200-A2-GB20-00 INIT-LOG Response Parameters Explanation Source NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 236: Response Format
UNKCELL [aid_atmport]: Unknown cell log for the ATM interface. SYSTEM: System log containing records of all significant system events (alarms, events, database chages, ftp file transfer status, and security messages). SECURITY: Security messages (from the system log). August 2002 4200-A2-GB20-00...
Page 237: Example
RTRV-LOG:TAMPA::40::SECURITY; TAMPA 02-07-24 10:30:43 40 COMPLD /* RTRV-LOG:TAMPA::40::SECURITY */ (dump of log buffer) Related Command INIT-LOG 4200-A2-GB20-00 RTRV-LOG Response Parameters Explanation Source NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 238 11. Log Commands 11-6 August 2002 4200-A2-GB20-00...
Page 239 Overview This chapter contains the following Security commands: DLT-USER-SECU ED-CID-SECU ED-PID ED-USER-SECU ENT-USER-SECU RTRV-CID-SECU RTRV-USER-SECU 4200-A2-GB20-00 on page 12-2 on page 12-4 on page 12-6 on page 12-8 on page 12-10 on page 12-12 on page 12-14 August 2002 12-1...
Page 240: Dlt-User-Secu
User identification name (10 characters maximum). Input is case-sensitive. Grouping is allowed. ALL is not supported. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 241: Example
TAMPA 01-11-24 12:30:43 42 COMPLD /* DLT-USER-SECU:TAMPA:RICHARD:42 */ Related Commands ED-USER-SECU ENT-USER-SECU RTRV-USER-SECU 4200-A2-GB20-00 DLT-USER-SECU Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 242: Ed-Cid-Secu
TMOUT: Timeout interval for a user session, in minutes (0 99). If the user is idle for this long, the session is automatically terminated. The default is 10. A value of 0 disables the feature. August 2002 4200-A2-GB20-00...
Page 243: Example
ED-CID-SECU:TAMPA:CRAFT:42::MXINV=3; TAMPA 01-11-24 12:30:43 42 COMPLD /* ED-CID-SECU:TAMPA:CRAFT:42::MXINV=3 */ Related Command RTRV-CID-SECU 4200-A2-GB20-00 ED-CID-SECU Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 244: Ed-Pid
Correlation tag (6 characters maximum) that links an input command with associated output responses. Old password. New password (8 10 characters). Must include at least one digit, one letter, and one nonalphanumeric character. Input is case-sensitive. The newpid and oldpid values must be different. August 2002 4200-A2-GB20-00...
Page 245: Example
Change Richard’s password from RCC-1210D to NR-12345. ED-PID:TAMPA:RICHARD:42::RCC-1210D,NR-12345; TAMPA 01-11-24 12:30:43 42 COMPLD /* ED-PID:TAMPA:RICHARD:42::RCC-1210D,NR-12345 */ Related Command None 4200-A2-GB20-00 ED-PID Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 246: Ed-User-Secu
NULL: User has no access rights. RTRV: Retrieve. Report and retrieve commands only (no configuring). PROV: Configuring (provisioning). Report, retrieve, and configuring commands allowed. No system administrator tasks including management of the NE. SUPER: Supervisor. All user functions allowed. August 2002 4200-A2-GB20-00...
Page 247: Example
TAMPA 01-11-24 12:30:43 42 COMPLD /* ED-USER-SECU:TAMPA:RICHARD:42::,NR-12345,,RTRV */ Related Commands DLT-USER-SECU ENT-USER-SECU RTRV-USER-SECU 4200-A2-GB20-00 ED-USER-SECU Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 248: Ent-User-Secu
RTRV: Retrieve. Report and retrieve commands only (no configuring). PROV: Configuring (provisioning). Report, retrieve, and configuration commands allowed. No system administrator tasks including management of the NE. SUPER: Supervisor. All user functions allowed. Named parameter block for UID. August 2002 4200-A2-GB20-00...
Page 249: Example
TAMPA 00-11-24 12:30:43 42 COMPLD /* ENT-USER-SECU:TAMPA:RICHARD:42::,NR-12345,,SUPER */ Related Commands ENT-USER-SECU ED-USER-SECU RTRV-USER-SECU 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 250: Rtrv-Cid-Secu
Calling address identifier. Valid values are: CRAFT: Local console interface REMOTE: Remote console interface Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 251: Example
TAMPA 01-11-24 12:30:43 42 COMPLD /* RTRV-CID-SECU:TAMPA:CRAFT:42 */ "CRAFT:SUPER,MXINV=3, TMOUT=10" Related Command ED-CID-SECU 4200-A2-GB20-00 Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 252: Rtrv-User-Secu
User Identification name (10 characters maximum). Input is case-sensitive. ALL is supported. Correlation tag (6 characters) maximum that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 253: Example
42 COMPLD /* RTRV-USER-SECU:TAMPA:RICHARD:42 */ "RICHARD:RTRV:PAGE=0,UAGE=0" Related Commands DLT-USER-SECU ED-USER-SECU ENT-USER-SECU 4200-A2-GB20-00 Explanation Target NE identification Year (two digits), month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 254 12. Security Commands 12-16 August 2002 4200-A2-GB20-00...
Page 255 Synchronization Commands Overview This chapter contains the following Synchronization commands: ED-SYNCN RD-SYNCN RTRV-SYNCN 4200-A2-GB20-00 on page 13-2 on page 13-4 on page 13-6 August 2002 13-1...
Page 256: Response Format
If not specified, the value of this parameter remains unchanged. PRICREF: Primary reference source for synchronizing the clock. Valid values are: – LOOP: Loop timing recovered from network side facility – LOCAL: Local oscillator on NT board August 2002 4200-A2-GB20-00...
Page 257: Example
Configure the NE clock to use the local oscillator as its primary reference source. ED-SYNCN:TAMPA:CLKSRCNT:42:::PRICREF=LOCAL; TAMPA 01-12-20 11:20:34 42 COMPLD /* ED-SYNCN:TAMPA:CLKSRCNT:42:::PRICREF=LOCAL*/ Related Commands RTRV-SYNCN 4200-A2-GB20-00 ED-SYNCN Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 258: Response Format
Identification of the target NE. The default value is null. The NE SID code is the only other valid value. AID of the NE clock. The value is CLKSRCNT. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 259: Example
Retrieve the NE clock source. RD-SYNCN:TAMPA:CLKSRCNT:42; TAMPA 01-12-20 11:20:34 42 COMPLD /* RD-SYNCN:TAMPA:CLKSRCNT:42*/ Related Commands None 4200-A2-GB20-00 RD-SYNCN Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 260: Response Format
Identification of the target NE. The default value is null. The NE SID code is the only other valid value. AID of the NE clock. The value is CLKSRCNT. Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. August 2002 4200-A2-GB20-00...
Page 261: Example
RTRV-SYNCN:TAMPA:CLKSRCNT:42; TAMPA 01-12-20 11:20:34 42 COMPLD /* RTRV-SYNCN:TAMPA:CLKSRCNT:42 */ CLKSRCNT::PRICREF=LOCAL; Related Commands ED-SYNCN 4200-A2-GB20-00 RTRV-SYNCN Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 262 13. Synchronization Commands 13-8 August 2002 4200-A2-GB20-00...
Page 263 LOGOFF RTRV-HDR RTRV-MEM RTRV-META-AID RTRV-META-CMD RTRV-META-SYN RTRV-NE-ALL SET-DAT SET-NE-ALL SET-SID 4200-A2-GB20-00 on page 14-2 on page 14-4 on page 14-6 on page 14-8 on page 14-9 on page 14-11 on page 14-13 on page 14-15 on page 14-17 on page 14-19...
Page 264: Act-User
It is optional with a default of 0. The user identification name (10 characters maximum). Must include at least one letter, one digit, and one nonalphanumeric character. Input is case-sensitive. Grouping is not allowed. August 2002 4200-A2-GB20-00...
Page 265: Example
Activate JANET, whose password is ABC-1234. ACT-USER:TAMPA:JANET:1::ABC-1234; TAMPA 01-10-25 10:35:34 40 COMPLD /* ACT-USER:JANET:1::40 ****** */ Related Command CANC-USER 4200-A2-GB20-00 ACT-USER Response Parameters Explanation Source NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 266: Alw-Msg-All
0. Notification code for some autonomous messages. Grouping is allowed. If no value is specified, ALL is assumed. Valid values are: CR = Critical alarm MJ = Major alarm MN = Minor alarm NA = Not alarmed August 2002 4200-A2-GB20-00...
Page 267 Enable the autonomous messages to be reported in the OS. ALW-MSG-ALL:TAMPA:ALL:40::MN; TAMPA 01-10-24 12:30:43 40 COMPLD /* ALW-MSG-ALL:TAMPA:ALL:40::MN Related Command INH-MSG-ALL 4200-A2-GB20-00 ALW-MSG-ALL Response Parameters Explanation Source NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 268: Canc-User
The NE's SID code is the only other valid value. The user identification name (10 characters maximum). Input is case-sensitive. The correlation tag (6 characters maximum) that links an input command with associated output responses. It is optional with a default of 0. August 2002 4200-A2-GB20-00...
Page 269 40 COMPLD /* CANC-USER:TAMPA:JANET:40 */ Related Command ACT-USER DLT-USER-SECU ED-USER-SECU ENT-USER-SECU RTRV-USER-SECU 4200-A2-GB20-00 CANC-USER Response Parameters Explanation Source NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0...
Page 270: Cpy-File
NE are applied directly to the active configuration. User name (if needed) to log in to the server. If no value is specified, null is assumed. Password (if needed) to log in to the server. If no value is specified, null is assumed. August 2002 4200-A2-GB20-00...
Page 271: Inh-Msg-All
DENY /* INH-MSG-ALL:[tid]:[aidall]:[ctag]::[ntfcncde] */ errcde 4200-A2-GB20-00 INH-MSG-ALL Command Format The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. Access Identifier for all entities. The value is ALL.
Page 272 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes on page 14-4 August 2002 4200-A2-GB20-00...
Page 273: Init-Sys
/* INIT-SYS:[tid]:aid_proc:[ctag]::init_mode */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 The identification of the target NE. TID is optional and has a factory default value of null. The NE's SID code is the only other valid value. Identifier of the processor to be initialized. The value can be preceded with AID= (not required).Grouping and ranging are not allowed.
Page 274 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes August 2002 4200-A2-GB20-00...
Page 275: Logoff
DENY /* LOGOFF:[tid]::[ctag] */ errcde 4200-A2-GB20-00 The identification of the target NE. TID is optional and has a factory default value of null. The NE's SID code is the only other valid value. The correlation tag (6 characters maximum) that links an input command with associated output responses.
Page 276 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes on page 14-2 August 2002 4200-A2-GB20-00...
Page 277: Rtrv-Hdr
DENY /* RTRV-HDR:[tid]::[ctag] */ errcde 4200-A2-GB20-00 The identification of the target NE. TID is optional and has a factory default value of null. The NE's SID code is the only other valid value. The correlation tag that correlates an input command with its associated output response(s).
Page 278 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes August 2002 4200-A2-GB20-00...
Page 279: Rtrv-Mem
/* RTRV-MEM:[tid]:aid_com:[ctag] */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access Identifier for all common equipment. The value can be preceded with AID=, but this is not required.
Page 280 Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes Name of a software module August 2002 4200-A2-GB20-00...
Page 281: Rtrv-Meta-Aid
DENY /* RTRV-META-AID:[tid]:[aid]:[ctag]; */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. The AID value. Valid values are: – NULL: Retrieve aids of all commands –...
Page 282 14. System Commands Example Retrieve the AID for the RTRV-IPPORT command. RTRV-META-AID:TAMPA:IPPORT:40; TAMPA 02-07-24 12:30:43 40 COMPLD IPPORT:ATM-{1,2} IPPORT:ETH-{1}, Related Commands None 14-20 August 2002 4200-A2-GB20-00...
Page 283: Rtrv-Meta-Cmd
DENY /* RTRV-META-CMD:[tid]:[cmd]:[ctag]; */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. The command value. Valid values are: – NULL: Retrieve all commands –...
Page 284 14. System Commands Example Retrieve the RTRV-IPPORT command. RTRV-META-CMD:TAMPA:RTRV-IPPORT:40; TAMPA 02-07-24 12:30:43 40 COMPLD RTRV-IPPORT Related Commands None 14-22 August 2002 4200-A2-GB20-00...
Page 285: Rtrv-Meta-Syn
DENY /* RTRV-META-SYN:[tid]:[cmd]:[ctag]; */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. The command value. Valid values are: – NULL: Retrieve syantax of all commands –...
Page 286 14. System Commands Example Retrieve the syntax for the RTRV-IPPORT command. RTRV-META-SYN:TAMPA:RTRV-IPPORT:40; TAMPA 02-07-24 12:30:43 40 COMPLD "RTRV-IPPORT:RTRV-IPPORT:[tid]:aid_ipport;[ctag}::[skipped]: [skipped]:[pstf]" Related Commands None 14-24 August 2002 4200-A2-GB20-00...
Page 287: Rtrv-Ne-All
/* RTRV-NE-ALL:[tid]:[aid_com]:[ctag][:] */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access Identifier for all common equipment. The value can be preceded with AID=, but this is not required.
Page 288 TZOFFSET: Offset of local time zone from GMT/UTC, in minutes (-780 780). Used by the system if SNTP is enabled. MEMDNLD: Whether external download of a system persistent database is enabled. Value is ENABLED (download allowed). August 2002 Table 14-21, RTRV-NE-ALL SET-DAT command 4200-A2-GB20-00...
Page 289 Table 14-22. RTRV-NE-ALL Response Parameters (2 of 3) Parameter ne_nblk (continued) 4200-A2-GB20-00 Explanation SNTPIPADDR: Simple Network Timing Protocol Server IP Address. Specifies the IP address of specific SNTP server to poll for time and synchronization. If a server address is specified and SNTPMODE is UNI, SNTP will operate in Unicast mode.
Page 290 TSTTMOUT: Test timeout. Specifies the amount of time a test will be allowed to run before automatic termination (0 99 minutes, where 0 disables automatic timeout). If no value is specified, this parameter remains the same. on page 14-31 August 2002 4200-A2-GB20-00...
Page 291: Set-Dat
DENY /* SET-DAT:[tid]::[ctag]::date,time */; errcde 4200-A2-GB20-00 The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. The correlation tag that correlates an input command with its associated output response(s).
Page 292 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes August 2002 4200-A2-GB20-00...
Page 293: Set-Ne-All
[tid] [aid_com] [ctag] ne_nblk 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access Identifier for all common equipment. The value can be preceded with AID=, but this is not required. The value is COM.
Page 294 – DISABLED: Spectrum management guidelines are not enforced on the NE. TSTTMOUT: Test timeout. Specifies the amount of time a test will be allowed to run before automatic termination (0 99 minutes, where 0 disables automatic timeout) August 2002 4200-A2-GB20-00...
Page 295 Table 14-26. SET-NE-ALL Response Parameters Parameter yy-mm-dd hh:mm:ss COMPLD DENY /* */ errcde 4200-A2-GB20-00 Explanation Source NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 296 14. System Commands Example Retrieve the common configuration parameters associated with the TAMPA NE. SET-NE-ALL:TAMPA:COM:40:::BOOTPVPI=1023,BOOTPVCI=15, MEMALM=CLEAR,SNTP=DISABLED; TAMPA 02-06-24 12:30:43 40 COMPLD /* SET-NE-ALL:TAMPA:COM:40 :::BOOTPVPI=1023,BOOTPVCI=15, MEMALM=CLEAR,SNTP=DISABLED*/ Related Command RTRV-NE-ALL 14-34 on page 14-25 August 2002 4200-A2-GB20-00...
Page 297: Set-Sid
DENY /* SET-SID:[tid]::[ctag]::sid */; errcde 4200-A2-GB20-00 The identification of the target NE. TID is optional and has a default value of null. The NE's SID code is the only other valid value. The correlation tag that correlates an input command with its associated output response(s).
Page 298 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes August 2002 4200-A2-GB20-00...
Page 299: Test Commands
Test Commands Overview This chapter contains the following Test commands: OPR-LPBK-T1 OPR-LPBK-VCL RLS-LPBK-T1 RLS-LPBK-VCL STA-LAMPTST STP-LAMPTST 4200-A2-GB20-00 on page 15-2 on page 15-4 on page 15-7 on page 15-9 on page 15-11 on page 15-13 August 2002 15-1...
Page 300 Correlation tag (6 characters maximum) that links an input command with associated output responses. The default is 0. Type of loopback. Valid values are: LINE: Loopback facility at the physical line level toward the facility (default) PAYLOAD: Loopback facility data (payload) toward the facility August 2002 4200-A2-GB20-00...
Page 301 Place NTT1 circuit 1 in payload loopback mode. OPR-LPBK-T1:TAMPA:NTT1-1:40::,,,PAYLOAD; TAMPA 01-11-24 12:30:43 40 COMPLD /* OPR-LPBK-T1:TAMPA:NTT1-1:40::,,,PAYLOAD */ Related Command RLS-LPBK-T1 4200-A2-GB20-00 OPR-LPBK-T1 Response Parameters Explanation Source NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag;...
Page 302 E2E: End-to-End loopback. Identifies an OAM loopback test on a VCL or VCC termination point using an end-to-end OAM cell. SEG: Segment loopback. Identifies an OAM loopback test on a VCL or VCC termination point using a segment OAM cell (default). August 2002 4200-A2-GB20-00...
Page 303 Table 15-4. Parameter yy-mm-dd hh:mm:ss COMPLD DENY /* */ errcde 4200-A2-GB20-00 OPR-LPBK-VCL Response Parameters Explanation Target NE identification Year, month, and day Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments –...
Page 304 Place rack 2, shelf 3, slot 5, circuit 1, virtual path LTVCL-7, virtual channel 99 in loopback mode, with network VC cells looped back to the network at the LT. OPR-LPBK-VCL:TAMPA:LTVCL-2-3-5-1-LTVCL-7-99:40::FEND,NEND; TAMPA 01-10-24 12:30:43 42 COMPLD OPR-LPBK-VCL:TAMPA:LTVCL-2-3-5-1-LTVCL-7-99:40::FEND,NEND */ Related Commands RLS-LPBK-VCL 15-6 on page 15-9 August 2002 4200-A2-GB20-00...
Page 305 DENY /* RLS-LPBK-T1:[tid]:aid_ds1:[ctag][:] */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 on page 15-2) and inband loopbacks (set with DS1 inband RLS-LPBK-T1 Command Parameters Identification of the target NE. The default value is null. The NE SID code is the only other valid value.
Page 306 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes on page 15-2 August 2002 4200-A2-GB20-00...
Page 307 DENY /* RLS-LPBK-VCL:[tid]:aid_vcl:[ctag][:] */ aid:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 RLS-LPBK-VCL Command Parameters Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Access identifier for the ATM virtual channel. The value can be preceded with AID=, but this is not required.
Page 308 Hour, minute, and second Message generated in response to an input command If provided, ctag; otherwise 0 Completed Input command is denied Enclosed are human readable comments – unspecified format Error code (see Appendix A, Error Codes on page 15-4 August 2002 4200-A2-GB20-00...
Page 309 DENY /* STA-LAMPTST:[tid]:aid_eqpt:[ctag][:] */ aid_eqpt:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 STA-LAMPTST Command Parameters Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Equipment access identifier. The value can be preceded with AID=, but this is not required.
Page 310 Equipment access identifier. The value can be preceded with AID=, but this is not required. Grouping and ranging are allowed. Enter in the following format, replacing lower-case parameters with the values given: COM: Common equipment system identifier. Grouping and ranging are not allowed. on page 15-13 August 2002 4200-A2-GB20-00...
Page 311 /* STP-LAMPTST:[tid]:aid_eqpt:[ctag][:] */ aid_eqpt:ERRCDE=errcde /* error description */ 4200-A2-GB20-00 Identification of the target NE. The default value is null. The NE SID code is the only other valid value. Equipment access identifier. The value can be preceded with AID=, but this is not required.
Page 312 Equipment access identifier. The value can be preceded with AID=, but this is not required. Grouping and ranging are allowed. Enter in the following format, replacing lower-case parameters with the values given: COM: Common equipment system identifier. Grouping and ranging are not allowed. on page 15-11 August 2002 4200-A2-GB20-00...
Page 313: Error Codes
IEAE IENE IPEX IPMS IPNC IPNV SARB SDNA SDNC SNVS 4200-A2-GB20-00 Type Description Not equipped with duplex switching Wrong equipment type Command not consistent Data not consistent Data not valid Entity already exists Entity does not exist Extra input parameter...
Page 314 A. Error Codes Table A-1. Error Code Descriptions (2 of 2) Error Code SROF SSRE SSTP Type Description Requested operation failed System resources exceeded Command execution stopped August 2002 4200-A2-GB20-00...
Page 315 LOGOFF Commands OPR Commands RD Commands REPT Commands RTRV Commands SET Commands STA Commands STP Commands 4200-A2-GB20-00 on page B-2 on page B-2 on page B-2 on page B-2 on page B-3 on page B-3 on page B-4 on page B-5...
Page 316 14-6 in Chapter 14, System Commands CPY Commands See . . . CPY-FILE on page 14-8 in Chapter 14, System Commands August 2002 on page 3-2 in Chapter 3, ADSL on page 3-4 in Chapter 3, ADSL 4200-A2-GB20-00...
Page 317 Table B-6. Command ED-ADSL ED-ATMPORT ED-CID-SECU ED-CRS-VC ED-EQPT ED-IPPORT ED-PID ED-PROFILE-ADSLDN 4200-A2-GB20-00 DLT Commands See . . . DLT-ATMARPENT on page 8-2 in Chapter 8, IP Access Commands DLT-CRS-VC on page 6-2 in Chapter 6, Cross Connect Commands DLT-PROFILE-ADSL Facility Commands...
Page 318 3-19 in Chapter 3, ADSL on page 3-21 in Chapter 3, on page 3-16 in Chapter 3, on page 3-24 in Chapter 3, ADSL on page 3-26 in Chapter 3, on page 5-8 in Chapter 5, ATM 4200-A2-GB20-00...
Page 319 LOGOFF OPR Commands Operate (OPR) commands operate or activate a function. Table B-11. OPR Commands Command OPR-LPBK-T1 OPR-LPBK-VCL 4200-A2-GB20-00 INH Commands See . . . INH-MSG-ALL on page 14-9 in Chapter 14, System Commands INIT Commands See . . .
Page 320 9-7 in Chapter 9, Performance Commands on page 8-14 in Chapter 8, IP REPT-OPSTAT-IPPORT Access Commands REPT-OPSTAT-T1 on page 4-10 in Chapter 4, DS1 Facility Commands REPT-OPSTAT-VCL on page 9-10 in Chapter 9, Performance Commands August 2002 4200-A2-GB20-00...
Page 321 RTRV-ATTR-EQPT RTRV-ATTR-T1 RTRV-ATUR RTRV-CID-SECU RTRV-COND-ADSL RTRV-COND-ALL RTRV-COND-EQPT RTRV-COND-T1 RTRV-CRS-VC RTRV-EQPT 4200-A2-GB20-00 B. Command Cross Reference See . . . RTRV-ADSL on page 3-32 in Chapter 3, ADSL Facility Commands RTRV-ALM-ALL on page 10-5 in Chapter 10, Fault Commands RTRV-ALM-ADSL on page 10-2 in Chapter 10, Fault...
Page 322 RTRV-PROFILE-ATMACC on page 5-16 in Chapter 5, ATM Commands RTRV-PROFILE-TRAFDSC on page 5-19 in Chapter 5, ATM Commands RTRV-SYNCN on page 13-6 in Chapter 13, Synchronization Commands RTRV-T1 on page 4-15 in Chapter 4, DS1 Facility Commands August 2002 4200-A2-GB20-00...
Page 323: Set Commands
STA-LAMPTST STP Commands Stop (STP) commands stop a test. Table B-17. STP Commands Command STP-LAMPTST 4200-A2-GB20-00 B. Command Cross Reference See . . . on page 12-14 in Chapter 12, Security RTRV-USER-SECU Commands on page 5-21 in Chapter 5, ATM Commands RTRV-VCL See .
Page 324 B. Command Cross Reference B-10 August 2002 4200-A2-GB20-00...
Page 325: Snmp Overview
The Simple Network Management Protocol (SNMP) is an application-level protocol used in network management to gather information from network devices. Each GranDSLAM 4200 runs an SNMP agent that collects data. The network management station can exercise all the management functions remotely from the Network Operations Center (NOC).
Page 326: Snmp Traps
The configuration has changed so that the Set(2) previously valid CAC contracts can no longer be guaranteed in the egress direction. Traps, lists the traps supported by the GranDSLAM 4200. Variable Binding ifIndex (RFC 2863) ifAdminStatus (RFC 2863) ifOperStatus (RFC 2863)
Page 327 Errored Second 15-minute interval threshold reached. adslAtucRateChangeTrap The ATU-C’s transmit rate has changed (RADSL mode only). adslAtucPerfLolsThresh Trap Loss of Link 15-minute interval threshold reached. adslAtucInitFailureTrap Atuc initialization failed. 4200-A2-GB20-00 Variable Binding atmVcCrossConnectIndex atmVcCrossConnectLowIfIndex atmVcCrossConnectLow Vpi atmVcCrossConnectLow Vci atmVcCrossConnectHighIfIndex atmVcCrossConnectHigh Vpi atmVcCrossConnectHigh Vci mpeDevFileXferStatus...
Page 328 Communicates the results of an auto firmware download when one takes place. Variable Binding ifIndex adslAtucPerfCurr15MinSesL ifIndex adslAtucPerfCurr15MinUasL ifIndex adslAtucPerfCurr15MinLofs adslAtucThresh15MinLofs ifIndex adslAturPerfCurr15MinLoss adslAturThresh15MinLoss ifIndex adslAturPerfCurr15MinLprs adslAturThresh15MinLprs ifIndex adslAturPerfCurr15MinESs adslAturThresh15MinESs ifIndex adslAturChanCurrTxRate adslAturChanPrevTxRate entPhysicalIndex entPhysicalIndex entPhysicalIndex mpeDevFileXferStatus mpeDevFileXferErrorStatus mpeDevFileXferFileType mpeDevFileXferFileName devAutoFwStatus August 2002 4200-A2-GB20-00...
Page 329 Internet Request for Comments (RFC) documents. The following sections provide brief descriptions about supported MIBs. Complete, up-to-date details about the content of all DSL MIBs are available on the Paradyne Web site at www.paradyne.com. Select Technical Support MIBs.
Page 330 — DMT Fast: (IANAifType=125) or DMT Interleave: (IANAifType=124) IP Group – Supported . ICMP Group – Supported. TCP Group – Supported. UDP Group – Supported. EGP Group – Not supported. Transmission Group – Not supported. SNMP Group – Supported. August 2002 4200-A2-GB20-00...
Page 331: Mib Ii (Rfc 1213) System Group
(snmp24), snmpOutGetResponses (snmp28), snmpOutTraps (snmp29), and snmpEnableAuthenTraps (snmp30). MIB II (RFC 1213) System Group System Group objects are fully supported by the GranDSLAM 4200, as shown in Table C-2, System Group Table C-2. System Group Objects (1 of 2)
Page 332 The evolution of the Interfaces Group of MIB II (RFC 2863 converted to SNMP v1) consists of an object indicating the number of interfaces supported by the GranDSLAM 4200 and an interface table containing an entry for each interface. There will be interface table entries for an uplink interface, each of the ATM cell...
Page 333 ATM1 24 interface: 32 2176 kbps ATM90 interface: 0 ATM91 interface: 0 BUS1: 512k RFC1483 interface: 0 For GranDSLAM 4200 ATM interfaces, this object should contain an octet string of zero length. August 2002 C. Traps and MIBs Assignments. Assignments.
Page 334 AAL5 CPCS PDUs passed to a higher layer. RFC1483 interface: 0 DSL1 24 interface: Number of octets received for discard ATM1 24 interface: 0 ATM90 interface: 0 ATM91 interface: 0 AAL5 interface: Number of AAL5 CPCS PDUs discarded. RFC1483 interface: 0 August 2002 4200-A2-GB20-00...
Page 335 (ifEntry 19) ifOutErrors (ifEntry 20) ifOutQLen (ifEntry 20) ifOutErrors (ifEntry 20) 4200-A2-GB20-00 Setting/Contents DSL1 24 interface: 0 ATM1 24 interface: The number of cells dropped due to uncorrectable HEC errors. ATM90 interface: 0 ATM91 interface: 0 AAL5 interface: Number of errored AAL5 CPCS PDUs received.
Page 336: Mib Ii (Rfc 2863) Extension To The Interface Table
MIB II (RFC 2863) Interface Stack Group For GranDSLAM 4200, the interface stack group is used to show the relationship between multiple logical and physical interfaces. The ifStackTable entries for GranDSLAM 4200 are shown in Entries.
Page 337: Mib Ii (Rfc 2863) Interface Test Table
MIB II (RFC 2863) Interface Test Table For GranDSLAM 4200, the Interface Test Table is supported for interface-related diagnostic tests such as loopback. MIB II (RFC 2863) ifTestEntry Table This table contains one entry per interface and defines objects that allow a network manager to instruct an agent to test an interface.
Page 338 ATM91 interface: 8 Read-only. Value is zero. Read-only. Value is 16. Read-only. Valid values are: ATM1 24 interface: The IP address assigned for the purpose of persistent management of the endpoint. ATM90 interface: 0.0.0.0 ATM91 interface: 0.0.0.0 August 2002 4200-A2-GB20-00...
Page 339: Atm Interface Traffic Descriptor Group (Rfc 2515)
(atmTrafficDescrParamEntry 10). The only valid values for this object are cbr(2) (Constant Bit Rate), rtVbr(3) (Real-Time Variable Bit Rate), nrtVbr(4) (NonReal-Time Variable Bit Rate), and ubr(6) (Unspecified Bit Rate). 4200-A2-GB20-00 Setting/Contents Read-only. Valid values are: ATM1 24 interface: Corresponding the value of atmfPortMyIfName through ILMI interaction with the neighbor system.
Page 340: Atm Vcl Configuration Group (Rfc 2515)
The only valid values are: aal5(3): AAL5 unknown(5): The AAL type cannot be determined. Not supported. Not supported. Not supported. August 2002 Table C-7, VCL Configuration 4200-A2-GB20-00...
Page 341: Virtual Channel Cross Connect Group (Rfc 2515)
Used to create a new cross-connection us (atmVcCrossConnectEntry row for the cross-connecting VCLs created using the atmVclTable or to change or delete an existing cross-connection. 4200-A2-GB20-00 Objects). Setting/Contents The only valid values are: up(1) down(2) unknown(3): Not supported. The only valid values are:...
Page 342 Count of OAM cells on this interface for the previous 15-minute interval. August 2002 Objects. Setting/Contents Only disable is supported. The only valid value is zero. Always uni(1). Integer. Zero-length string. Zero-length string. Zero-length string. Always zero. Always zero. 4200-A2-GB20-00...
Page 343 Paradyne Extensions to the ATM Interface Configuration Table, ATM Forum M4 The following MIBs listed in Configuration Table, ATM Forum M4. Table C-10. Paradyne Extensions to ATM Interface Configuration Table Table pdnAmIfConfExtEntry (pdn_AtmExt.mib) pdnAtmTrafficDescrParamExtEntry (pdn_AtmExt.mib) pdnAtmfM4TcProtoCurrExtEntry (pdn_AtmM4Ext.mib) pdnAtmfM4TcProtoHistExtEntry (pdn_AtmM4Ext.mib) pdnAtmVclCurrEntry (pdn_AtmStats.mib) pdnAtmVclHistEntry (pdn_AtmStats.mib)
Page 344: Entity Physical Group (Rfc 2737)
Read only. Valid values are: Stack: sysDescr in the MIB II System Group. Chassis: Company Name; ATM Stackable 4200 DSLAM; Model Description; Unit #. Main card: ATM Stackable 4200; Main Card Model Description; Unit # Uplink module: ATM Stackable 4200; Uplink Module; Unit # Splitter card: ATM Stackable 4200 DSLAM;...
Page 345 A value of zero indicates this physical entity is not contained in any other physical entity. 4200-A2-GB20-00 Setting/Contents Led PLD: ATM Stackable 4200 DSLAM; Led PLD.; Unit # T1/E1 PLD: ATM Stackable 4200 DSLAM; T1/E1 PLD; Unit # Read only. Valid values are: Stack: { Company Enterprise .1.14.18.1.1}atmstk-4200...
Page 346 ReachDSL port: port (10) T1/E1 port: port (10) Console port: port (10) Ethernet Mgmt port: port (10) Temp sensor: sensor (8) Fan: fan (7) Management Plane PLD: other (1) Led PLD: other (1) T1/E1 PLD: other (1) August 2002 4200-A2-GB20-00...
Page 347 7) physical entity. entPhysicalHardwareRe Identifies the hardware revision v(entPhysicalEntry 8) string for the physical entity. 4200-A2-GB20-00 Setting/Contents Read only. Valid values are the following: Stack: -1 Chassis: Position in the stack (1 5) Main card: 1 Uplink module: 2...
Page 348 Temp sensor: zero-length string Fan: zero-length string Management Plane PLD: string containing the currently running software revision level Led PLD: string containing the currently running software revision level T1/E1 PLD: string containing the currently running software revision level August 2002 4200-A2-GB20-00...
Page 349 Management Plane PLD: zero-length string Led PLD: zero-length string T1/E1 PLD: zero-length string Read only. Valid value is Paradyne for all entities except ReachDSL port, which is a string reflecting the DSP revision. Read only. Valid values are the following:...
Page 350 Main card: TRUE Uplink module: TRUE Splitter card: TRUE ReachDSL port: FALSE T1/E1 port: FALSE Console port: FALSE Ethernet Mgmt port: FALSE Temp sensor: FALSE Fan: FALSE Management Plane PLD: FALSE Led PLD: FALSE T1/E1 PLD: FALSE August 2002 4200-A2-GB20-00...
Page 351 4200-A2-GB20-00 Objects. Contents August 2002 C. Traps and MIBs Read only Read only Read only Read/write. SNMP string Read/write. SNMP string Read only Read only Read only...
Page 352 Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only 4200-A2-GB20-00...
Page 353 (7) adslAtucChanPerfCurr15MinReceivedBlks(8) adslAtucChanPerfCurr15MinTransmittedBlks(9) adslAtucChanPerfCurr15MinCorrectedBlks(10) adslAtucChanPerfCurr15MinUnCorrectBlks(11) adslAtucChanPerfCurr1DayTimeElapsed (12) adslAtucChanPerfCurr1DayReceivedBlks (13) adslAtucChanPerfCurr1DayTransmittedBlks (14) adslAtucChanPerfCurr1DayCorrectedBlks(15) 4200-A2-GB20-00 Contents August 2002 C. Traps and MIBs Read only Read only Read only Read only Read only Read only Read only Read only...
Page 354 Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only 4200-A2-GB20-00...
Page 355 4200-A2-GB20-00 Contents August 2002 C. Traps and MIBs Read only Read only Read only Read only Read only Read only Read/write. SNMP Admin string Integer Integer...
Page 356: Adsl Supplement To The Adsl Line Mib
Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Integer Unsigned Unsigned 4200-A2-GB20-00...
Page 357 4200-A2-GB20-00 Table C-14, DS1 MIB Contents Interface index Interface Index Integer Integer Integer Integer Integer Display string Integer Integer Integer Integer Integer Integer...
Page 358 Perf Total Count Perf Total Count Perf Total Count Perf Total Count Interface index Interface index Integer Integer Perf Current Count Perf Current Count Perf Current Count Perf Current Count Perf Current Count Perf Current Count Perf Current Count August 2002 4200-A2-GB20-00...
Page 359 4200-A2-GB20-00 Contents Perf Current Count Perf Current Count Perf Current Count Interface index Perf Interval Count Perf Interval Count Perf Interval Count Perf Interval Count Perf Interval Count Perf Interval Count...
Page 360: Paradyne Ds1 Extension Mib
Paradyne DSLAM System MIB (pdn_dslam.mib) Support for the pdn_dslam.mib is provided to enable an NMS to access certain objects specific to a DSLAM. The objects listed in System MIB Table C-15. Paradyne DSLAM System MIB Objects (1 of 3) Object Description loginUserId...
Page 361 Table C-15. Paradyne DSLAM System MIB Objects (2 of 3) Object Description loginUserPriv Contains the access privileges of the user. loginStatus Indicates whether the user is still accessing the device. loginFailureAccessApp Describes the access application used by the end user to access the device.
Page 362 C. Traps and MIBs Table C-15. Paradyne DSLAM System MIB Objects (3 of 3) Object Description sysDevConfigUserAccount An index of the Device Configuration Index User Accounts table. sysDevConfigUserAccount The login ID of the user account. UserId sysDevConfigUserAccount The password of the user account.
Page 363 Paradyne Syslog MIB (pdn_syslog.mib) The Paradyne Syslog MIB (pdn_syslog.mib) defines a set of objects for managing syslog messages. The objects listed in are supported. Table C-17. Paradyne Syslog MIB Objects (1 of 2) Object Description pdnSyslogStatus Enables or disables syslog event generation.
Page 364 C. Traps and MIBs Table C-17. Paradyne Syslog MIB Objects (2 of 2) Object Description pdnSyslogSeverityThreshold Specifies the minimum severity level that syslog messages can be sent. pdnSyslogRemoteDaemon Enables or disables syslog messages going to a remote daemon. pdnSyslogNumber A sequentially increasing index of syslog messages starting at 1.
Page 365 Paradyne Control MIB (mpe_Control.mib) The Paradyne Control MIB (mpe_Control.mib) stores the results of the Power-On Self Test. This MIB begins with mpe, indicating that it is indexed on the entPhysicalIndex and depends upon the Entity MIB to be implemented. The objects supported are listed in Table C-19.
Page 366 Paradyne Control MIB (pdn_Control.mib) The Paradyne Control MIB (pdn_Control.mib) stores the results of the Power-On Self Test. This MIB begins with pdn, indicating that it can be used if the Entity MIB is not implemented. The objects supported are listed in Control MIB Table C-20.
Page 367 Paradyne Configuration MIB (mpe_Config.mib) The Paradyne Configuration MIB (mpe_Config.mib) allows the choice of the network timing reference source for the GranDSLAM 4200 (mpeDevConfigClockSrcEntry table). Table C-21. Paradyne Configuration MIB Objects Object Description mpeDevCfgClkWhichSrc Defines the master clock source. mpeDevCfgClkSource Selects the source for the master clock for the device.
Page 368 C. Traps and MIBs Paradyne Time MIB (pdn_Time.mib) The Paradyne Time MIB (pdn_Time.mib) controls the date and time on the unit. Table C-23. Paradyne Time MIB Objects Object Description devDateAndTime Displays the unit’s date and time and allows the NMS to change them to the appropriate time zone.
Page 369: Paradyne Reachdsl Mib (Pdn_Reachdsl.mib)
Paradyne ReachDSL MIB (pdn_reachDSL.mib) This Paradyne enterprise MIB provides objects for configuration of objects specific to ReachDSL v3 devices such as the Hotwire 6390 ReachDSL Modem. The following objects are supported. Table C-25. Paradyne ReachDSL MIB Objects Table ReachDSLSpectrumMgmtConfEntry ReachDSLSpectrumMgmtLineInfoEntry...
Page 370: Paradyne Ds1 Config Mib (Rfc)
Paradyne DS1 Extension MIB The objects supported for the Paradyne extension to the DS1 MIB are listed in Table C-27, Paradyne Extension to DS1 Config MIB Table C-27. Paradyne Extension to DS1 Config MIB Objects Table Objects...
Page 371: Hotwire 6390 Reachdsl Modem Overview
Hotwire 6390 ReachDSL Modem Overview The Hotwire 6390 ReachDSL Modem is a component in the ReachDSL System and interoperates with the GranDSLAM 4200 ATM Stackable DSLAM. This system provides high-speed Internet or corporate LAN access over traditional twisted-pair copper telephone wiring.
Page 372: Downloading Hotwire 6390 Reachdsl Modem Software
Before attempting to download, you must first build a management Permanent Virtual Circuit (PVC) through the GranDSLAM 4200 to VPI 0, VCI 33 on the port connected to the Hotwire 6390 ReachDSL modem to be downloaded (see...
Page 373 Procedure To create a PVC from the GrandDSLAM 4200 port to the Hotwire 6390 ReachDSL modem: 1. Log into the GranDSLAM 4200 unit using the For example, type: ACT-USER:TAMPA:SUPERUSER:100::******** 2. Create a VCL to the upstream network (on the NT) with VPI=1 and VCI=33...
Page 374 3. Use the PC (where the batch file resides) and go to the DOS prompt C:\>. Type epdown.bat and press Enter to execute the batch file you just created to download software to the Hotwire 6390 ReachDSL Modem. August 2002 Step 4200-A2-GB20-00...
Page 375 ADSL lines, 9-5 ADSLDNALM edit profile, 3-16 ADSLUP edit profile, 3-19 report operational parameters of ADSL lines, 9-7 ADSLUPALM edit profile, 3-21 retrieve, 14-19 4200-A2-GB20-00 alarm ADSL, 10-2 all NE, 10-5 DS1, 10-12 equipment, 10-9 T1, 10-12 allow autonomous messages, 14-4...
Page 376 6-1 login, 2-8 password, 2-5, 2-8, 12-10 user, 2-5, 12-10 default uplink, 6-1 delete ADSL profile, 3-6 ADSLALM profile, 3-8 ATMARPENT, 8-2 CRS-VC, 6-2 IPPORT, 8-4 TRAFDSC profile, 5-2 VCL, 5-4 DHCP mode, 2-6 diagnostics, A-1 August 2002 4200-A2-GB20-00...
Page 377 PROFILE-ADSLDNALM, 3-16 PROFILE-ADSLUP, 3-19 PROFILE-ADSLUPALM, 3-21 SYNCN, 13-2 T1, 4-2 USER-SECU, 12-8 ED commands, B-3 ED-CID-SECU, 12-4 ED-CRS-VC, 6-4 4200-A2-GB20-00 edit ADSL profile, 3-10 ADSLDN profile, 3-14 ADSLDNALM profile, 3-16 ADSLUP profile, 3-19 ADSLUPALM profile, 3-21 ATMPORT, 5-6 CRS-VC, 6-4...
Page 378 7-5 retrieve, 7-6 retrieve inventory data, 7-9 error codes, A-1 Ethernet, 2-7 features, 1-1, 1-3 file copy, 14-8 GranDSLAM 4200 overview, 1-1 header retrieve, 14-15 history of commands, 2-5 inband management, 2-6, 6-1 turn-up procedure, 2-7 INH commands, B-5...
Page 379 OPR commands, B-5 OPR-LPBK T1, 15-2 VCL, 15-4 option field completion, 2-4 out-of-band management, 2-6 turn-up procedure, 2-7 output message, 2-3 Paradyne DS1 Config MIB RFC 2495, C-46 passsword edit, 12-6 password default, 2-5, 2-8 password default, 2-5, 12-10 performance monitoring...
Page 380 LOG, 11-4 PM-ADSL, 3-37 PM-T1, 4-12 PROFILE-ADSL, 3-40 PROFILE-ADSLALM, 3-42 PROFILE-ADSLDN, 3-44 PROFILE-ADSLDNALM, 3-47 PROFILE-ADSLUP, 3-50 PROFILE-ADSLUPALM, 3-53 PROFILE-ATMCC, 5-16 PROFILE-TRAFDSC, 5-19 SYNCN, 13-6 T1, 4-15 USER-SECU, 12-14 VCL, 5-21 RTRV commands, B-7 RTRV-ADSL, 3-32 RTRV-ALM-ADSL, 10-2 August 2002 4200-A2-GB20-00...
Page 381 2-5 configuration, 14-31 date, 14-29 system identifier, 14-35 time, 14-29 SET commands, B-9 SET-DAT, 14-29 4200-A2-GB20-00 SET-NE-ALL, 14-31 SET-SID, 14-35 Simple Network Management Protocol (SNMP), C-1 agent overview, C-1 SNMP traps, C-1 SNTP, 2-7–2-8, 14-26 STA command, B-9...
Page 382 2-5 user accounts access levels, 2-5 IN-8 delete, 5-4 enter, 5-10 loopback, 15-4, 15-9 report operational parameters, 9-10 retrieve, 5-21 virtual channel link ADSL, 5-21 delete, 5-4 enter, 5-10 report operational parameters, 9-10 August 2002 4200-A2-GB20-00...

Paradyne GranDSLAM 4200 User Manual

Table of Contents

15 Test Commands

About this Guide

Using the Command Line Interface

Example

Atm Commands

Security Commands

System Commands

Quick Links

Chapters

Related Manuals for Paradyne GranDSLAM 4200

Summary of Contents for Paradyne GranDSLAM 4200
