Digital Projection M-Vision 930 Series
3D menu continued from previous page
3D types
In most situations you can use the
Auto
format. Otherwise, consider the notes below to help you set up the 3D input manually.
The following 3D formats are supported:
•
Dual-Pipe (LEFT and RIGHT)
The left and right eye images are delivered on two separate HDMI links, which the projector
will interleave for 3D display.
•
Frame Packing
This format will be detected, re-synchronised, frame-multiplied and displayed at 144 Hz with
the left eye / right eye dominance automatically extracted from the video data. You need to
optimize
and
Dark Time
Sync Delay
•
Top and Bottom
Sets the projector to reformat the video frames and map them to the display with the left eye /
right eye dominance automatically extracted from the video data. You need to optimize
and
manually to suit your chosen switching glasses.
Time
Sync Delay
•
Side by Side (Half): interlaced and progressive, 50 and 60Hz
The side-by-side image will be de-interlaced (if appropriate), resized and then sequentially
displayed at 100 or 120 Hz. The left eye / right eye dominance will be automatically extracted
from the video data, however you will need to optimize
to suit your chosen switching glasses.
Dark Time
and
Sync Delay
need to be set only once, to optimize the image for the glasses in
use.
Operating Guide
setting to have the projector automatically detect the
manually to suit your chosen switching glasses.
Dark Time
and
Sync Delay
USING THE PROJECTOR
L
HDMI 1
R
HDMI 2
Dual Pipe
L
R
Frame Packing
Dark
L
R
Top-and-Bottom
manually
L
Side-by-Side (Half)
Notes
R
Rev C February 2015
page 60
