Feature
TPM Device Selection
►Firmware Update Configuration
Me FW Image Re-Flash
8.4.12

SMART Settings Submenu

Feature
SMART Self Test
8.4.13

Super IO Submenu

Feature
Super IO Chip
SIO Clock
Serial Port
Device Settings
Serial Port
Device Settings
Parallel Port
Device Settings
Copyright © 2016 congatec AG
Options Description
dTPM 1.2 Select TPM device:
PTT 'PTT' - Enables PTT and disables dTPM in SkuMgr.
'dTPM 1.2' - Enables dTPM 1.2 and disables PTT in SkuMgr.
Warning: If you enable PTT, dTPM will be disabled and all data saved on it will be lost.
Likewise, if you enable dTPM, PTT will be disabled and all data saved on it will be lost.
Submenu Opens submenu to configure management engine technology parameters.
Disabled Enable or disable Me FW Image Re-Flash function.
Enabled
Options Description
Disabled Run SMART self test on all HDDs during POST.
Enabled
Options Description
W83627
24MHz Super IO base clock.
Disabled Enable or disable serial port (COM).
Enabled
IO=3F8h Displays the currently used settings.
IRQ=4
Disabled Enable or disable serial port (COM).
Enabled
O=2F8h Displays the currently used settings.
IRQ=3
Disabled Enable or disable parallel port (LPT/LPTE).
Enabled
IO=378h Displays the currently used settings.
IRQ=5
