Page 1 BARCO PROJECTION SYSTEMS VISION 701 MULTIMEDIA R9000748 OWNER'S MANUAL Date: Rev. : Art. No. 200697 R5975238A...
Page 2 Due to constant research, the information in this manual is subject to change without notice. Produced by BARCO NV, June 1997. All rights reserved. Trademarks are the rights of their respective owners. Printed in Belgium...
Page 3: Table Of Contents
TABLE OF CONTENTS WARNINGS ......................1-1 SAFETY INSTRUCTIONS ................... 1-1 On safety ....................1-4 On installation ..................... 1-5 On servicing ....................1-6 On cleaning ....................1-6 On repacking ....................1-7 On illumination .................... 1-7 LOCATION AND FUNCTION OF CONTROLS ........... 2-1 Rear panel terminology ................
Page 4 TABLE OF CONTENTS GUIDED ADJUSTMENT MODE ................7-1 Start up of the guided adjustment mode............7-2 Overview flowchart 'Guided Adjustment' procedure........7-3 Selecting Setup Pattern ................7-4 Internal Cross Hatch Pattern ............... 7-5 Picture tuning ....................7-6 Sync Fast/Slow toggle ................. 7-6 Line Doubler (option) ...................
Page 5 Change language ..................9-7 Change projector address ................9-8 Change baudrate ..................9-8 Power up mode ................... 9-9 BARCO logo ..................... 9-10 Memory management ................9-11 Copy a block ..................... 9-11 Deletion of blocks ..................9-12 Deleting block by block ................9-13 Deletion of all blocks .................
Page 6 TABLE OF CONTENTS Orbiting Kit ....................11-4 Soft edge matching kit ................11-4 Contrast modulation kit ................11-4 Appendix A : Battery replacement in the RCU............ A-1 Appendix B : Orbiting ..................B-1 Appendix C : Soft edge matching ................ C-1 Appendix D : Contrast modulation (option) ............
Page 7: Warnings
SAFETY INSTRUCTIONS WARNINGS SAFETY INSTRUCTIONS on safety on installation on servicing on cleaning on repacking on illumination R5975238A BARCOVISION 701 MULTIMEDIA 070497...
Page 8 SAFETY INSTRUCTIONS The lightning flash with an arrowhead within a triangle is intended to tell the user that parts inside this product may cause a risk of electrical shock to persons. The exclamation point within a triangle is intended to tell the user that important operating and/or servicing instructions are in- cluded in the technical documentation for this equipment.
Page 9 SAFETY INSTRUCTIONS 3. Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord. To disconnect the cord, pull it out by the plug. Never pull the cord itself. 4.
Page 10 SAFETY INSTRUCTIONS When installing the projector and screen, care must be taken to avoid exposure to ambient light directly on the screen. Avoid adverse illumination on the screen from direct sunlight or fluorescent lighting fixtures. The use of controlled ambient lighting, such as incandescent spot light or a dimmer, is recommended for proper room illumination.
Page 11: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS LOCATION AND FUNCTION OF CONTROLS Rear Panel Terminology Front Panel Terminology RCU Terminology R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 12: Rear Panel Terminology
LOCATION AND FUNCTION OF CONTROLS REAR PANEL TERMINOLOGY COMM PORT G(S) RS232IN RS232OUT S-VIDEO REMOTE VIDEO (800 peripherals) R- Y Y(S) RS232IN Connection between the BARCOVISION 701 MULTIMEDIA and an IBM PC (or compatible) or MAC (RS422) for remote computer control and data communication.
Page 13: Front Panel Terminology
LOCATION AND FUNCTION OF CONTROLS VIDEO IN (Composite video, 1x BNC connector): allows a video tape recorder, video camera, color receiver/monitor, etc. having video line output to be connected to the projector. S-VIDEO IN: Separated Y/C (luma-chroma) signal inputs and outputs for higher quality playback of Super VHS signals (4-pin S-VIDEO connector).
Page 14: Control Panel Terminology
LOCATION AND FUNCTION OF CONTROLS Control panel terminology a. The local keypad Getting access The local keypad is covered by a door on which the projector logo is screened. ADJ UST EXIT STANDBY ENTER To open this door, push as indicated on next drawing and turn it to the front side of the projector.
Page 15 LOCATION AND FUNCTION OF CONTROLS Local keypad ADJUST EXIT STANDBY ENTER EXIT ENTER STBY PAUSE TEXT SHARPNESS TINT COLOR stand-by BRIGHTNESS pause/park CONTRAST sharpness tint color brightness contrast R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 16 LOCATION AND FUNCTION OF CONTROLS Back light key : when activated, all keys will be lit up and visible in the dark. ADJ. : adjust key, to enter or exit the adjustment mode. Address key (recessed key), to enter the address of the projector (between 0 and 9).
Page 17: Power (Mains) Connection
POWER CONNECTION POWER (MAINS) CONNECTION R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 18: Switching On/Off
POWER CONNECTION Power (mains) cord connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the front of the projector. See installation instructions before connecting to the supply V NOM 120 Volt I MAX 5 AMP...
Page 19: Source Connections
CONNECTIONS SOURCE CONNECTIONS - connecting a Video source - connecting a S-Video source - connecting a RGsB or RGBS analog source - connecting a RG3sB or RGB3S analog source - connecting a (R-Y)Ys(B-Y) or (R-Y)Y(B-Y)S analog source - connecting a (R-Y)Y3s(B-Y) or (R-Y)Y(B-Y)3S analog source PERIPHERAL EQUIPMENT CONNECTION - Connecting a computer, e.g.
Page 20: Signal Input Connection To The Projector
CONNECTIONS Signal input connection to the projector : - Composite Video (*) - S-Video (*) - RGBS or RGsB - RGB3S or RG3sB - (R-Y)Y(B-Y)S or (R-Y)Ys(B-Y) [component input] (**) - (R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) [component input] (**) (*) The line double feature is built in, this feature is available via a software on/off toggle. (**) The line double feature is built in, this feature is available for component video signals on standard frequency via software on/off toggle.
Page 21: Connecting A Composite Video Source
CONNECTIONS Connecting a Composite Video source. Composite video signals from a VCR, OFF air signal decoder, etc.. A line doubler is built in : the default position of this line doubler is ON (active), the video input signal will be displayed as a non interlaced image (= improved image stability). To enable or to disable this line doubler function, enter the adjustment mode and change the position of the ON/OFF toggle switch (see Picture tuning in chapter 'Guided' adjustment mode or 'Random access' adjustment mode).
Page 22: Connecting A S-Video Source
CONNECTIONS - use the control disk to high- light 1. GENERAL ACCESS - press ENTER to select the highlighted source. SHARPNESS TINT COLOR BRIGHTNESS CONTRAST Enter ADJUST Select with then <ENTER>. <EXIT> to return Connecting a S-Video source. Separate Y-luma/C-chroma signals for higher quality playback of Super VHS signals.
Page 23: Connecting A Rgb Analog Source With Composite Sync
CONNECTIONS S-Video input selection a. Press digit button 2 on the RCU or b. with the local keypad : (to gain access to the local keypad, see 'Local keypad' in chapter 'Location and function of controls'.) - Press ADJUST key, the General access menu is displayed on the screen. - Use the control disk to highlight 2.
Page 24 CONNECTIONS COMM PORT G(S) S-VIDEO REMO TE VIDEO RS232 OUT (800 peripherals) RS232 IN R- Y Y(S) ANALOG OUT INPUT AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA RGBS or RGsB input selection a. Press digit button 3 on the RCU or b.
Page 25: Connecting A Rgb Analog Source With Tri-Level Sync
CONNECTIONS Connecting a RGB Analog source with Tri-level sync. RGB analog input terminals with Tri level sync input or with Tri-level sync on green. The projector detects automatically where the sync signal is located. COMM PORT G(S) S-VIDEO (800 peripherals) REMOTE VIDEO RS232 OUT RS232 IN...
Page 26: Connecting A Component Source
CONNECTIONS Connecting a Component source. (R-Y)Y(B-Y) analog input terminals with sync input or with sync on the luminance (Y) input. The projector detects automatically where the sync signal is located. Line doubling is possible for component video input sources on standard line frequency.
Page 27: Connecting A Component Source With Tri-Level Sync
CONNECTIONS - Use the control disk to high- light 5. - Press ENTER to select the GENERAL ACCESS highlighted source. SHARPNESS TINT COLOR BRIGHTNESS CONTRAST Enter ADJUST Select with then <ENTER>. <EXIT> to return Connecting a Component source with Tri-level sync. (R-Y)Y(B-Y) analog input terminals with Tri-level sync input or with Tri-level sync on the luminance input.
Page 28 CONNECTIONS (R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) input selection a. Press digit button 6 on the RCU or b. With the local keypad : (to gain access to the local keypad, see 'Local keypad' in chapter 'Location and function of controls'.) - Press ADJUST key, the General access menu is displayed on the screen. - Use the control disk to high- light 6.
Page 29: Connecting A Computer, E.g. Ibm Pc (Or Compatible), Apple Macintosh To The Rs232 Input Of The Projector
CONNECTIONS Connecting a computer, e.g. IBM PC (or compatible), Apple Macintosh to the RS232 input of the projector. The projector has a RS232 port that allows it to communicate with a computer. Applications: remote control and data communications. a) remote control: - easy adjustment of the projector via IBM PC (or compatible) or MAC connection.
Page 30: Connecting A Rcvds 05 Switcher To The Projector
CONNECTIONS PERIPHERAL EQUIPMENT Connecting a RCVDS 05 switcher to the projector. - Up to 10 inputs (20 inputs when video and S-video) with the RCVDS 05 switcher and up to 90 inputs when 10 RCVDS switchers are linked via the expansion modules. - Serial communication with the projector.
Page 31: Controlling
CONTROLLING CONTROLLING Battery installation in the RCU How to use the RCU Projector address How to display a projector address How to program an address into the RCU Input selection Picture controls The Pause key R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 32 CONTROLLING Battery installation in the RCU. A new battery is delivered inside the plastic bag with the power cord. Before using the RCU, install first the battery. Remove the battery cover on the backside of the remote control by pushing the indicated handle a little to the bottom of the RCU.
Page 33 CONTROLLING The BARCOVISION 701 MULTIMEDIA can be controlled with a. the RCU b. the hardwired RCU (cable not included) c. the local keypad. Controlling the projector with the RCU and the hardwired RCU is the same. How to use the RCU a) Point the front of the RCU towards the reflective screen surface Ceiling IR sensor...
Page 34 CONTROLLING Rear side of projector Front of projector 45° 45° 45° 45° ENTER ENTER FREEZ FREEZ c) RCU used in a hardwired configuration. CO MM PO RT RS23 2IN RS 232O UT S- VIDEO (800 peri pherals) REMOTE G (S ) VIDEO Plug one end of the remote cable in the connector on the bottom of the RCU and the second side in the connector in the rear panel of the BARCOVISION 701 MULTIME-...
Page 35: Projector Address
Every projector requires an individual address between 0 and 16 which is set with hardware DIP switches inside the projector. To change that address, contact a BARCO authorized technician. b. How to control the projector. The projector's address may be set to any value between 0 and 16. When the address is set, the projector can be controlled now with : - the RCU for addresses between 0 and 9.
Page 36: How To Program An Address Into The Rcu
CONTROLLING How to program an address into the RCU? Press the ADDRESS key (recessed key on the RCU) with a pencil and enter the address with the digit buttons. That address can be any digit between 0 and 9. When programming '0', zero address, the RCU will control a projector regardless of the projector's address.
Page 37 CONTROLLING Use the control disk to highlight the desired source number. Push the GENERAL ACCESS control disk up or down to move the cursor up and down, push the con- SHARPNESS TINT trol disk to the left or to the right to COLOR move the cursor to the left and to BRIGHTNESS...
Page 38: Picture Controls
CONTROLLING When a valid source number is selected, the projector will display this source or it will wait on the selected source number until the source becomes available. A mes- sage 'source not available' will be displayed for a short time. WARNING source not available...
Page 39 CONTROLLING GENERAL ACCESS SHARPNESS TINT COLOR BRIGHTNESS CONTRAST Enter ADJUST Select with then <ENTER>. <EXIT> to return When a picture control is selected, a text box with bar scale and the function name of the control appear on the screen. The length of the bar scale indicates the current memorized setting for this source (percentage scale).
Page 40 CONTROLLING Contrast Control A correct 'contrast' setting is impor- tant for good image reproduction. Adjust the contrast to the level you prefer, according to room lighting conditions. A bar scale gives a visual indication on the screen of the current con- trast setting while pressing the + or - buttons (RCU) or pushing the con- trol disk to the left or to the right...
Page 41: The Pause Key
CONTROLLING Tint Control Tint is only active for Video and S- Video. Tint control is effective only when using the NTSC 4.43 or NTSC 3.58 system. A bar scale gives a visual indication on the screen of the current tint setting while pressing the + or - buttons (RCU) or pushing the control disk to the left or to the right (local...
Page 42 CONTROLLING 5-12 R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 43: Start Up Of The Adjustment Mode
START UP OF THE ADJUSTMENT MODE START UP OF THE ADJUSTMENT MODE R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 44: Entering The Adjustment Mode
START UP OF THE ADJUSTMENT MODE Entering the adjustment mode ADJUSTMENT MODE Select a path from below: GUIDED RANDOM ACCESS INSTALLATION SERVICE IRIS source 1 Select with then <ENTER> <EXIT> to return IRIS Installation (only for qualified technician) Service Random Access Adjustment Guided Adjustment...
Page 45: Adjustment Mode
START UP OF THE ADJUSTMENT MODE Adjustment mode All picture geometry and convergence adjustments are made while in the 'Adjustment mode'. Two possible ways to enter the adjustment mode : a) Using the RCU. Press the ADJUST key. The projector displays the path selection menu. b) Using the local keypad.
Page 46 START UP OF THE ADJUSTMENT MODE Note : to adjust the Analog picture control while in the 'Adjustment mode', press the ADJUST key. The next General Access menu will be displayed. Push the control disk up or down to select the analog con- GENERAL ACCESS trol to be adjusted and press the ENTER key to confirm.
Page 47 (Password protection is only available when the password DIP switch on the controller module is in the ON position. Contact a BARCO authorized technician when no password is requested during the adjustment procedure and password protec- tion is desired.)
Page 48 START UP OF THE ADJUSTMENT MODE b) adjusting the projector with the local keypad. When the 'compose password' menu is displayed, select with con- COMPOSE trol disk the first digit of your pass- PASSWORD word and press ENTER. Continue by selecting the second digit with 7 8 9 the control disk and press ENTER.
Page 49: Guided Adjustment Mode
GUIDED ADJUSTMENT MODE GUIDED ADJUSTMENT MODE R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 50: Start Up Of The Guided Adjustment Mode
GUIDED ADJUSTMENT MODE Start up of the guided adjustment mode. Push the control disk up or down to highlight GUIDED on the 'Adjustment mode' menu ADJUSTMENT MODE and then press ENTER. Select a path from below: GUIDED The Guided Adjustment mode RANDOM ACCESS is password protected (when INSTALLATION...
Page 51: Overview Flowchart 'Guided Adjustment' Procedure
GUIDED ADJUSTMENT MODE Overview flowchart 'Guided Adjustment' procedure. GUIDED ADJUSTMENT MODE INSURE THAT THE PROJECTOR HAS BEEN INSTALLED CORRECTLY, Picture tuning AND THAT THE LENSES/CRTS HAVE BEEN PROPERLY FOCUSED AND ALIGNED. ALL ADJUSTMENTS ARE MADE WITH THE ARROW KEYS <ENTER> to continue Horizontal &...
Page 52: Selecting Setup Pattern
GUIDED ADJUSTMENT MODE Selecting Setup Pattern If an external source is con- nected to the projector, the Setup pattern menu will be dis- Choose a setup pattern played. Push the control disk from below: up or down to highlight the desired setup pattern and then SELECTED SOURCE press ENTER.
Page 53: Internal Cross Hatch Pattern
GUIDED ADJUSTMENT MODE Internal Cross Hatch Pattern The Internal # pattern menu will be displayed if the internal cross hatch pattern has been INTERNAL # PATTERN selected or if no source is con- kHz / Hz nected to the projector. 15.6/50 PAL/SECAM 15.7/60...
Page 54: Picture Tuning
GUIDED ADJUSTMENT MODE Picture tuning Depending on the source type (video, S-Video, RGB(S) analog with composite or Tri-level sync, component input with composite or Tri-level sync) the picture tuning menu offers the possibility to toggle : For Video, S-Video or Component video sources : - The Synchronisation speed - The Line Doubler feature For RGB analog or component input with composite or tri-level sync sources:...
Page 55: Line Doubler (Option)
GUIDED ADJUSTMENT MODE Highlight Line Doubler by push- ing the control disk up or down and press ENTER to toggle PICTURE TUNING between ON (active) and OFF (non active) SYNC : FAST CHROMA DELAY : PAL LINE DOUBLER : ON CONTINUE Select with <ENTER>...
Page 56: Raster Centering On Green Crt Faceplate
GUIDED ADJUSTMENT MODE Raster Centering on Green CRT Faceplate The green raster must be centered both horizontally and vertically on the center of the H AND V SHIFT CRT surface. To center the USE THE ARROW KEYS green raster, look into the green TO CENTER THE RASTER ON THE FACE PLATE OF THE lens and use the control to...
Page 57 GUIDED ADJUSTMENT MODE correct raster position wrong raster position After centering the green raster, press the ENTER key to continue. ENTER continues to Red Raster Shift EXIT returns to Horizontal and Vertical Shift R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 58: Shifting Red And Blue On Green
GUIDED ADJUSTMENT MODE Shifting Red and Blue on Green Use the control disk to shift the red image until the center coincides with the center of the green image. red or blue image green image When the red image is correctly positioned, press the ENTER key to continue with the blue image.
Page 59: Vertical Centerline Bow Adjustment
GUIDED ADJUSTMENT MODE Vertical Centerline Bow Adjustment Correct by pushing The vertical centerline bow the control disk to adjustment corrects for curva- the right ture in the horizontal direction in the middle of the picture for the vertical lines. Push the control disk to the left or to the right to adjust the Vertical centerline vertical centerline bow of the...
Page 60: Right Keystone Adjustment
GUIDED ADJUSTMENT MODE Right Keystone Adjustment Correct by pushing The right keystone function the control disk to corrects the keystone geom- the right. etry distortion of the vertical lines on the right side of the image. Push the control disk to the right or to the left to adjust the right keystone (vertical lines) Correct by pushing...
Page 61: Left Bow Adjustment
GUIDED ADJUSTMENT MODE Left Bow Adjustment The left bow function corrects Correct by pushing for curvature occurring the ver- the control disk to tical lines at the left of the dis- the right. played image. Push the control disk to the left or to the right to adjust the left bow of the setup pattern (vertical lines) and press EN-...
Page 62: Top-Bottom (North-South) Adjustments
GUIDED ADJUSTMENT MODE H size too large Correct by pushing the control disk to the left. Ideal image width H size too small Correct by pushing the control disk to the right. Top-Bottom (North-South) Adjustments Top-Bottom adjustments affect only the horizontal lines of the TOP-BOTTOM setup pattern.
Page 63: Horizontal Centerline Skew Adjustment
GUIDED ADJUSTMENT MODE Horizontal Centerline Skew Adjustment The horizontal skew function Correct by pushing corrects for tilting of the hori- the control disk up zontal lines in the middle of the picture. Push the control disk up or down to adjust the horizontal centerline skew of the setup Hor.
Page 64: Top Bow Adjustment
GUIDED ADJUSTMENT MODE Top Bow Adjustment Correct by pushing the control disk up. The top bow function corrects for curvature occurring in the upper part of the image. Adjust the bow of the horizon- tal lines in the upper side of the image by pushing the control disk up or down until these lines are straight.
Page 65: Size-Linearity Adjustment
GUIDED ADJUSTMENT MODE Size-linearity Adjustment Size adjustments affect the height and width of the pro- jected image. The vertical lin- SIZE-LINEARITY earity adjustment is used to ADJUST VERTICAL SIZE adjust the horizontal lines of AND LINEARITY, IN ORDER the setup pattern until the spac- TO ADJUST THE DESIRED IMAGE DIMENSIONS.
Page 66: Vertical Size Adjustment
GUIDED ADJUSTMENT MODE Vertical Size Adjustment Adjust the vertical size by push- ing the control disk up or down until the exact image height is obtained. Note : - if the internal # pattern was selected, this pattern re- mains on the screen. - if the genlocked pattern was V SIZE selected, the external...
Page 67: Horizontal Phase Adjustment
GUIDED ADJUSTMENT MODE Horizontal Phase Adjustment Note : No horizontal phase adjustment is available on the internal # pattern. For external sources : If the raster shift is correctly adjusted, the text box H phase is projected in the middle of the raster.
Page 68: Convergence Adjustment
GUIDED ADJUSTMENT MODE Convergence Adjustment Convergence adjustments af- fect both the horizontal and vertical lines of the setup pat- CONVERGENCE START WITH GREEN ONLY, tern. These adjustments are THEN RED ON GREEN, THEN BLUE ON GREEN. performed on the red image USE THE ARROW KEYS FOR while superimposed on the HORIZONTAL AND VERTICAL...
Page 69: Blanking Adjustment
GUIDED ADJUSTMENT MODE Blanking Adjustment Blanking adjustments affect only the edges of the projected BLANKING image and are used to frame the projected image on to the screen and to hide or black out ADJUST THE TOP, BOTTOM, unwanted information (or LEFT AND RIGHT BLANKING IN ORDER TO FRAME noise).
Page 70: Top Blanking Adjustment
GUIDED ADJUSTMENT MODE Top blanking adjustment Push the control disk up or unwanted information (to be blanked out) down to adjust the top blank- ing of the setup pattern. Press Correct by pushing ENTER to continue. the control disk down. useful information (to be displayed) Correct by pushing...
Page 71: Left Blanking Adjustment
GUIDED ADJUSTMENT MODE Left blanking adjustment Push the control disk to the unwanted information (to be blanked out) right or to the left to adjust the Correct by pushing left blanking of the setup pat- the control disk to tern. the right.
Page 72: Color Balance
GUIDED ADJUSTMENT MODE Color Balance Use the control disk to select between : - Fixed Color Balance (one of COLOR BALANCE the 4 predefined values) FIXED COLOR BALANCE 3200 4900 6500 9300 - Custom white balance - Custom black balance CUSTOM WHITE BALANCE CUSTOM BLACK BALANCE CONTINUE...
Page 73: Random Access Adjustment Mode
RANDOM ACCESS ADJUSTMENT MODE RANDOM ACCESS ADJUSTMENT MODE Starting up the random access adjustment mode Overview flow chart 'Random Access adjustment mode' Selecting Setup Pattern Internal cross hatch pattern Picture tuning Color balance Sync Fast/Slow Line Doubler Enhanced Blue Geometry adjustments Horizontal phase Raster shift adjustment Left-right adjustments...
Page 74: Starting Up The Random Access Adjustment Mode
RANDOM ACCESS ADJUSTMENT MODE Starting up the random access adjustment mode. Push the control disk up or down to highlight "RANDOM ADJUSTMENT MODE ACCESS" and then press EN- TER. Select a path from below: GUIDED Some items in the Random RANDOM ACCESS INSTALLATION access mode are password...
Page 75: Overview Flowchart 'Random Access Adjustment' Mode
RANDOM ACCESS ADJUSTMENT MODE Overview flowchart 'Random Access Adjustment' mode RANDOM ACCESS ADJUSTMENT MODE PICTURE TUNING GEOMETRY CONVERGENCE COLOR SELECT Select with <ENTER> to accept <EXIT> to return COLOR SELECT PICTURE TUNING GREEN BLUE COLOR BALANCE RED AND GREEN SYNC : FAST BLUE AND GREEN LINE DOUBLER : ON RED AND BLUE...
Page 76 RANDOM ACCESS ADJUSTMENT MODE GEOMETRY LEFT-RIGHT H PHASE V CENTERLINE BOW RASTER SHIFT V CENTERLINE SKEW LEFT - RIGHT (E-W) RIGHT BOW TOP - BOTTOM (N-S) RIGHT KEYSTONE H SIZE LEFT BOW V LINEARITY LEFT KEYSTONE V SIZE BLANKING Select with then <ENTER>...
Page 77: Selecting Setup Pattern
RANDOM ACCESS ADJUSTMENT MODE Selecting Setup Pattern If an external source is con- nected to the projector, the path selection menu will be Choose displayed. Push the control a setup pattern from below: disk up or down to highlight the desired setup pattern and SELECTED SOURCE then press ENTER.
Page 78: Internal Cross Hatch Pattern
RANDOM ACCESS ADJUSTMENT MODE Internal Cross Hatch Pattern The Internal # pattern menu will be displayed if the internal cross hatch pattern has been INTERNAL # PATTERN selected or if no source is con- kHz / Hz nected to the projector. 15.6/50 PAL/SECAM 15.7/60...
Page 79: Picture Tuning
RANDOM ACCESS ADJUSTMENT MODE Picture tuning Highlight Picture tuning by pushing the control disk up or down and press ENTER. PICTURE TUNING The Picture tuning menu will be displayed. Depending on the input COLOR BALANCE source, the Picture tuning SYNC : FAST LINE DOUBLER : ON menu will display different items.
Page 80: Sync Fast/Slow Adjustment
RANDOM ACCESS ADJUSTMENT MODE Custom Color Balance. Select custom white balance by pushing the control disk up or down and press ENTER to start the adjustment. Push the control disk up or down to adjust the red gain and push the control disk to the left or to the right to adjust the blue gain.
Page 81: Line Doubler
RANDOM ACCESS ADJUSTMENT MODE Line Doubler Line doubling is only possible for Video, S-Video or Component Video images on standard line frequency. To eliminate the video line patterns and to improve the image stability, the line doubler has to be switched on. The line doubler is default set in the ON position when starting up for the first time.
Page 82: Color Select
RANDOM ACCESS ADJUSTMENT MODE Color Select Highlight COLOR SELECT by pushing the control disk up RANDOM ACCESS and down and press ENTER to ADJUSTMENT MODE display the color select menu. PICTURE TUNING GEOMETRY CONVERGENCE COLOR SELECT Select with <ENTER> to accept <EXIT>...
Page 83: Geometry Adjustments
RANDOM ACCESS ADJUSTMENT MODE Geometry Adjustments The geometry adjustments have to be done only on the green image. These adjustments are automatically implemented for the other color images : Left-right (EW) and Top-Bottom corrections, blanking, Horizontal amplitude, vertical amplitude, vertical linearity and Horizontal phase. Highlight GEOMETRY by pushing the control disk up or RANDOM ACCESS...
Page 84: Horizontal Phase Adjustment
RANDOM ACCESS ADJUSTMENT MODE Horizontal Phase Adjustment Push the control disk up or down to highlight H PHASE on Geometry menu and then press GEOMETRY ENTER. H PHASE RASTER SHIFT LEFT - RIGHT (E-W) TOP - BOTTOM (N-S) H SIZE V LINEARITY V SIZE BLANKING...
Page 85 RANDOM ACCESS ADJUSTMENT MODE Note : - if the genlocked pattern was selected, the external source will be displayed. A bar scale and a number indi- cator (between 0 and 100) on the screen give a visual indica- tion of the horizontal phase ad- justment.
Page 86: Raster Shift Adjustment
RANDOM ACCESS ADJUSTMENT MODE Raster Shift Adjustment The green raster must be centered both horizontally and vertically on the center of the GEOMETRY CRT surface. To center the H PHASE green raster, look into the green RASTER SHIFT LEFT - RIGHT (E-W) lens and use the control disk TOP - BOTTOM (N-S) to move the raster.
Page 87 Note : Horizontal and Vertical shifts for Red and Blue should be end up with a setting close to 50%. If these settings are significantly greater or lesser than 50%, then contact a BARCO authorized service technician. 8-15 R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 88: Left-Right (East-West) Adjustments
RANDOM ACCESS ADJUSTMENT MODE Left-Right (east-west) Adjustments Left-right and center adjustments affect only the vertical lines of the projected image. To start up the left-right and center adjustments, follow the next procedure : Push the control disk up or down to highlight LEFT-RIGHT (E/W) on the geometry menu GEOMETRY and then press ENTER .
Page 89 RANDOM ACCESS ADJUSTMENT MODE Adjust the next alignments until the vertical lines are straight. To enter an alignment, push the control disk up or down to highlight a function and press ENTER to activate Corrects for curvature of the vertical lines in the middle this function.
Page 90: Top-Bottom (North-South) Adjustments
RANDOM ACCESS ADJUSTMENT MODE Top-Bottom (north-south) Adjustments Top-Bottom and center adjustments affect only the horizontal lines of the projected image. To start up the Top-Bottom and center corrections, follow the next procedure : Push the control disk up or down to highlight TOP-BOT- TOM (N/S) on the geometry GEOMETRY menu and then press ENTER.
Page 91 RANDOM ACCESS ADJUSTMENT MODE Adjust the next alignments until the vertical lines are straight. To enter an alignment, push the control disk up or down to highlight a function and press ENTER to activate this function. Corrects for curvature of the horizontal lines in the Press EXIT to return.
Page 92: Horizontal Size Adjustment
RANDOM ACCESS ADJUSTMENT MODE Horizontal Size Adjustment Push the control disk up or down to highlight H SIZE on the Geometry menu and then GEOMETRY press ENTER . H PHASE RASTER SHIFT LEFT - RIGHT (E-W) TOP - BOTTOM (N-S) H SIZE V LINEARITY V SIZE...
Page 93: Vertical Linearity Adjustment
RANDOM ACCESS ADJUSTMENT MODE Vertical Linearity Adjustment The vertical linearity adjust- ment function corrects for ver- tical non-linearities which ex- GEOMETRY tend from the center of the im- H PHASE age to the top and bottom of RASTER SHIFT LEFT - RIGHT (E-W) the image.
Page 94: Vertical Size Adjustment
RANDOM ACCESS ADJUSTMENT MODE Vertical Size Adjustment Push the control disk up or down to highlight V SIZE on the Geometry menu and then GEOMETRY press ENTER . H PHASE RASTER SHIFT LEFT - RIGHT (E-W) TOP - BOTTOM (N-S) H SIZE V LINEARITY V SIZE...
Page 95: Blanking Adjustments
RANDOM ACCESS ADJUSTMENT MODE Blanking Adjustments Blanking adjustments affect only the edges of the projected image and are used to frame the projected image on to the screen and to hide or black out unwanted information (or noise). A 0% on the bar scale indicates no blanking. To start up the Blanking adjustments, follow the next procedure : Push the control disk up or down to highlight BLANKING...
Page 96 RANDOM ACCESS ADJUSTMENT MODE Adjust the next blanking alignments until the image is correctly framed or the unwanted information is blanked out. To enter a blanking alignment, push the control disk up or down to highlight a function and press ENTER to activate this function. Press EXIT to return.
Page 97: Convergence Adjustments
RANDOM ACCESS ADJUSTMENT MODE Convergence Adjustment Convergence adjustments af- fect both the horizontal and vertical lines of the setup pat- CONVERGENCE tern. These adjustments are performed on the red image while superimposed on the GREEN ONLY RED ON GREEN green image and then on the BLUE ON GREEN blue image while superim- posed on the green image.
Page 98 RANDOM ACCESS ADJUSTMENT MODE The screen area is divided into 25 areas. Use the control disk to move the box to the desired zone and then press ENTER to begin the convergence adjustment. Start the convergence adjustment with zone one and continue as mentioned in the diagram hereafter.
Page 99: Service Mode
SERVICE MODE SERVICE MODE Starting up the service mode Overview flow chart Service mode Projector Set Up Memory Management Common Settings I2C Diagnostics R5975228A BARCOVISION 701 MULTIMEDIA 200697...
Page 100 SERVICE MODE Starting up the Service mode. Use the control disk to highlight 'Service' and then press ENTER. ADJUSTMENT MODE Some items in the Service mode Select a path from below: are password protected (when the GUIDED password function is active). Enter RANDOM ACCESS INSTALLATION your password to continue.
Page 101 TOTAL RUN TIME CHANGE PASSWORD CHANGE LANGUAGE PROJECTOR SET-UP CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE POWER UP MODE BARCO LOGO COPY A BLOCK DELETE A BLOCK DELETE ALL BLOCKS MEMORY MANAGEMENT ALL SETTINGS TO MIDPOS R&B CONVERGENCE MID GR CONV. MID...
Page 102: Identification
- Change password then <ENTER> - Change language <EXIT> to return. - Change projector address - Change baudrate - Power up mode - BARCO logo PROJECTOR SET-UP IDENTIFICATION TOTAL RUN TIME CHANGE PASSWORD CHANGE LANGUAGE CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE...
Page 103: Total Run Time
CHANGE PASSWORD CHANGE LANGUAGE CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE POWER UP MODE : operating BARCO LOGO Select with then <ENTER> <EXIT> to return. ENTER gives the selected item. EXIT returns to the Service mode menu. ADJUST returns to the Operational mode.
Page 104: Change Password
TOTAL RUN TIME CHANGE PASSWORD CHANGE LANGUAGE CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE POWER UP MODE : operating BARCO LOGO Select with then <ENTER> <EXIT> to return. ENTER will display the selected item. EXIT will return to the Path Selection main menu.
Page 105: Change Language
CHANGE LANGUAGE - French CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE - German POWER UP MODE : operating BARCO LOGO Highlight 'Change Language' with Select with the control disk and press ENTER. then <ENTER> <EXIT> to return. ENTER selects the Change language menu.
Page 106: Change Projector Address
'Change Porjector Address' and press CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE ENTER. The Change Projector Ad- POWER UP MODE : operating BARCO LOGO dress menu will be displayed and the actual address will be filled in. Select with then <ENTER> <EXIT> to return.
Page 107: Power Up Mode
Stand-by mode : the projector start CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE up in stand-by and waits until the POWER UP MODE : operating BARCO LOGO stand-by button or a digit key is pressed. To change the Power up mode, Select with then <ENTER>...
Page 108: Barco Logo
SERVICE MODE BARCO_logo The BARCO logo can be added to the image, in overlay or in background, PROJECTOR SET-UP on any place on the screen. To add the BARCO logo or to change IDENTIFICATION TOTAL RUN TIME a setting in the BARCO logo menu,...
Page 109: Memory Management
SERVICE MODE Memory management Highlight 'Memory management' by pushing the control disk up or down SERVICE MODE and press ENTER to display the memory management menu. PROJECTOR SET-UP Within the memory management MEMORY MANAGEMENT COMMON SETTINGS menu, the following items can be I2C DIAGNOSTICS consultated or executed : - copy a block...
Page 110: Deletion Of Blocks
SERVICE MODE To copy the settings of a closed block to the block you are working on COPY MODE (active block), use the control disk to Nr. Src Fh conf. select a block. 15.6 50 video 31.2 60 RGB3S RT All existing settings will be overwritten 15.6 50 intern...
Page 111: Deleting Block By Block
SERVICE MODE Deleting block by block MEMORY MANAGEMENT The 'delete a block' function deletes COPY A BLOCK the settings of a selected block. DELETE A BLOCK DELETE ALL BLOCKS Highlight 'Delete a block' with the ALL SETTINGS TO MIDPOS R & B CONVERGENCE MID control disk and press ENTER.
Page 112: Deletion Of All Blocks
SERVICE MODE Deletion of all blocks Highlight 'delete all blocks' with the control disk and press ENTER. MEMORY MANAGEMENT COPY A BLOCK DELETE A BLOCK DELETE ALL BLOCKS ALL SETTINGS TO MIDPOS R & B CONVERGENCE MID GR CONVERGENCE MID Select with then <ENTER>...
Page 113: Undo All Settings To Midpos
SERVICE MODE ENTER will set all settings to their midposition. EXIT will cancel the ALL SETTINGS TO MIDPOSITION operation to set all settings to their midposition. All settings in current block wil be overwritten ! <ENTER> to confirm <EXIT> to cancel Undo all settings to midpos When "All settings to midpos"...
Page 114: Undo R & B Convergence Mid
SERVICE MODE ENTER sets the convergence set- tings to their midposition. EXIT can- R & B CONVERGENCE MID cels the procedure to set the conver- gence settings to their midposition. Convergence settings in current block wil be overwritten ! <ENTER> to confirm <EXIT>...
Page 115: Common Settings
SERVICE MODE Undo green convergence mid Only available when the projector is equipped with green conver- MEMORY MANAGEMENT gence adjustmentes. The item 'Undo green convergence COPY A BLOCK DELETE A BLOCK mid' will automatically be displayed DELETE ALL BLOCKS ALL SETTINGS TO MIDPOS when the green convergence is R &...
Page 116: G2 Adjustment
NOTICE RISK OF ELECTRICAL SHOCK G2 ADJUSTMENT SHOULD BE 'G2 adjustment should be per- PERFORMED BY BARCO PERSONNEL, formed by BARCO personnel, or OR BARCO AUTHORIZED DEALERS. BARCO authorized dealers'. IF QUALIFIED, PRESS If you are qualified, press ENTER to <ENTER>...
Page 117: Crt Run In Cycle
SERVICE MODE CRT run in cycle The CRT run in cycle option can only be activated when memory blocks on an internal # pattern are available. When one or more such blocks are available, a flashing white image (5sec on, 5 sec off) is generated and that for 5 min on the first internal block. In the next 5 min, a second internal block will be used to generate the flashing white image.
Page 118: Projector Warm Up
SERVICE MODE Projector warm up Highlight 'Projector warm up' by push- ing the control disk up or down and COMMON SETTINGS press ENTER to select the projector warm up menu. G2 ADJUSTMENT CRT RUN IN CYCLE PROJECTOR WARM UP Select with then <ENTER>...
Page 119: I2C Diagnostics
SERVICE MODE I2C Diagnostics Highlights 'I2C Diagnostics' by pushing the control disk up or SERVICE MODE down and press ENTER. The I2C diagnostics menu gives PROJECTOR SET-UP an overview of the I2C failures MEMORY MANAGEMENT inside the projector. COMMON SETTINGS I2C DIAGNOSTICS Select with then <ENTER>...
Page 120 SERVICE MODE 9-22 R5975228A BARCOVISION 701 MULTIMEDIA 200697...
Page 121: Messages, Warnings And Failures
MESSAGES, WARNINGS AND FAILURES MESSAGES, WARNINGS AND FAILURES R5975228 BARCOVISION 701 MULTIMEDIA 070497 10-1...
Page 122 MESSAGES, WARNINGS AND FAILURES When selecting a new source, information about this INPUT 01 source will be displayed on the screen. Source number, Fh= 15.6 kHz horizontal and vertical frequencies of the displayed Fv= 050 Hz source. Announcement of the selected source. SOURCE 01 Message to enter your password.
Page 123 MESSAGES, WARNINGS AND FAILURES WARNING : The input is a valid input but the source is not connected to the input terminals or the input source is switched off. source not available WARNING : When a wrong key is pressed on the RCU. invalid key entry WARNING :...
Page 124 MESSAGES, WARNINGS AND FAILURES WARNING : Projector will switch to 'stand-by' when the RCVDS is no longer available. go to stand by WARNING : The entered frequency or applied frequency of the invalid source is out of the projector's range. frequency input Message to inform that selected table is deleted.
Page 125: Options
OPTIONS OPTIONS IR receiver 800 Hardwired RCU Projector Control software RCVDS 05 VS05 Adapter and communication cables Ceiling mount CM50 Soft edge matching Contrast modulation Picture Orbiting R5975238 BARCOVISION 701 MULTIMEDIA 070497 11-1...
Page 126 OPTIONS IR Receiver 800 This infrared receiver unit makes it possible to control the projector from another room. There is a communication line with cable between the IR receiver and the projector or the RCVDS05. The control information from the RCU can now be sent to this IR receiver.
Page 127 LED on the rear. VS05 The VS05 is a versatile Video and HDTV source selector for all BARCO's digitally controlled large screen projectors. It offers the possibility to connect and switch up to 5 different Video sources, 3 different S-Video sources and 1 RGB Analog source to a BARCO projector.
Page 128: Orbiting Kit
Available length : 1 m, order number R9827630 Ceiling mount CM50 This suspension system enables to mount any projector from the BARCO 700 series to the ceiling without using any mechanical interface, and to adapt the projector perfectly to the local mounting requirements.
Page 129: Appendix A : Battery Replacement In The Rcu
APPENDIX A : BATTERY REPLACEMENT IN THE RCU Battery replacement in the RCU. Remove the battery cover on the backside of the remote control by pushing the indicated handle a little to the bottom of the RCU. Lift up the top side of the cover at the same time (fig.
Page 130 APPENDIX A : BATTERY REPLACEMENT IN THE RCU R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 131: Appendix B : Orbiting
Due to the fact that the same picture information is shown for a long period on the same place, picture tubes can be damaged by 'local burn-in'. To avoid this problem, BARCO has designed special Orbiting circuitry which moves the picture very slowly around a predefined screen area.
Page 132 APPENDIX B : ORBITING Master/slave toggle Highlight 'CHANGE TO SLAVE' with the control disk and press ENTER to set the projector as MASTER ORBITING CHANGE TO SLAVE Slave. MODE: ON SPEED: FAST ADJUST DEVIATION SELECT WITH THEN <ENTER> DEVIATION ADJUST : VERTICAL WITH HORIZONTAL WITH <EXIT>...
Page 133 APPENDIX B : ORBITING Orbiting speed toggle (only in MASTER Orbiting) Highlight 'SPEED : SLOW' with the coontrol disk and press EN- TER to set the ORBITING SPEED MASTER ORBITING CHANGE TO SLAVE to Fast. MODE: ON SPEED: FAST Highlight 'SPEED : FAST' with the ADJUST DEVIATION control disk and press ENTER to SELECT WITH...
Page 134 APPENDIX B : ORBITING When adjusting the horizontal and the vertical deviation, the picture moves in the corresponding direction, allowing the set up of the deviation without orbiting operation. Push the control disk to the left (right) or up (down) to toggle be- tween Hor.
Page 135 APPENDIX B : ORBITING Adjustment procedure multiple projector installations : Important : to allow corrections in the deviation alignments of the slave projectors, never adjust the deviations of the master projector to its maximum. Default setting of the Master projector see 'Stand alone projector'. Highlight 'ADJUST DEVIATION' with the control disk and press ENTER.
Page 136 APPENDIX B : ORBITING R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 137: Appendix C : Soft Edge Matching
APPENDIX C : SOFT EDGE MATCHING Soft edge matching (option) Multi-screens are popular for many applications. In these installations, the goal is to obtain a contiguous matched image, forming one homogenous view. The soft edge matching feature provides a solution to the annoying side effects when adjusting two or more projected images next to each other.
Page 138 APPENDIX C : SOFT EDGE MATCHING Basic concept total light output 100% light output per image 100% Image 1 Image 2 adjustable overlapping area Adjustment procedure : Start up the adjustment mode by pressing ADJUST (see also chapter 'Start up of the adjustment mode') Highlight Random access with the control disk and press ENTER to start up the Random Access Adjustment mode (see also chapter Random Access Adjustment...
Page 139 APPENDIX C : SOFT EDGE MATCHING Each overlap area (left and right) is determined by a start (stop) position and an area width. The start (stop) position for the top (bottom) overlap area is determined by the blanking adjustment. Highlight 'H TEST MODE' and press ENTER.
Page 140 APPENDIX C : SOFT EDGE MATCHING Start position Highlight START POSITION with the control disk and press ENTER . SOFT EDGE CORRECTION START START LEFT RIGHT STOP BOTTOM STOP H TEST MODE-OFF V TEST MODE-OFF Select with then <ENTER> <EXIT> to return 639a ENTER displays the normal image super- imposed with the internal generated test...
Page 141 APPENDIX C : SOFT EDGE MATCHING Left image area Highlight LEFT with the control disk and press ENTER . The normal image superimposed SOFT EDGE CORRECTION with the test pattern will be dis- START played. START LEFT RIGHT STOP BOTTOM STOP H TEST MODE-OFF V TEST MODE-OFF...
Page 142 APPENDIX C : SOFT EDGE MATCHING Stop position Highlight STOP POSITION with the control disk and press ENTER . SOFT EDGE CORRECTION START START LEFT RIGHT STOP BOTTOM STOP H TEST MODE-OFF V TEST MODE-OFF Select with then <ENTER> <EXIT> to return 639h ENTER displays the normal image super- imposed with the internal generated test...
Page 143 APPENDIX C : SOFT EDGE MATCHING Right image area Highlight LEFT with the control disk and press ENTER . SOFT EDGE The normal image, superimposed CORRECTION with the test pattern will be dis- START played. START LEFT RIGHT STOP BOTTOM STOP H TEST MODE-OFF V TEST MODE-OFF...
Page 144 APPENDIX C : SOFT EDGE MATCHING Vertical test mode Highlight ' V TEST MODE ' and press ENTER . SOFT EDGE The test image is enabled to adjust CORRECTION the start (stop) position and the START area width. START LEFT RIGHT STOP When switching the V test mode to BOTTOM On, the H test mode will switch to...
Page 145 APPENDIX C : SOFT EDGE MATCHING Top soft edge area adjustment Highlight TOP with the control disk and press ENTER . The normal image, superimposed SOFT EDGE CORRECTION with the test pattern will be dis- START played. START LEFT RIGHT STOP BOTTOM STOP H TEST MODE-OFF...
Page 146 APPENDIX C : SOFT EDGE MATCHING Bottom soft edge area adjustment Highlight BOTTOM with the con- trol disk and press ENTER . The normal image, superimposed SOFT EDGE CORRECTION with the test pattern will be dis- START played. START LEFT RIGHT STOP BOTTOM STOP H TEST MODE-OFF...
Page 147: Appendix D : Contrast Modulation (Option
APPENDIX D : CONTRAST MODULATION Contrast modulation (option) Today multi-screens are very popular for many applications e.g. simulation busi- ness. In these installations, the goal is to obtain a continuous matched image, forming one homogeneous view. The viewer wants to see an overall light output uniformity.
Page 148: Adjustment Procedure
APPENDIX D : CONTRAST MODULATION Basic concept WITHOUT CONTRAST MODULATION WITH CONTRAST MODULATION horizontal light output horizontal light output CORNER CORNER 100% 100% FALL OFF FALL OFF Image Image vertical vertical light output 100% 100% light output horizontal light ouptut horizontal light ouptut 100% 100%...
Page 149 APPENDIX D : CONTRAST MODULATION The first 3 adjustments (horizontal red, green and blue) are used for CONTRAST horizontal light equalisation for the EQUALISATION three specific colors separately. RED HORIZONTAL GREEN HORIZONTAL This compensates the error due to BLUE HORIZONTAL VERTICAL the different horizontal position of CONTRAST...
Page 150 APPENDIX D : CONTRAST MODULATION Highlight VERTICAL with the con- trol disk and press ENTER . This CONTRAST adjustment is done for all three EQUALISATION colors at the same time. RED HORIZONTAL GREEN HORIZONTAL BLUE HORIZONTAL VERTICAL Use the control disk to equalise the CONTRAST vertical light output and press EN- EDGE CORRECTION...
Page 151 APPENDIX D : CONTRAST MODULATION Highlight TOP-BOTTOM with the control disk and press ENTER to CONTRAST start the vertical ' hot spot ' cor- EQUALISATION rection in the center of the RED HORIZONTAL GREEN HORIZONTAL screen. Adjust with the control BLUE HORIZONTAL VERTICAL disk for the same light output in...
Page 152 APPENDIX D : CONTRAST MODULATION R5975238A BARCOVISION 701 MULTIMEDIA 200697...
Page 153: Appendix E : Adjustment Blocks (Memory Blocks
APPENDIX E : ADJUSTMENT BLOCKS Adjustment Blocks (memory blocks) As the BARCOVISION 701 MULTIMEDIA is digitally controlled, all geometry and convergence adjustments are stored in the projector’s memory as numeric values. These numeric values are used to control digital potentiometers which in turn, control the projector.
Page 154 APPENDIX E : ADJUSTMENT BLOCKS blocks available, the projector dis- plays a warning. WARNING All memory blocks are Press ENTER to continue and start used. Please, go to the up the adjustment mode to delete a service mode, delete a block and reselect the source block.
Page 155: Appendix F : Source Numbers 90 - 99
APPENDIX F : SOURCE NUMBERS 90 - 99 Source numbers 90 - 99 Source numbers 90 - 99 do not correspond to physical inputs to the projector or RCVDS05. They are used to assign an additional adjustment block to a source. This additional adjustment block may contain different geometry and convergence set- tings, sync fast/slow positions and enhanced blue on/off settings.
Page 156 APPENDIX F : SOURCE NUMBERS 90 - 99 Follow the steps below to create a second adjustment block for a source between 0 and 9. 1. Select the source between 0 and 9 that the second adjustment block is to be created for.
Page 157 INPUT SOURCES INPUT SOURCES PROJECTOR PROJECTOR INPUT SOURCES INPUT SOURCES RCVDS RCVDS R5975238A BARCOVISION 701 MULTIMEDIA 200697...

Barco VISION 701 MULTIMEDIA Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Barco VISION 701 MULTIMEDIA

Summary of Contents for Barco VISION 701 MULTIMEDIA

Table of Contents
