Summary of Contents for Barco Vision 708 9002357
- Page 1 VISION R9002357 R9002358 INSTALLATION MANUAL...
- Page 3 BARCO PROJECTION SYSTEMS VISION R9002357 R9002358 INSTALLATION MANUAL Date : Art. No. : 200499 R5976026A...
- Page 4 Produced by BARCO NV, April 1999. All rights reserved. Trademarks are the rights of their respective owners. Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...
-
Page 5: Table Of Contents
Table of Contents TABLE OF CONTENTS WARNINGS ......................................1-1 SAFETY INSTRUCTIONS ..................................1-1 On safety ......................................1-2 On installation ....................................1-2 On servicing ..................................... 1-2 On cleaning ...................................... 1-2 On repacking ....................................1-2 On illumination ....................................1-2 UNPACKING & DIMENSIONS ..................................2-1 Unpacking ...................................... - Page 6 Table of Contents 5976026A BARCOVISION 708 200499...
-
Page 7: Safety Instructions
The part number and serial number are located at the back side of the projector. Record these numbers in the spaces provided below. Refer to them whenever you call upon your BARCO dealer regarding 1. This product should be operated from an AC power source. - Page 8 The exclusion zone must be not less dampened with mild detergent solution. Never use strong solvents, than 10 cm (4”) for BARCO Retro Projectors and not less than 40 cm (16”) such as thinner or benzine, or abrasive cleaners, since these will for all other BARCO projectors.
-
Page 9: Unpacking & Dimensions
Unpacking and Dimensions UNPACKING AND DIMENSIONS To open de banding, pull on the clip as shown in the first drawing. Take the projector out of its shipping carton and place it on a table. Save the original shipping carton and packing material, they will come in handy if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory. - Page 10 Unpacking and Dimensions 5976026A BARCOVISION 708 200499...
-
Page 11: Installation Guidelines
The projector is designed for projecting an image width from 1.4m (4.6') to 7m (23') with an aspect ratio of 4 to 3. It leaves the BARCO factory, adjusted as a ceiling front projector for a screen width of 2.4m. - Page 12 Max phosphor width on CRT = 4.33 inch Max phosphor width on CRT = 11 cm Ceiling mount or table mount? To install the projector, apply always the BARCO kits which are specially designed for this function. BARCO ceiling support.
-
Page 13: Installation Set Up
Installation Set Up INSTALLATION SET UP Opening procedure : During the projector set up and installation it is neces- sary to open the top cover. To gain access, procede as follow : *Turn both lock screws with a screwdriver or a coin counter clockwise. -
Page 14: Access To Controls
Installation Set Up The scanning can be switch by turning the Horizontal and Vertical scan connectors and the convergence connectors. To change the scanning, it is necessary to open the projector top cover and to rotate the chassis. For opening the projector's top cover, see Getting access to controls. WARNING TURN OFF PROJECTOR AND UNPLUG THE POWER CORD BEFORE CHANGING THE SCAN DIRECTION. - Page 15 CHANGE BAUDRATE 7. Push the cursor key é or ê to select 'IDENTIFICATION' POWER UP MODE : operating BARCO LOGO 8. Press ENTER. On this screen, information is given about the projectors configuration. Configuration when leaving the factory : ceiling/front configuration.
- Page 16 Installation Set Up 5976026A BARCOVISION 708 200499...
-
Page 17: Projector Set Up
Projector Set Up PROJECTOR SET UP strap The strap on the controller unit allow a set up of the password mode. Gaining access to the strap - Open the top cover (see installation set up) C ‚…v“‚ ‡hyÆp h à - Open the chassis (see installation set up) p ‚r p ‡‚…†... - Page 18 Projector Set Up 5976026A BARCOVISION 708 200499...
-
Page 19: Power (Mains) Connection
Power Connection POWER CONNECTION Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the front of the projector. See installation instructions before V NOM 120/230 Volt connecting to the supply I MAX 5/2.5 AMP... -
Page 20: Fuses
For continued protection against fire hazard : - replace with the same type of fuse - refer replacement to qualified service personnel Fuse type : 2 x T5A/250V (Barco order number : R314104) The projector is switched ON and OFF using the power (mains) switch ON/OFF. -
Page 21: Installation Adjustments
Installation Adjustments INSTALLATION ADJUSTMENTS Press ADJUST to enter the adjustment mode. ADJUSTMENT MODE Select a path from below : IRIS GUIDED RANDOM ACCESS INSTALLATION SERVICE Source 01 Select with then <ENTER> <EXIT> to return. (only for qualified technician) 5976026A BARCOVISION 708 200499... -
Page 22: Scheimpfug Adjustment
Installation Adjustments Adjustment Mode Installation Scheimpflug Adjustment Optical Lens Focusing Raster Centering CRT Projection Angle Adjustment It will be necessary to perform several mechanical adjustments while in the installation mode. Remove the top cover in order to gain access to the adjustment points (see Access to controls). Two possible ways to enter the installation mode : a) Using the RCU. - Page 23 THE FOLLOWING INSTALLATION MENUS ARE RESERVED TO, AND When entering the installation mode, the projector will automatically TO BE PERFORMED ONLY BY BARCO PERSONNEL, OR BARCO switch to the internal pattern on 15 kHz/50 Hz. AUTHORIZED DEALERS IF QUALIFIED, PRESS <ENTER>...
- Page 24 Installation Adjustments The scheimpfug correction can be adjusted separately for the three range 1 tubes within 3 ranges: P min. SW : 1.40 m (55") max. SW : 1.90 m (75") P range 1 : 1.4 m (55") to 1.9 m (75"), optimum screen width 1.4 m (55") range 2 : 1.9 m (75") to 3.2 m (126"), optimum screen width 2.4 m (94")
- Page 25 Installation Adjustments The optical focusing procedure is performed separately for each lens. The appropriate CRT will be switched on as the user proceeds OPTICAL LENS FOCUSING through the optical focusing adjustment sequence. 1. LOOSEN THE NUT ON THE REAR OF THE XXXX LENS, ROTATE THE LENS BARREL TO FOCUS THE CENTER Each lens has two focus adjustment points, one at the rear of the lens...
-
Page 26: Raster Centering
Installation Adjustments The raster must be centered on the CRT screen surface of each tube, therefore, it is necessary to look into the lenses. Caution : To avoid eye discomfort while performing these adjust- ments, reduce the contrast and gradually increase the brightness level until the raster becomes visible behind the image. -
Page 27: Crt Projection Angle Adjustment
Installation Adjustments The projection angle of the red and blue CRT's is dependent on the CRT PROJECTION ANGLE desired size of the projected image. If the centers of green, blue and ADJUSTMENT red do not coincide, the CRT projection angle must be adjusted. Never CRT PROJECTION ANGLE IS try to correct this misalignment with the shift correction or the static THE FIRST STEP OF STATIC... - Page 28 Installation Adjustments & & Screws A, B, C and D (M4) : upper fixation latch. nutdriver 7mm. Screw A', B', C' and D' (M4) : lower fixation latch. nutdriver 7mm. & & Loosen the four hexagon screws A, A', B and B', upper and lower fixation latch. These screws fasten the cooling house of the red tube.
- Page 29 Installation Adjustments After finishing the installation adjustments procedure, the 'Path selection' returns on the screen. You are now able to start the alignment procedure for the projector. You have the choice between: ADJUSTMENT MODE - Guided Adjustment Procedure Select a path from below : - Random Access Adjustment Procedure IRIS GUIDED...
- Page 30 Installation Adjustments 7-10 5976026A BARCOVISION 708 200499...
-
Page 31: Appendix A : G2 Adjustment
If you are qualified, press ENTER to continue with the G2 adjustment, RISK OF ELECTRICAL SHOCK otherwise press EXIT to return to the service menu. G2 ADJUSTMENT SHOULD BE PERFORMED BY BARCO PERSONNEL OR BARCO AUTHORIZED DEALERS IF QUALIFIED, PRESS <ENTER>... - Page 32 G2 Adjustment Open the top cover to reach the G2 controls and adjust these G2 controls for red, blue and green separatly. The controller automatically increases brightness and contrast until the raster behind the displayed text becomes visible. Loosen screws and move the cover plate Look to the projected image and observe the raster behind the image to the left to access the G2 controls.
