Locking
Modules can be locked by using the built-in website. Front panel menu can be locked as
follows:
Info: The locking/unlocking can be switched from the built-in website, see more information in
section

6.2. Info menu

The Info menu displays basic information about the unit as follows:

6.3. Settings menu

6.3.1. Network settings

If the extender is connected to an Ethernet Network, the settings are available in this
submenu.
Info: If you change more settings in Network submenu, it is not necessary to restart the device
after every step. Reboot after setting all necessary parameters is enough.
Setting the IP address
Step 1. Navigate to Settings / Network Settings / IP Address
Step 2. Use left ◄ and right ► buttons to place the cursor to
Step 3. Set the numbers by the up ▲ and down ▼ buttons.
Step 4. Press the enter  button to save changes.
Step 5. Press the enter  button to restart device
Setting the Subnet mask
Step 1. Navigate
Step 2. Use left ◄ and right ► buttons to place the cursor to
Step 3. Set the numbers by the up ▲ and down ▼ buttons.
Step 4. Press the enter  button to save changes.
Step 5. Press the enter  button to restart (recommended).
Page 30 / 90

Lock LCD home screen: The whole screen is locked, no front panel operations
can be done, front panel buttons are disabled, Device information is displayed.

Disable setup from LCD menu: Front panel
operations are enabled, but settings cannot be
changed, a closed padlock sign is displayed.
7.8.7 on page 56.

MCU Firmware version

FPGA Firmware version

Web content version

Supply A (the power supply unit)

Supply B (not in use, reserved for future developments)
 Temperature – measured on the core module. If the temperature is above the
Overheat limit, the speaker sounds, the unit reboots and the event is logged.
submenu and press the enter  button.
the desired number.
(recommended).
to Settings
Subnet mask submenu and press the enter  button.
the desired number.
/ Network Settings
Section 6. Front panel operations
¹IP Address:
192.168.002.2ý
¹Network SettinÞ
¾-IP Address
¹IP Address:
192.168.002.2½
Restart now?
ENTER=Yes ESC=No
/
¹Network SettinÞ
¾-Subnet mask º
¹Subnet mask:
255.255.255.0½
Restart now?
ENTER=Yes ESC=No
Þ
º
Þ
Þ
