2. Controls and connections

2.1. Frames

2.1.1. Transmitter front view

Info: MODEX-OPTS frames can be seen on the photos which look almost the same as
MODEX-OPTM frames. Their housing contains just two differences: the 'OPTM'
designation and the part number.
Ethernet
USB K+M
5
Ethernet
1
Status LEDs
2
3 Menu navigation
PSU LEDs
4
5 USB K+M
Menu display
6
Reset
7
Page 10 / 90
Status LEDs
1 2
Locking RJ45 socket. Remote control port for connecting the unit
to Local Area Network (LAN).
Audio LED lights green when the audio transfer is active. Video
LED indicates correct video transmission. CNTRL LED is green
when low speed handshake of the extenders is complete. OPTS
LINK LED lights when optical link is active.
Up, down, left, right, enter and escape buttons for menu
navigation.
CPU live LED blinks to indicate normal operation. +5V and +3.3V
LEDs light green when the extender is powered on.
USB connection to HOST (Computer) unit via USB B-type
connector.
Displays status information and menu operation on the LCD with
2x16 characters.
Reset button reboots the extender. This is the same as
disconnecting from power source and reconnecting again.
Menu navigation
Menu display
6
Section 2. Controls and connections
PSU LEDs
3 4
Reset
7
