2.1.2. Receiver front view

Info: MODEX-OPTS frames can be seen on the photos which look almost the same as
MODEX-OPTM frames. Their housing contains just two differences: the 'OPTM'
designation and the part number.
Ethernet
USB ports
5
Ethernet
1
2 Status LEDs
Menu navigation
3
PSU LEDs
4
USB ports
5
Menu display
6
7 Reset

2.2. Rear view

MODEX can be supplied with many kind of interface modules, thus the rear view of the
extenders are different. Following example shows the structure of the installed modules.
Media connector
1
HID: Human Interface Device
Section 2. Controls and connections
Status LEDs
1 2
Locking RJ45 socket. Remote control port for connecting the unit
to Local Area Network (LAN).
Audio LED lights green when the audio transfer is active. Video
LED indicates correct video transmission. CNTRL LED is green
when low speed handshake of the extenders is complete. OPTS
LINK LED lights when optical link is active.
Up, down, left, right, enter and escape buttons for menu
navigation.
CPU live LED blinks to indicate normal operation. +5V and +3.3V
LEDs light green when the extender is powered on.
USB K+M ports for HID
mouse). See more information in section
Displays status information and menu operation on the LCD with
2x16 characters.
Reset button reboots the extender. This is the same as
disconnecting from power source and reconnecting again.
1 2
Interface module (D)
Menu navigation
Menu display
6
Interface module (E)
3
MODEX-OPTS, MODEX-OPTM
User's Manual
3 4
7
1
devices (preferably Keyboard and
4.4 on page 25.
Video & Audio module (B)
4
PSU LEDs
Reset
