- Page 1 HDMI-TPS-TX90/RX90 User’s Manual...
- Page 2 Page 2 / 31...
-
Page 3: Safety Instructions
HDMI-TPS-TX90/RX90 User’s Manual SAFETY INSTRUCTIONS Class II apparatus construction. This equipment should be operated only from the power source indicated on the product. To disconnect the equipment safely from power, remove the power cord from the rear of the equipment, or from the power source. The MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable. -
Page 4: Declaration Of Conformity
DECLARATION OF CONFORMITY Lightware Kft. 15 Peterdy Street, Budapest H-1071, HUNGARY as manufacturer declare, that the products HDMI-TPS-TX90 HDMI-TPS-RX90 (Computer Monitor Extender) in accordance with the EMC Directive 2004/108/EC and the Low Voltage Directive 2006/95/EEC is in conformity with the following standards: EMI/EMC ........ -
Page 5: Table Of Contents
Possible errors during firmware upgrade ..............22 TROUBLESHOOTING ......................... 23 7.1....................... 23 HERE IS NO PICTURE SPECIFICATION .......................... 24 MECHANICAL DRAWINGS ......................26 9.1. HDMI-TPS-TX90 ........................26 9.2. HDMI-TPS-RX90 ........................28 WARRANTY ..........................30 DOCUMENT REVISION HISTORY ..................30 Page 5 / 31... -
Page 6: Introduction
1. Introduction Thank you for choosing Lightware’s HDMI TPS series transmitter and receiver. The HDMI-TPS-TX90 and HDMI-TPS-RX90 twisted pair extenders provide extension of uncompressed Full-HD video for extreme distances over a single CATx cable. 2. General description 2.1. Box contents ... -
Page 7: Features
HDMI-TPS-TX90/RX90 User’s Manual 2.3. Features Two available firmware versions – To best fit to customers’ demands, Lightware provides two firmware versions. Users can maximize potential cable length or extended resolutions. 10/100 Ethernet extension – Don’t need a separate LAN cable anymore. Ethernet ... -
Page 8: Controls And Connections
4.5.4 for more information.) RS-232 port 9-pole D-sub female receptacle connector. Connect a serial cable between the HDMI-TPS-TX90 and the desired serial device. (See section for more information about usage of serial port.) Page 8 / 31 Section 3. Controls and connections... -
Page 9: Tx90 Rear View
19-pole standard HDMI connector. Connect a standard HDMI cable between HDMI source HDMI-TPS-TX90. Use locking receptacle if the plug has additional screw for safe connecting. (See section 3.5.1 for more information.) TPS Output RJ45 receptacle connector. Connect a Twisted Pair cable between the HDMI-TPS-RX90 and HDMI-TPS-TX90. -
Page 10: Rx90 Front View
4.5.4 for more information.) RS-232 port 9-pole D-sub female receptacle connector. Connect a serial cable between the HDMI-TPS-TX90 and the desired serial device. (See section for more information about usage of serial port.) Page 10 / 31 Section 3. Controls and connections... -
Page 11: Rx90 Rear View
19-pole standard HDMI connector. Connect a standard HDMI cable between HDMI source HDMI-TPS-TX90. Use locking receptacle if the plug has additional screw for safe connecting. (See section 3.5.1 for more information.) TPS Output RJ45 receptacle connector. Connect a Twisted Pair cable between the HDMI-TPS-RX90 and HDMI-TPS-TX90. -
Page 12: Electrical Connections
3.5. Electrical connections 3.5.1. HDMI Input and Output HDMI-TPS-TX90 and RX90 provide standard 19-pole HDMI connectors for input and output. Always use high quality DVI cable for connecting sources and displays. HDMI Type A receptacle HDMI Type A Plug Signal... -
Page 13: Twisted Pair Inputs And Outputs
HDMI-TPS-TX90 and RX90 provide standard RJ45 connectors for TPS Input, Output and Ethernet. RJ45 receptacle RJ45 plug Lightware recommends the termination of TP cables on the basis of TIA/EIA T 568 A or TIA/EIA T 568 B standards. TIA/EIA color and... -
Page 14: Installation
4. Installation 4.1. Mounting of HDMI-TPS units To fix the extender units, Lightware supplies optional accessories for different usage methods. All kind of mounting kits have the similar fixing method. The TPS units have two mounting holes with inner thread on the bottom side. Secure the device by screwing the enclosed M3x6 mm cross recessed, countersunk head screws (DIN 965A) through two holes of the shelf into the TPS’... -
Page 15: Connection Between Tx90 And Rx90
4.2. Connection between TX90 and RX90 Connect one CAT5, CAT5e, CAT6a or CAT7 (recommended) cable between HDMI-TPS-TX90 transmitter and HDMI-TPS-RX90 receiver. The TPS line connection is not compatible with Ethernet devices. Do not connect either the TPS Output or TPS Input to a Local Area Network device or a PC. It might damage both devices. -
Page 16: Serial Devices
Pin 2: Pin 3: RD: Received Data (digital input) TD: Transmitted Data (digital output) Info: HDMI-TPS-TX90 and RX90 are DCE units according to their pin-out. Different type of serial cables must be used between different serial devices. Null-modem Straight Straight Null-modem* * in general contact DCE with DCE by tail-circuit serial cable. -
Page 17: Example Connection Diagrams
HDMI-TPS-TX90/RX90 User’s Manual 4.5.3. Example connection diagrams The following cases are examples. Devices may have different receptacles and pin-outs. To extend RS-232 between controller system (DTE) and projector (DCE). Connect straight serial cable between controller system (DTE) and TX90 (DCE) and null-modem serial cable between RX90 (DCE) and projector (DCE). -
Page 18: Operation
TPS connection. After the system setup is complete, connect the output of the +12V Power Adaptor to the HDMI-TPS-TX90 or the HDMI-TPS-RX90. Both units are immediately powered ON. The initialization of the units may take time up to 10 seconds. After this procedure the status LEDs provide information about the connection. -
Page 19: Power Save Mode
HDMI-TPS-TX90/RX90 User’s Manual 5.3. Power save mode* The units enter power save mode when no signal is detected on the input. Normal operation is restored automatically when any signal appears on the input. Info Power save mode is available only with normal firmware. Long reach firmware does not support low consumption mode. -
Page 20: Firmware Update
6. Firmware update This section is about the update procedure of Lightware HDMI-TPS-TX90 and HDMI-TPS-RX90 long range extenders. 6.1. Information: The firmware update is recommended if a new version is released. It might also be necessary if serious problems occur with former (or later) versions. - Page 21 HDMI-TPS-TX90/RX90 User’s Manual After a successful burning verification starts automatically. After a successful verification the firmware upgrade terminates. 8. Press any key to exit. 9. Turn the switch back to "Normal" position on the front panel (not necessary for normal operation, but recommended) 10.
-
Page 22: Possible Errors During Firmware Upgrade
6.3.1. Possible errors during firmware upgrade “Could not autodetect board connected to any uart port” Possible reason Solution Check if the serial cable is connected Serial cable is not connected properly between the TPS device and properly: the computer. ... -
Page 23: Troubleshooting
Check the power state of the devices Check the LIVE LED on the front side of the HDMI-TPS-TX90 and the HDMI-TPS- RX90. If the units are powered and ready to use the LIVE LED blinks once every two seconds. -
Page 24: Specification
8. Specifications Video Standard ..............HDMI standard which supports: ........................Deep color, ........Blu-ray Disc and HD DVD video and audio at full resolution, ....................... 3D over HDMI, ......................4K x 2K resolution, ................Consumer Electronic Control (CEC), ..................Updated list of CEC commands, .................. - Page 25 HDMI-TPS-TX90/RX90 User’s Manual Connectors TX video input, RX video output ........ 19-pole HDMI Type A receptacle TX TPS output, RX TPS input ........... CAT6 RJ45 receptacle TX and RX Ethernet ..............CAT6 RJ45 receptacle TX and RX IR input, output ......3.5mm TRS connector (approx. 1/8’’ jack) TX and RX Serial port ............
-
Page 26: Mechanical Drawings
9. Mechanical Drawings 9.1. HDMI-TPS-TX90 Front View Top view Page 26 / 31 Section 9. Mechanical Drawings... - Page 27 HDMI-TPS-TX90/RX90 User’s Manual Rear View Bottom View Section 9. Mechanical Drawings Page 27 / 31...
-
Page 28: Hdmi-Tps-Rx90
9.2. HDMI-TPS-RX90 Front View Top view Page 28 / 31 Section 9. Mechanical Drawings... - Page 29 HDMI-TPS-TX90/RX90 User’s Manual Rear View Bottom View Section 9. Mechanical Drawings Page 29 / 31...
-
Page 30: Warranty
The customer shall pay shipping charges when unit is returned for repair. Lightware will cover shipping charges for return shipments to customers. In case of defect please call your local representative, or Lightware at Lightware Visual Engineering 15 Peterdy Street, Budapest H-1071, HUNGARY Tel.: +36 1 889 6177... - Page 31 HDMI-TPS-TX90/RX90 User’s Manual NOTES: Section 11. Document revision history Page 31 / 31...
