2.6.3. DVI inputs and outputs
29 pole DVI-I connectors, however internally connected pins vary by interface types. This
way, user can plug in any DVI connector, but keep in mind that analog signals (such as
VGA or RGBHV) are currently not processed – planned for future developments.
Always use high quality DVI cable for connecting sources and displays. Pay attention to
the DVI cable, if dual link signal is to be sent, use only dual link capable DVI cables.
Pin
1
2
3
4
5
6
7
8
C1
C4
2.6.4. BNC connectors (SDI)
Standard BNC receptacle is used for SD/HD/3G-SDI input and outputs.
Recommended coax cable type: Belden 1694A
1
These pins are connected only in MODEX-AV-DVIDL-IM and MODEX-AV-DVIDL-OM modules.
2
These pins are only for future developments.
Section 2. Controls and connections
1
9 10 11
17 18 19
Signal
TMDS Data2-
TMDS Data2+
TMDS
Data2/4
Shield
TMDS Data4-
1
1
TMDS Data4+
DDC Clock
DDC Data
2
Analog Vertical Sync
2
Analog Red
2
Analog Horizontal Sync
Table 2-2. DVI-I connector pin assignments
BNC receptacle
2
3
4
5
6
7
8
12 13
14 15 16
20 21
22 23 24
Pin
Signal
9
TMDS Data1-
10
TMDS Data1+
11
TMDS
Data1/3
Shield
12
TMDS Data3-
13
TMDS Data3+
14
+5V Power
15
GND (for +5V)
16
Hot Plug Detect
C2
Analog Green
C5
GND
BNC plug
MODEX-OPTS, MODEX-OPTM
User's Manual
C1
C2
C3
C4
C5
Pin
Signal
17
TMDS Data0-
18
TMDS Data0+
19
TMDS
Data0/5
1
20
TMDS Data5-
1
21
TMDS Data5+
22
TMDS Clock Shield
23
TMDS Clock+
24
TMDS Clock-
2
C3
Analog Blue
Page 15 / 90
Shield
1
1
2
