4
RECEIVE AND TRANSMIT

D PSK memory transmission

Pre-set characters can be sent using the PSK memory.
Contents of the memory are set using the edit menu.
q During PSK mode operation, push [DECODE] (F-3)
to select PSK decode screen.
w Push [TX MEM] (F-3) to select PSK memory screen.
e Push [1–4/5–8] (F-6) to select memory bank then
push one of the function keys ([PT1] (F-1) to
[PT4] (F-4) or [PT5] (F-1) to [PT8] (F-4)).
• When no keyboard is connected, the selected memory
contents will be transmitted immediately.
• When a keyboard is connected, the memory contents
will be transmitted immediately when [F1] to [F8] on
the connected keyboard is pressed, or transmitted after
[F12] is pressed, depending on auto transmission/
reception setting (see below).
• The transmission date, time, reception date and/or time
may be displayed in RX contents screen, depending on
setting.
For your information
When an external keypad is connected to [MIC] con-
nector on the front panel, the programmed contents,
PT1—PT4, can be transmitted. (pgs. 18, 133)

D Automatic transmission/reception setting

q During PSK mode operation, push [DECODE] (F-3)
to select PSK decode screen.
w Push [TX MEM] (F-3) to select PSK memory
screen, then push [EDIT] (F-5) to select PSK mem-
ory edit screen.
• PSK memory contents of Channel 1 (PT1) is selected.
e Push [PT1..PT8] (F-6) several times to select the
desired PSK memory.
r Push [AUTO TX] (F-5) several times to select the
desired condition, as follows.
• AUTO TX/RX : Automatically transm its the
• AUTO TX
• AUTO RX
• No indication : Press [F12] on the keyboard
t Push [EXIT/SET] to return to exit from PSK mem-
ory edit condition.
NOTE: The transceiver always functions in the
"AUTO TX/RX" setting when no keyboard is con-
nected.
57
selected memory and returns to
receive after the transmission.
: Automatically transm its the
selected memory. To return to
receive, press [F12] on the key-
board.
: Press [F12] on the keyboard
to transmit the selected memory.
Automatically returns to receive
after the transmission.
to transmit the selected memory
and press [F12] again to return to
receive.
/
DECODE TX MEM 1–4/5–8
F-3
F-1 F-4 F-1 F-4
– –
or
PT1 PT4 PT5 PT8
/
DECODE TX MEM PT1..PT8
F-3 F-6
F-5
/
EDIT AUTO TX
Auto TX/RX settings
F-6
EXIT/SET
