Icom IC-7600 Instruction Manual page 77

Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 8 to 11 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 11 to 15 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 15 to 20 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 20 to 22 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 22 to 26 MHz band is selected.
( 8.00 − 11.00)
(11.00 − 15.00)
(15.00 − 20.00)
(20.00 − 22.00)
(22.00 − 26.00)
RECEIVE AND TRANSMIT
10.100 − 10.150 MHz
• Set the frequencies within 8.000 to 11.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display band
width of 5 kHz to a maximum of 500 kHz.
14.000 − 14.350 MHz
• Set the frequencies within 11.000 to 15.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display band
width of 5 kHz to a maximum of 500 kHz.
18.068 − 18.168 MHz
• Set the frequencies within 15.000 to 20.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display band
width of 5 kHz to a maximum of 500 kHz.
21.000 − 21.450 MHz
• Set the frequencies within 20.000 to 22.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display band
width of 5 kHz to a maximum of 500 kHz.
24.890 − 24.990 MHz
• Set the frequencies within 22.000 to 26.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display band
width of 5 kHz to a maximum of 500 kHz.
4
Continues to the next page.
