o RTTY TUNING INDICATOR
Shows the tuning condition in RTTY mode.
!0 MODE INDICATOR
Shows the selected mode.
!1 FREQUENCY READOUTS
Shows the operating frequency.
• Gray characters are used for not-selected readout.
!2 MEMORY CHANNEL READOUTS
Shows the selected memory channel contents
in VFO mode.
Shows the VFO contents in memory mode.
!3 SELECT MEMORY CHANNEL INDICATOR (p. 109)
Indicates the displayed memory channel is set as
a select memory channel.
!4 MULTI-FUNCTION SCREEN
Shows the screens for the multi-function digital
meter, spectrum scope, voice recorder, memory
list, scan, memory keyer, RTTY decoder, PSK de-
coder, IF filter selection or set modes, etc.
!5 VFO/MEMORY CHANNEL INDICATOR (p. 26)
Indicates the VFO mode or selected memory chan-
nel number.
!6 LCD FUNCTION SWITCH GUIDE
Indicates the function of the LCD function switches
([F-1] to [F-6]).
!7 MULTI-FUNCTION SWITCH GUIDE
Indicates the function of the multi-function switches.
!8 TX INDICATOR
appears while transmitting. (p. 36)
" "
Indicates the frequency readout for transmit.
• " " appears during an operating frequency is
not in an amateur band. When the band edge warn-
ing beep is set to "OFF" (p. 31), "
appear.
• Appears on the sub band readout when the split
function is turned ON.
!9 RIT INDICATOR
" " appears when RIT function is in use.
@0 ∂TX INDICATOR
" appears when ∂TX function is in use.
"
@1 RIT/∂TX SHIFT FREQUENCY INDICATOR
Shows the shift frequency for the RIT or ∂TX func-
tion.
@2 NOTCH INDICATOR (p. 83)
"
is in use. This function is available in SSB, CW,
RTTY, PSK and AM modes.
"
in use. This function is available in SSB, AM
and FM modes.
@3 APF/TPF INDICATOR
"
tion is in use. This function is available in CW
mode. (p. 39)
"
tion is in use. This function is available in RTTY
mode. (p. 47)
@4 DUAL WATCH INDICATOR
"
is in use.
" does not
PANEL DESCRIPTION
" appears when the manual notch function
" appears when the auto notch function is
" appears when the audio peak filter func-
" appears when the twin peak filter func-
" appears when the dualwatch function
