Icom IC-7600 Instruction Manual page 52

4
RECEIVE AND TRANSMIT
D Keyer set mode (continued)
Paddle Polarity
This item sets the paddle dot-dash polarity.
Keyer Type
This item selects the keyer type for [ELEC-KEY]
connector on the front panel.
MIC Up/Down Keyer
(Microphone's [UP]/[DN] switches keyer)
This item allows you to set the microphone [UP]/
[DN] switches to be used as a paddle. (The micro-
phone [UP]/[DN] switches do not work as a
'squeeze key.')
45
Normal
• Normal and reverse polarity can be selected.
ELEC-KEY
• Straight key, BUG-KEY and ELEC-KEY can be
selected. (default: ELEC-KEY)
OFF
• ON : [UP]/[DN] switches can be used for CW.
• OFF : [UP]/[DN] switches cannot be used for CW.
NOTE: When "ON" is selected, the frequency and
memory channel cannot be changed using the
[UP]/[DN] switches.
