Icom IC-7600 Instruction Manual page 78

4
RECEIVE AND TRANSMIT
D Scope set mode (continued)
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 26 to 30 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 30 to 45 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 45 to 60 MHz band is selected.
71
(26.00 − 30.00)
(30.00 − 45.00)
(45.00 − 60.00)
28.000 − 28.500 MHz
• Set the frequencies within 26.000 to 30.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display band
width of 5 kHz to a maximum of 500 kHz.
30.000 − 30.500 MHz
• Set the frequencies within 30.000 to 45.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display band
width of 5 kHz to a maximum of 500 kHz.
50.000 − 50.500 MHz
• Set the frequencies within 45.000 to 60.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display band
width of 5 kHz to a maximum of 500 kHz.
