12
CONTROL COMMAND
D Command table (continued)
Cmd. Sub cmd. Data
1A 05 0095 00
01
0096 00
01
0097 00
01
0098 00
01
0099 00
01
02
03
04
0100 00
01
02
03
04
05
06
07
08
09
10
0101 0010 to
0100
0102 00 to 31 Send/read keyboard repeat speed
0103 00
01
0104 00
01
0105 00
01
02
0106 see p. 158 Send/read waveform color for receiving signal
0107 see p. 158 Send/read waveform color for max. hold
0108 00
01
02
0109 00
01
02
0110 00
01
02
0111 00
01
02
0112 00
01
02
155
Description
Voice memory transmission OFF with [F1]–
[F4] on the keyboard
Voice memory transmission ON with [F1]–
[F4] on the keyboard
Memory keyer transmission OFF with [F1]–
[F4] on the keyboard
Memory keyer transmission ON with [F1]–
[F4] on the keyboard
CI-V transceive OFF
CI-V transceive ON
CI-V selection for [USB-B] usage
Decode selection for [USB-B] usage
300 bps selection for decode speed
1200 bps selection for decode speed
4800 bps selection for decode speed
9600 bps selection for decode speed
19200 bps selection for decode speed
English keyboard selection
Japanese keyboard selection
United Kingdom keyboard selection
French keyboard selection
French (Canadian) keyboard selection
German keyboard selection
Portuguese keyboard selection
Portuguese (Brazilian) keyboard selection
Spanish keyboard selection
Spanish (Latin American) keyboard selection
Italian keyboard selection
Send/read keyboard repeat delay
( 0010=100 msec., 0100=1000 msec.;
50 msec. steps)
(00=2.0 cps, 31=30.0 cps)
Scope indication during TX OFF
Scope indication during TX ON
Scope max. hold function OFF
Scope max. hold function ON
Filter center selection for scope center fre-
quency (center mode only)
Carrier point center selection for scope cen-
ter frequency (center mode only)
Carrier point center (Abs. Freq.) selection for
scope center frequency (center mode only)
SLOW selection for scope sweep speed in
±2.5 kHz span
MID selection for scope sweep speed in
±2.5 kHz span
FAST selection for scope sweep speed in
±2.5 kHz span
SLOW selection for scope sweep speed in
±5 kHz span
MID selection for scope sweep speed in
±5 kHz span
FAST selection for scope sweep speed in
±5 kHz span
SLOW selection for scope sweep speed in
±10 kHz span
MID selection for scope sweep speed in
±10 kHz span
FAST selection for scope sweep speed in
±10 kHz span
SLOW selection for scope sweep speed in
±25 kHz span
MID selection for scope sweep speed in
±25 kHz span
FAST selection for scope sweep speed in
±25 kHz span
SLOW selection for scope sweep speed in
±50 kHz span
MID selection for scope sweep speed in
±50 kHz span
FAST selection for scope sweep speed in
±50 kHz span
Cmd. Sub cmd. Data
1A 05 0113 00 SLOW selection for scope sweep speed in
±100 kHz span
01 MID selection for scope sweep speed in
±100 kHz span
02 FAST selection for scope sweep speed in
±100 kHz span
0114 00 SLOW selection for scope sweep speed in
±250 kHz span
01 MID selection for scope sweep speed in
±250 kHz span
02 FAST selection for scope sweep speed in
±250 kHz span
0115 see p. 158 Scope edge frequencies for 0.03 to 1.60 MHz
band
0116 see p. 158 Scope edge frequencies for 1.60 MHz to
2.00 MHz band
0117 see p. 158 Scope edge frequencies for 2.00 MHz to
6.00 MHz band
0118 see p. 158 Scope edge frequencies for 6.00 MHz to
8.00 MHz band
0119 see p. 158 Scope edge frequencies for 8.00 MHz to
11.00 MHz band
0120 see p. 158 Scope edge frequencies for 11.00 MHz to
15.00 MHz band
0121 see p. 158 Scope edge frequencies for 15.00 MHz to
20.00 MHz band
0122 see p. 158 Scope edge frequencies for 20.00 MHz to
22.00 MHz band
0123 see p. 158 Scope edge frequencies for 22.00 MHz to
26.00 MHz band
0124 see p. 158 Scope edge frequencies for 26.00 MHz to
30.00 MHz band
0125 see p. 158 Scope edge frequencies for 30.00 MHz to
45.00 MHz band
0126 see p. 158 Scope edge frequencies for 45.00 MHz to
60.00 MHz band
0127 00 Auto monitor function OFF during voice
memory transmission
01 Auto monitor function ON during voice mem-
ory transmission
0128 03 to 10 Send/read voice memory short play time
(03=3 sec., 10=10 sec.)
0129 05 to 15 Send/read voice memory normal record time
(05=5 sec., 15=15 sec.)
0130 00 Normal selection for contest number style
01 "190 ANO" selection for contest number style
02 "190 ANT" selection for contest number style
03 "90 NO" selection for contest number style
04 "90 NT" selection for contest number style
0131 01 M1 selection for count up trigger channel
02 M2 selection for count up trigger channel
03 M3 selection for count up trigger channel
04 M4 selection for count up trigger channel
0132 0001 to Send/read present number
9999 (0001=1, 9999=9999)
0133 01 to 60 Send/read CW keyer repeat time
(01=1 sec., 60=60 sec.)
0134 28 to 45 Send/read CW keyer dot/dash ratio
(28=1:1:2.8, 45=1:1:4.5)
0135 00 2 msec. selection for rise time of the transmit-
ted CW envelope
01 4 msec. selection for rise time of the transmit-
ted CW envelope
02 6 msec. selection for rise time of the transmit-
ted CW envelope
03 8 msec. selection for rise time of the transmit-
ted CW envelope
04 10 msec. selection for rise time of the trans-
mitted CW envelope
0136 00 Normal selection for paddle polarity
01 Reverse selection for paddle polarity
0137 00 Straight selection for keyer type
01 BUG-KEY selection for keyer type
02 ELEC-KEY selection for keyer type
0138 00 Mic. up/down keyer function OFF
01 Mic. up/down keyer function ON
Description
