TABLE B–1
Description Pin
1 G round
2 G round
3 G round
4 G round
5 G round
6 G round
7 G round
8 G round
9 G round
10 Ground
11 Ground
12 Ground
13 N/C
14 Ground
15 Ground
16 Ground
17 Ground
18 Ground
1
1. All signals are active low.
SPARCstation 5 Service Manual ♦ Revision A, August 1994
138
1
Pinout Signals for External SCSI Connector
Description Pin
19 Ground
20 Ground
21 Ground
22 Ground
23 Ground
24 Ground
25 Ground
26 Data 0
27 Data 1
28 Data 2
29 Data 3
30 Data 4
31 Data 5
32 Data 6
33 Data 7
34 Parity
35 Ground
36 Ground
Description Pin
37 Ground
38 Termpower
39 Ground
40 Ground
41 Attention
42 Ground
43 Busy
44 Acknowledge
45 Reset
46 Message
47 Select
48 Control data
49 Request
50 Direction
