6. Plug the power supply connector into the system board.
See Figure 8–1.
7. Remove the wrist strap from your wrist and then from the power supply.
8. Replace the cover.
See "Replacing the Cover" on page 50.
9. Plug in the power cord to the system unit and the wall outlet.
10. Power on the system.
See "Powering On the System" on page 46.

Power LED

The system power LED is located at one end of the speaker/LED cable. An in-line
connector in the cable facilitates removal of the LED without having to remove the
entire speaker/LED cable.

Removing the Power LED

1. Shut down and power off the system.
See "Powering Off the System" on page 43.
2. Remove the cover and attach a wrist strap.
See Chapter 7.
3. Remove the CD-ROM drive (if present).
See "Removing the CD-ROM Drive" on page 71.
4. Disconnect the in-line connector in the speaker/LED cable.
See Figure 8–3.
57
Major Subassemblies
