In online mode whatever is stored is printed.
Incoming Printing-Offline
Step 1: Set the filters as per the need
Step 2: Give the command to download the Incoming SMDR data.
Various filters can be used to generate a report. These commands enable the user to select the type of calls to
be printed viz. Normal calls, DID calls, Unanswered calls, Long Speech Duration calls. It is also possible to print
the calls with desirable combination like Long Speech Duration calls and DID calls.
It is possible to sort on one or more keys and generate a report.
A summary of the report is printed at the end of each report.
Filter
Set default filters
Normal Calls
DID Calls
Unanswered Calls
DID Unanswered Calls
All Calls
Calls received by a Station
Calls received by a range of Station
Calls received by all the Station
Calls received on a trunk
Calls received on a range of trunks
Calls received on all trunk
Calls received on a date
Calls received on a range of dates
Calls received on all date
Calls received at a time
Calls received between the range of time 1584-2-Hour-Minute-Hour-Minute
Calls received at any time
Call unanswered for duration
Calls with speech duration
Use following command to start printing of SMDR Incoming calls report:
1580
Use following command to start printing of SMDR Outgoing calls report:
1540
A sample printout of SMDR reports is attached herewith for ready reference.
Vision System Manual
Command
1506-#
(Immediately printing OFF and All Incoming calls are printed)
1591 - Flag
1592 - Flag
1593 - Flag
1594 - Flag
1595 - Flag
1581-1-Station
1581-2-Station-Station
1581-*
1582-1-Trunk
1582-2-Trunk-Trunk
1582-*
1583-1-Date-Month-Year
1583-2-Date-Month-Year-Date-Month-Year
1583-*
1584-1-Hour-Minute
1584-*
(Hour-Minute is in HH:MM, 24 hour format)
1585-Minutes-Seconds
1586-Minutes-Seconds
(Minutes is from 00 to 59, Seconds is from 00 to 59)
