What's this?
Vision offers flexibility to assign a number of your choice to a station. This code is called flexible number. For
example, to access first station having software port 00, one has to dial 21. It is possible to change this code to
any other number of your choice.
The system loads default access codes (flexible numbers) to all the stations on first power ON. Later on the
stations can be assigned desired flexible numbers.
How to program?
Use following command to program the flexible number for a station:
4201-1-Station-Flexible Number-#*
Where,
Station is from 00 to 08.
Flexible Number can be of 1, 2, 3 or 4 digits.
Terminate the command using #* is flexible number is of less than four digits.
Use following command to default the flexible numbers of all the stations:
4201-*-#
A typical table of default flexible numbers looks like:
Software Port Flexible Number
00
01
02
03
04
05
06
07
08
Use following command to clear the flexible numbers of all the stations:
4201-*-0
Example:
Software port 00 to 03 should be assigned flexible numbers as 31 to 34 and software port from 04 to 07 should
be assigned flexible numbers as 21 to 24.
4201-1-00-31#*
4201-1-01-32#*
4201-1-02-33#*
4201-1-03-34#*
4201-1-04-21#*
4201-1-05-22#*
4201-1-06-23#*
4201-1-07-24#*
Important Points:
• Flexible numbers are the codes dialed from dial phase to call another station. These flexible numbers should
be unique and should not match with any other station or any of the features available from the dial phase.
• It is possible to have single digit, 2-digit, 3-digit and 4-digit flexible numbers.
114

Flexible Numbers

21
22
23
24
25
26
27
28
29
