Output Loader Files - Analog Devices VisualDSP++ 3.5 Manual

Diagrams in this section illustrate boot streams utilized by the
ADSP-BF535 processor's boot kernel. The elements are covered as
follows.
• "Output Loader Files" on page 2-9
• "Global Headers" on page 2-12
• "Block Headers" on page 2-13
• "Flags" on page 2-13

Output Loader Files

An output loader file for 8-bit PROM/Flash booting and 8-/16-bit
addressable SPI booting without the second-stage loader:
Output .LDR File
4-Byte Header for
Byte Count (N)
Byte 0
Byte 1
Byte 2
Byte 3
........
........
........
D7
VisualDSP++ Loader Manual
for 16-Bit Processors
Blackfin Processor Loader/Splitter
Byte Count for
Application Code
Application
Code
D0
2-9
