ADSP-219x DSP Booting

ADSP-219x DSP Booting
The ADSP-219x loader/splitter creates a boot stream, non-boot stream, or
combinational output. The program accepts one executable file (
input and generates one file (.
Upon powerup, a ADSP-219x DSP can be booted from the EPROM,
UART, SPI, or Host port. Booting can also be initiated in software after
. Refer to the Application Note EE-131 and your DSP's data sheet or
RESET
Hardware Reference manual for more information on system configura-
tion, peripherals, registers, and operating modes.
You can run the loader/splitter program from a command-line or from
within the VisualDSP++ IDDE. When working within the VisualDSP++,
specify options via the Load page of the Project Options dialog box.
!
Option setting on the Load page correspond to switches displayed
on the command line.
To ensure correct operation of the loader, familiarize yourself with:
• "ADSP-219x DSP Boot Modes" on page 3-3
• "ADSP-219x DSP Boot Kernel" on page 3-4
• "ADSP-219x DSP Boot Streams" on page 3-4
• "Parallel EPROM Boot Streams" on page 3-4
• "Host Booting" on page 3-10
• "UART Booting" on page 3-11
• "Serial EPROM Booting" on page 3-12
• "No-booting" on page 3-12
