The boot ROM does not support booting to core A scratch mem-
ory (
0xFFB0 0000
(
0xFF70 0000
to runtime should not be placed in scratch memory.

ADSP-BF561 Processor Initialization Blocks

An initialization block or a second-stage loader must be used to initialize
the SDRAM memory of the ADSP-BF561 processor before any instruc-
tions or data are loaded into it.
The initialization block is identified by a bit in the flag word of the
10-byte block header. When the boot ROM encounters an initialization
block in the boot stream, it loads the block and executes it immediately.
The initialization block must save and restore registers and return to the
boot ROM, so the boot ROM can load the rest of the blocks. For more
details, see "Flags of Block Header" on page
Both the initialization block and second stage loader can be used to force
the boot ROM to load a specific
the boot ROM stores multiple executable files. The initialization block
can manipulate the
memory pointers for Flash/PROM or SPI memory boot, respectively.
After the processor returns from the initialization block, the boot ROM
continues to load blocks from the location specified in the
ter, which can be any
starting locations of specific executables within external memory. The
or register must point to the 10-byte count header, as illustrated in
R3
"ADSP-BF531/BF532/BF533 and ADSP-BF561 Multiple .DXE Boot-
ing" on page 2-37.
