Table 3-3. EPROM Image—Two Segments Only
Address range
0x000000 - 0x00FFFF
0x010000 - 0x01FFFF
Typically, the loader utility generates an Intel hex-32 file, which is read-
able by most EPROMs. If the image must be post-processed, the loader
may also generate ASCII files.
DM Example:
ext_data { TYPE(DM ROM) START(0x010000) END(0x010003) WIDTH(8) }
The above DM segment results in the following code.
00010000 // 32-bit logical address field
00000004 // 32-bit logical length field
00020201 // 32-bit control word: 2x address multiply
// 02 bytes logical width, 01 byte physical width
00000000 // reserved
1234 // 1st data word, DM data is 16 bits
5678
9ABC
DEF0 // 4th (last) data word
CRC16 // optional, controlled by the -checksum switch
PM Example:
ext_code { TYPE(PM ROM) START(0x040000) END(0x040007) WIDTH(16)}
The above PM segment results in the following code.
00040000 // 32-bit logical address field
00000008 // 32-bit logical length field
00020302 // 32-bit control word: 2x address multiply
// 03 bytes logical width, 02 bytes physical width
00000000 // reserved
123456 // 1st data word, PM data is 16 bits
VisualDSP++ Loader Manual
for 16-Bit Processors
ADSP-219x DSP Loader/Splitter
Purpose
seg_ext_data
seg_ext_code
3-15
