Network requirements

As shown in Figure 331, a local SSH connection is established between the

host (SSH client) and the switch (SSH server) for secure data exchange.

Password authentication is required.

Network diagram

Figure 331 Network diagram for SSH server configuration (using password

authentication)

192.168.0.2/24

Configuration procedure

Configure the SSH server

# Generate RSA and DSA key pairs and enable the SSH server.

<Switch> system-view

[Switch] public-key local create rsa

[Switch] public-key local create dsa

[Switch] ssh server enable

# Configure an IP address for VLAN interface 1. This address will serve as the

destination for the SSH client in connecting the server.

[Switch] interface vlan-interface 1

[Switch-Vlan-interface1] ip address 192.168.1.40 255.255.255.0

[Switch-Vlan-interface1] quit

# Set the authentication mode for the user interface to AAA.

[Switch] user-interface vty 0 4

[Switch-ui-vty0-4] authentication-mode scheme

# Enable the user interface to support SSH.

[Switch-ui-vty0-4] protocol inbound ssh

[Switch-ui-vty0-4] quit
