■ Power ON
➥ Push and hold [ ] for 1 sec. to turn power ON.
• Push and hold [ ] for 1 sec. to turn power OFF.
The voltage indication can be skipped in the Initial set mode
(p. 61).

BASIC OPERATION

■ Setting audio volume

➥ Rotate [VOL] to adjust the audio level.
• If squelch is closed, push and hold [MONI](BAND) while setting
the audio level.
• The display shows the volume level while setting.
[VOL]
The beep level is adjusted in the Initial set mode (p. 60).
4
Volume level
Minimum setting (no audio)
Maximum setting
