Options - Icom IC-T70A Instruction Manual

• BP-263
battery case
Battery case for LR6 (AA) × 6 alkaline batteries.
• BP-264
-
ni mh battery pack
7.2 V/1400 mAh (Typ.) Ni-MH battery pack. Battery life:
11.5 hrs. (approx.; VHF, FM, high power, Tx : Rx : Standby
= 5:5:90)
Same as supplied one. (Not supplied with some version.)
• BP-265 -
li ion battery pack
7.4 V/1900 mAh (Min.)/2000 mAh (Typ.) Lithium Ion battery
pack. Battery life: 16 hrs. (approx.; VHF, FM, high power, Tx
: Rx : Standby = 5:5:90)
• BC-167S
battery charger
For regular charging of the Ni-MH battery pack, BP-264.
Same as supplied one. (Not supplied with some version.)
• BC-191 +BC-123S
desktop charger
For rapid charging of the Ni-MH battery pack, BP-264. An
AC adapter may be supplied with the charger, depending
on the version.
Charging time: Approx. 2 hours for the BP-264.
• BC-193 +BC-123S
desktop charger
For rapid charging of the Li-Ion battery pack, BP-265. An
AC adapter may be supplied with the charger, depending
on the version.
Charging time: Approx. 2.5 hours for the BP-265.
Options may vary by versions.
Please ask your dealer for details.
• BC-192
ac adapter
ac adapter
• MB-130

OPTIONS

BC-191/BC-193 common specifications
Power supply voltage 12 to 16 V DC or the specified
Icom AC adapter (BC-123S)
Charging temp. range +10°C to +40°C;
+50°F to +104°F
Dimensions 87.5(W)×53.7(H)×72.8(D) mm;
(projections not included) 3
+BC-147S/BC-206S
desktop charger
For regular charging of the Ni-MH battery pack, BP-264. An
AC adapter may be supplied with the charger, depending
on the version.
Charging time: Approx. 16 hours for the BP-264.
BC-192 specifications
Power supply voltage* 12 to 16 V DC or the specified
Icom AC adapter (BC-147S/
BC-206S)
Charging temp. range 0°C to +45°C;
32°F to +113°F
Dimensions 87.5(W)×53.7(H)×72.8(D) mm;
(projections not included)
3
* Charging time differs depending on the input voltage.
12 V : Approx. 36 hours
13.8 V : Approx. 21 hours
16 V : Approx. 16 hours
vehicle charger bracket
Vehicle mounting bracket for the BC-191, BC-192 and BC-
193 battery chargers.
13
7 ⁄ (W)×2 1 ⁄ (H)×2 7 ⁄ (D) in
16 8 8
ac adapter
7 1 7
⁄ (W)×2 ⁄ (H)×2 ⁄ (D) in
16 8 8
