INSTRUCTION MANUAL
144 MHz FM TRANSCEIVER
iT2H
This device complies with Part 15 of the FCC rules. Operation is sub-
ject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-T2H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Icom IC-T2H

Summary of Contents for Icom IC-T2H

  • Page 1 INSTRUCTION MANUAL 144 MHz FM TRANSCEIVER iT2H This device complies with Part 15 of the FCC rules. Operation is sub- ject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Important

    If disregarded, inconvenience only. No risk NOTE of personal injury, fire or electric shock. Versions of the IC-T2H which display the “CE” symbol on the serial number seal, comply with the ETSI specifi- cation prETS300 684 (EMC product standard for Com- mercially Available Amateur Radio Equipment).

  • Page 3: Supplied Accessories

    Ni-Cd batteries will become ex- hausted. For USA only: Caution: Changes or modifications to this transceiver, not ex- pressly approved by Icom Inc., could void your authority to operate this transceiver under FCC regulations. SUPPLIED ACCESSORIES Accessories included with the transceiver: ➀...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS IMPORTANT ... ii EXPLICIT DEFINITIONS ... ii CAUTIONS ... ii SUPPLIED ACCESSORIES ... iii TABLE OF CONTENTS ... iv 1 ACCESSORY ATTACHMENT ... 1 2 PANEL DESCRIPTION ... 2–7 I Switches, controls, keys and connectors ... 2 I Customizable keys ...

  • Page 5: Accessory Attachment

    D Antenna Connect the supplied flexible antenna to the antenna con- nector and rotate the antenna clockwise. u CAUTION: Transmitting without an antenna may damage the transceiver. ACCESSORY ATTACHMENT D Belt clip To attach: Slide the belt clip into the plastic loop on the back of the battery case/pack.

  • Page 6: Panel Description

    PANEL DESCRIPTION I Switches, controls, keys and connectors [SP/MIC] [PWR/VOL] [PTT] [UP/DOWN] [MONITOR] r[ANTENNA] t[CHARGE] y[TX] o[DIAL SELECT] !0 - !7 [CUSTOMIZABLE KEYS] [GUIDE] [DIGIT KEYS] [MHz KEY]...
  • Page 7 q PTT SWITCH [PTT] (p. 12) Push and hold to transmit; release to receive. w POWER/VOLUME CONTROL [PWR/VOL] ➥ Rotate to turn power on and off. ➥ Rotate clockwise to increase volume and counterclock- wise to decrease volume. e EXTERNAL SPEAKER AND MICROPHONE JACKS [SP/MIC] Connect an optional speaker-microphone or headset, if de- sired.
  • Page 8 PANEL DESCRIPTION !0 SQUELCH KEY [SQL]* ➥ Push [SQL], then push [Y]/[Z] one or more times to select squelch level. “AUto”, “Sql 1” to “Sql 8” are available to suit personal preferences and operating conditions. (p. 13) !1 SCAN START/STOP KEY [SC]* ➥...

  • Page 9: I Customizable Keys

    I *Customizable keys [SQL], [SC], [DUP], [H/L], [ V], [ M], [ These keys can be assigned a variety of functions (see p. 32 for a list of available functions). NOTE: In this manual, the customized keys are represented by the “ ”...

  • Page 10: I Function Display

    PANEL DESCRIPTION I Function display q MEMORY MODE INDICATOR (p. 13) Appears while in memory mode. w LOCK INDICATOR (p. 13) Appears while the lock function is activated. e DUPLEX INDICATOR (p. 15) Appears during semi-duplex operation. • “–DUP” appears for minus duplex; “DUP” appears for plus du- plex.

  • Page 11: Panel Description

    ➥ In set mode or initial set mode, indicates the selected item, condition, etc. i BUSY AND S/RF INDICATORS (p. 12) ➥ “BUSY” appears when receiving a signal or when the squelch is open. ➥ The S/RF indicators show the relative signal strength while receiving and the output power when transmitting (2 segments appear for low power and all segments ap- pear for high power).

  • Page 12: Battery Packs

    BATTERY PACKS I Battery pack charging The supplied BP-194 BATTERY CASE Ni-Cd batteries* and can be charged approx. 300 times. Charge the batteries before first operating the transceiver or when they become exhausted. If you want to be able to charge the batteries more than 300 times, the following points should be observed: 1.

  • Page 13: I Charging Connections

    I Charging connections D Regular charging When charging a battery case (pack) attached to the trans- ceiver the power must be OFF. Transceiver with attached battery case (pack) CP-12L (optional) OPC-254L (optional) [CHARGE] black Charging periods: *Not supplied with some versions. 15 hours (w/BP-195) 20 hours (w/BP-196) D Rapid charging with the BC-119...

  • Page 14: I Installing Batteries In The Battery Case

    BATTERY PACKS I Installing batteries in the battery case When using a battery case attached to the transceiver, install 8 AA(R6) size Ni-Cd or alkaline batteries as illustrated below. ➀ Remove the bat- tery case from the transceiver. ➁ Install 8 × R6(AA) size Ni-Cd or alka- line batteries.

  • Page 15: Basic Operation

    I Power ON Rotate [PWR/VOL] clockwise to turn power ON. D Toggling frequency/channel indication mode Channel indication mode is used to simplify operation. In this mode only pre-programmed memory channel numbers are displayed and functions are limited ([PWR/VOL], [ ], [H/L] and [SC] are functional). To toggle between the indication modes: While pushing [Z] + [0], rotate [PWR/VOL] to turn power ON.

  • Page 16: I Dial Select Function

    BASIC OPERATION I Dial select function Use the dial select function to adjust the tuning behaviour or the [Y]/[Z] keys—use 1 MHz tuning when you want to change the frequency in large increments; use the selected tuning step when you want to change the frequency in smaller increments.

  • Page 17: I Selecting A Memory Channel

    ✔ Convenient Monitor function: Push and hold [ ] to listen to weak sig- nals that do not open the squelch; or push [ itor a signal without having to continuously hold [ Squelch control: The transceiver employs a noise pulse count system and therefore, squelch is adjusted automatically when “AUto”...

  • Page 18: I Notes For Set Mode

    BASIC OPERATION I Notes for “Set mode” The following items can be set from VFO mode. Set mode items: Tuning steps (p. 14) Duplex setting (p. 15) Repeater tones (p. 16) Offset frequency (p. 16) Subaudible tones (p. 16) Call channel (p.

  • Page 19: Repeater Operation

    I General When using a repeater, the transmit frequency is shifted from the receive frequency by the offset frequency. It is convenient to program repeater information into memory channels (p. 19). ➀ Set the receive frequency (repeater output frequency). ➁ Push [DUP] one or more times to select –DUP or DUP.

  • Page 20: I Subaudible Tones

    REPEATER OPERATION I Subaudible tones Some repeaters require subaudible tones to be accessed. Subaudible tones are superimposed over your normal signal and must be set in advance. ➀ Push [ V] for 1 sec. to enter set mode. ➁ Push [t] one or more times until “RP”...

  • Page 21: I Auto Repeater Function

    I Auto repeater USING function (USA version only) The USA version automatically activates the repeater settings (duplex, ON/OFF, duplex direction, tone encoder ON/OFF) when the operating frequency falls within or outside of the general repeater output frequency range. The offset and re- peater tone frequencies are not changed by the auto repeater function, reset these frequencies, if necessary.

  • Page 22: Repeater Operation

    REPEATER OPERATION WEATHER CHANNELS (USA version only) There are 10 weather channels for monitor- ing weather channels from the NOAA (Na- tional Oceanographic and Atmospheric Administration) broadcasts. NOTE: The weather channel frequencies are out of the guaranteed frequency range (see p. 38). Intermittent re- ception and/or poor signal quality may occur depending on conditions.

  • Page 23: Memory/Call Programming

    I General The transceiver has 40 memory channels (plus 1 pair of scan edge channels and 1 call channel) for storage of often-used frequencies. In addition, the USA version has 10 marine weather channels (however, these are not programmable). D Memory/call channel contents The following information can be programmed into mem- ory/call channels: •...

  • Page 24: I Programming The Call Channel

    MEMORY/CALL PROGRAMMING I Programming the call channel ➀ Push [ (CALL)] to select call channel mode. • “C” appears. ➁ Push [ (CALL)] for 1 sec. to enter set mode. ➂ Push [t] one or more times until “FR” appears. ➃...

  • Page 25: I Memory Editing

    I Memory editing Memory (call) channel contents can be moved to VFO or to another memory. D Memory/call ➾ VFO ➀ Select the memory (call) channel to be transferred: ➥ Push [ V] ([ (CALL)]) to select memory (call) mode. ➥...

  • Page 26: Dtmf Memory

    DTMF MEMORY I Programming a DTMF code The transceiver has 5 DTMF memory channels (d1 to d5) for storage of often-used DTMF codes of up to 32 digits. ➀ Push [ (DTMF)] to enter DTMF memory. • One of “d1” to “d5” appears. ➁...

  • Page 27: I Dtmf Transmission Speed

    I DTMF USING transmission speed When slow DTMF transmission speeds are required (as for some repeaters), the transceiver’s rate of DTMF transmission can be adjusted. ➀ While pushing [8] + [0], turn power on to enter initial set mode. ➁ Push [t] one or more times until “dt”...

  • Page 28: Scan Operation

    Band condition determines what ac- edge tion the transceiver takes. The IC-T2H has 2 scan resume conditions available as illus- trated at right. Use initial set mode to select the one which best suits your needs.

  • Page 29: I Programmed Scan

    I Programmed scan Programmed scan repeatedly scans between two user-pro- grammed frequencies (memory channels “PA” and “Pb”). This scan is useful for checking for signals within a specific fre- quency range such as repeater output frequencies, etc. ➀ Push [ V] to select VFO mode, if necessary.

  • Page 30: Subaudible Tone Operation

    SUBAUDIBLE TONE OPERATION I Tone squelch D Operation The tone squelch opens only when receiving a signal con- taining a matching subaudible tone. You can silently wait for calls from group members using the same tone. ➀ Set the operating frequency. ➁...

  • Page 31: I Tone Scan

    I Tone scan The transceiver can detect the subaudible tone frequency in a received signal. By monitoring a signal, such as that being transmitted on a repeater input frequency, you can determine the tone frequency required to access the repeater. ➀...

  • Page 32: Other Functions

    OTHER FUNCTIONS I Initial set mode Initial set mode is accessed at power on and allows you to set seldom-changed settings. In this way you can “customize” transceiver operations to suit your preferences and operating style. D Entering initial set mode ➀...

  • Page 33: Power Saver

    D Auto power OFF This item allows you to set a time at which the transceiver will automati- cally turn OFF. The power OFF time can be set to 20, 40, 60 min. or turned off. D LCD backlighting When set to AUTO, display backlight- ing automatically turns on when a key is pushed;...

  • Page 34: I Resetting The Cpu

    OTHER FUNCTIONS D Scan resume condition D Active memory channels This item allows you to adjust the number of active memory channels. Selectable values are 10, 20, 30 or I Resetting the CPU (see p. 24) Reset the CPU before operating the transceiver for the first time, or when the internal CPU malfunctions.

  • Page 35: I Key Customize Mode

    I Key customize mode The functions of the [SQL], [SC], [DUP], [H/L], [ T] and [ L] keys on the IC-T2H can be customized to suit your operating needs. ➀ While pushing [#] + [0], turn power on to enter key customize mode.

  • Page 36: Other Functions

    OTHER FUNCTIONS ASSIGNABLE FUNCTIONS NULL Backlight (LIGHT) Power output ([H/L]) Scan start/stop ([SC]) DTMF memory* (DTMF) DTMF re-dial (RE-DIAL) Lock function Beep tones (BEEP) VFO/memory Tone setting Tone scan (T SCAN) Tuning step (TS) Squelch level ([SQL]) WX channels* (WX) ANI code* (ANI CODE) Duplex setting...

  • Page 37: Ani Operation

    In order to use the IC-T2H’s ANI function, cloning is neces- sary via a PC using the optional CS-T2 Using this software, the transceiver’s individual ANI code, group codes, ANI time-out timer and other settings related to ANI operation can be set.

  • Page 38: I Operation

    ANI OPERATION I Operation D Calling a specific station ➀ Turn power on and set the [VOL] control to the 10 or 12 o’- clock position. ➁ Push the [Y]/[Z] keys to set the desired channel. • “ ” appears when the ANI function has been programmed via cloning.

  • Page 39: Ani Operation

    D Calling group stations ➀ Turn power on, then select the desired group channel. ➁ Enter the 3-digit ANI code including the group code “D”— the transceiver calls the desired station automatically. • The transceiver transmits the pre-programmed selective code. •...

  • Page 40: Cloning

    D Cloning using a PC Data can be cloned to and from a PC (IBM compatible) using the optional CS-T2 POWER ON IC-T2H’s ANI mode. Consult the CS-T2 with adapter plugs HELP message for details. D Cloning error NOTE: DO NOT push the [PTT] on the slave transceiver during cloning.

  • Page 41: Troubleshooting

    If your transceiver seems to be malfunctioning, please check the following points before sending it to a service center. PROBLEM POSSIBLE CAUSE No power comes on. • The battery is exhausted. (A slight current flows in the circuits even when the power is off.) Transmitting is impossible.

  • Page 42: Specifications

    SPECIFICATIONS GENERAL • Frequency coverage • Operating mode • Frequency stability • Antenna impedance • Power supply • Current drain ( at 9.6 V; typ.) Rx Rated audio Power saved Standby • Scan speed VFO mode Memory channel mode • Usable temperature range •...

  • Page 43: Options

    Remote control capability (see p. 28 for details) D Others CS-T2 CLONING SOFTWARE Allows you to clone the memory contents of an IC-T2H transceiver between transceivers or to a PC for editing. OPC-474 CLONING CABLE For transceiver-to-transceiver cloning. OPC-478 CLONING CABLE For transceiver-to-PC cloning.

  • Page 44: Mode Arrangement

    MODE ARRANGEMENT VFO MODE [ (CALL)] [ (CALL)] CALL MODE CHANNEL INDICATION MODE See p. 11 for details AT POWER ON VIA CLONING Refer to the CS-T2 cloning software See p. 33 for details read me file for details. V]/[ (CALL)] for 1 sec. V]/[ (CALL)] momentarily NOTE: indicates one of the...

  • Page 45: Mode Arrangement

    TO ENTER at power ON ➀ Push a key to program—currently assigned function is displayed. ➁ Push the [ ]/[ ] keys to select the desired function. (See p. 32 for a list of available functions.) ➂ Push the selected key for 1 sec. to program the function.

  • Page 46: Memo

    MEMO...

  • Page 47: Memo

    MEMO...
  • Page 48 MEMO...
  • Page 49 MEMO...
  • Page 50 Count on us! A-5530H-1EX Printed in Japan 6-9-16 Kamihigashi, Hirano-ku, Osaka 547-0002 Japan © 1998 Icom Inc.
