D Regular charging with the BC-192
The BC-192 provides regular charging of only the BP-264 Ni-MH
battery pack. Never use it to charge any other battery pack.
Charging time (with the BC-147S/BC-206S): Approx. 16 hours
The following item is additionally required:
• The AC adapter BC-147S/BC-206S (not supplied with some ver-
sions) or the OPC-515L DC power cable.
BC-147S/BC-206S
Battery pack
The
optional
OPC-515L (for
a DC power
source) can be
used instead of
Charging time period differs
the AC adapter.
depending on the input voltage.
12 V : Approx. 36 hours
13.8 V : Approx. 21 hours
16 V : Approx. 16 hours
Transceiver
Turn power OFF
Screws*
(Self tapping screw:
M3.5 × at least 30 mm)
*Purchase separately.
Using
screws
is
recommended
to
secure the charger.
Charge indicator
• Lights green while charging.
NOTE:
The charger indicator will
not go out even after a
battery pack is fully charged.
BATTERY CHARGING
D Rapid charging with the BC-193
The BC-193 provides rapid charging of only the BP-265 Li-
Ion battery pack. Never use it to charge any other battery
pack.
Charging time: Approx. 2.5 hours
The following item is additionally required:
• The AC adapter BC-123S (not supplied with some versions) or the
OPC-515L or CP-23L DC power cable.
Battery pack
BC-123S
The optional OPC-
515L (for a DC power
Charge indicator
source) can be used
• Lights orange : While charging
instead of the AC
• Lights green : Charging is completed
adapter.
• Blinks red
3
3
Transceiver
Turn power OFF
Screws*
(Self tapping screw:
M3.5 × at least 30 mm)
*Purchase separately.
Using
screws
is
recommended
to
secure the charger.
: Charging error has occured
14
