D Tuning step (TS)

Selects the tuning step between 5, 10, 12.5, 15, 20, 25, 30,

50, 100, 125 and 200 kHz for the dial operation.

The default value may differ, depending on the selected fre-

quency band (before accessing the Set mode) and the trans-

ceiver version.

D Frequency offset (OFFSET)

Sets the frequency offset for duplex operation (repeater)

within the range of 0 to 59.995 MHz.

The default value may differ, depending on the selected fre-

quency band (before accessing the Set mode) and trans-

ceiver version.

The selected tuning step in the VFO mode is used when

setting the frequency offset.

5.0 kHz tuning step

0.600 MHz setting

D Reverse duplex function (DUP.REV)

Turns the reverse duplex function ON or OFF. (default: OFF)

D Operating mode (MODE)

Sets the operating mode between "WIdE" (FM mode) and

"nARROW" (FM-N mode).

D Weather alert (WX.ALT)

Turns the weather alert function ON or OFF. (p. 72)

SET MODES

Reverse function is OFF

(default: WIdE)

FM mode setting

U.S.A. version only

(default: OFF)
