Extent of removal Order
1
2
3
4
1
5
6
7
2
8
9
10
11
12
13
14
15
Part name
Locking tie
Taillight coupler
Starting circuit cut-off relay coupler
Plastic band
Clamp (air filter joint)
Rear frame
Bolt (rear shock absorber-relay arm)
Bolt (rear shock absorber-frame)
Rear shock absorber
Locknut
Adjuster
Lower spring guide
Upper spring guide
Spring (rear shock absorber)
Bearing
5 - 143
REAR SHOCK ABSORBER
Q'ty
2
1
1
2
1 Only loosening.
1
1 Hold the swingarm.
1
1
1
Only loosening.
1
1
1
1
2 Refer to "REMOVAL POINTS".
CHAS
Remarks
