Avocent MERGEPOINT 53XX SP MANAGER Installer/User Manual page 90

76 MergePoint Service Processor Manager SP53XX Installer/User Guide
To open the DirectCommand connection list window:
1. In the side navigation bar, click a target device name.
2. Click the DirectCommand tab.
3. Click Connect.
4. From the Top Option bar, click Connected. The DirectCommand connection list
window appears.
5. You may view all of the currently active DirectCommand connections with their target device
IP addresses here.
To enter the Browser Session interface:
1. In the side navigation bar, click a target device name.
2. Click the DirectCommand tab.
3. If DirectCommand is not already connected, click Connect.
4. Click Browser Session.
-or-
From the Top Option bar, click Connected. The DirectCommand connection list window
appears. Select the alias of the desired target device from the window, then click
DirectCommand.
To enter the Browser Session (Auto Login) interface:
1. In the side navigation bar, click a target device name.
2. Click the DirectCommand tab.
3. If DirectCommand is not already connected, click Connect.
4. Click Browser Session (Auto Login).
-or-
From the Top Option bar, click Connected. Select the alias of the desired target device, then
click Browser Session.
To enter the vKVM Session interface:
1. In the side navigation bar, click a target device name.
2. Click the DirectCommand tab.
3. If DirectCommand is not already connected, click Connect.
4. Click the vKVM Session link.
-or-
From the Top Option bar, click Connected. Select the alias of the desired target device, then
click vKVM Session.
