3. Configure the interface, protocol, source IP, source port destination IP and destination port
filtering options as needed.
4. Click Start.
NOTE: You must stop the debug manually; otherwise the debug process continues indefinitely. When the trace
file size reaches to the maximum size (preset maximum is 1M), the trace file will be rewritten.
To stop the network debug:
1. Click the Diagnostic tab.
2. In the top navigation bar, click Debug.
3. Click Stop. Once stopped, you may download the trace file.
To download the trace file:
1. Click the Diagnostic tab.
2. In the top navigation bar, click Debug.
3. Click Download. All trace data is compiled and a download link appears next to the Download
button.
4. Click the Download link to save the trace file.
NOTE: The trace file is stored on the server until the next debug starts.
NOTE: Diagnostics may also be configured using the CLI utility. See Diagnostics CLI command -tcpdump on
page 123.

Appliance Operations

MergePoint SP manager sessions

By selecting the System - Sessions option, the Admin user can view and manage MergePoint SP
manager sessions and SSH/Telnet sessions.
Current MergePoint SP manager sessions are listed in the upper table of the session window.
To activate the session window and view a session:
Click System - Session. The current user session will be listed in green text.
To delete a session:
1. Click System – Session.
2. Select the session you wish to delete and click Delete.

Upgrade

Visit
www.avocent.com
firmware files onto your workstation.
to download and save the latest MergePoint SP manager upgrade
Chapter 3: Operations 63
