42 MergePoint Service Processor Manager SP53XX Installer/User Guide
To turn on, turn off or reset all selected target devices:
1. Click the Targets tab, then click Targets in the top navigation bar. The Targets window
appears.
2. In the Managed Targets list, select the target device(s) you wish to manage and click the
desired power operation.
To view and control the chassis status (LED):
1. In the side navigation bar, click a target device name.
2. Click the System tab.
3. In the top navigation bar, click Chassis. The Chassis Information window appears and the
current chassis status of the target device is displayed.
4. To modify how often the LED flashes, enter the number of seconds in the Indicator ON
Seconds field.
5. To change the chassis indicator status of the target device, complete any of the following steps:
To turn the LED on and leave the LED flashing for a specified number of seconds, click
Indicator On Seconds. The LED flashes for the time specified in the Indicator On seconds
field.
- or -
To turn the LED on and leave the LED flashing permanently, click Indictor On.
- or -
To turn the LED off, click Indicator Off.
6. Click Apply.
To perform a cold reset on a target device:
1. In the side navigation bar, click a target device name.
2. Click the System tab.
3. In the top navigation bar, click Advanced Tools. The Setting window appears.
4. Click Cold Reset to perform a cold reset on the selected target device. A message will appear
to indicate the success status of the cold reset.
To reboot the MergePoint SP manager:
Click System – Setting - Apply Reboot.

Performing Target Device Group Operations

Admin users may perform the following for all target devices in a group at the same time: turn on,
turn off or reset the devices, turn the target device LED indicators on or off, and configure time,
Platform Event Trap (PET) alert settings, usernames and passwords.
