40 MergePoint Service Processor Manager SP53XX Installer/User Guide
NOTE: When following any of the MergePoint SP manager configuration procedures in this document, start by
clicking the name of the MergePoint SP manager in the side navigation bar. Click Apply to save changes. To
cancel changes, click Back to return to the previous screen or click another navigation element, such as the
name of a tab, window or target.
1
1
2

Figure 3.1: MergePoint SP Manager Web Interface

Table 3.1: MergePoint SP Manager Web Interface Descriptions

Number Window Area
1 Top Option Bar
2 Side Navigation Bar
3 Tab Bar
4 Top Navigation Bar
Description
Use the top option bar to log out or access online help. If any alerts
occur, a yellow icon is displayed. The name of the logged in user
appears on the left side of the top option bar.
Use the side navigation bar to select the appliance or target devices and
access or edit corresponding information in the content area.
Use the tab bar to display and manage the MergePoint SP manager,
managed groups and target devices.
The selections in the top navigation bar vary, depending on the active
tab in the tab bar.
3
4
5
