60 MergePoint Service Processor Manager SP53XX Installer/User Guide
Enter
<Ctrl> + <[mouse right-click]>
terminal settings, define tunnels and modify other settings. For example, to change the terminal
emulation program, select Settings - Terminal - Terminal Type.
To view SoL history:
1. In the side navigation bar, click a target device name.
2. Click the Console tab.
3. In the top navigation bar, click Device Console. The Device Console window opens.
4. Click SoL History to display all the commands entered in SoL mode and their output.
NOTE: Dell DRAC/MC target devices do not support SoL history.
To replay SoL:
1. In the side navigation bar, click a target device name.
2. Click the Console tab.
3. In the top navigation bar, click Device Console. The Device Console window opens.
4. Click SoL Replay to replay SoL actions and results, including the BIOS result. Click and drag
the speed bar to control replay speed.
Service processor console
You can also access the service processor console of the selected target device. After accessing the
service processor console, you launch the management application from the service processor's
command line.
To access service processor console:
1. In the side navigation bar, click a target device name.
2. Click the Console tab.
3. In the top navigation bar, click SP Console.The SP Console window opens.
4. Click Connect.
NOTE: After connecting to the service processor console, you can run any corresponding service processor
console commands.
Telnet console
You can also access the Telnet console of the selected target device. After accessing the Telnet
console, you can launch the management application from the service processor's command line.
To access the Telnet console:
1. In the side navigation bar, click a target device name.
2. Click the Console tab.
3. In the top navigation bar, click Telnet Console.The Telnet Console window opens.
for the MindTerm menu. From the menu, you can configure
