Avocent MERGEPOINT 53XX SP MANAGER Installer/User Manual page 149

Managing power on the MergePoint SP manager
To manage power on the MergePoint SP manager, enter the stop or reset command with the
MergePoint SP manager target: /admin1/map1.
To power off MergePoint SP manager:
Power off MergePoint SP manager by entering the stop command, followed by the target:
/admin1-> stop /map1
To reset MergePoint SP manager:
Reset MergePoint SP manager by entering the reset command, followed by the target:
/admin1-> reset /map1
Managing servers on the side navigation bar
The /admin1/map1/nodemanagesvc1 target is for managing the servers on the side navigation bar
of MergePoint SP manager. The /admin1/map1 target is associated with /admin1/map1/
nodemanagesvc1 target. You can add a server and delete a server from the side navigation bar.
Supported commands are: create and delete.
To add a server to the side navigation bar:
Enter the create command with OtherIdentifyingInfo property: create system*
OtherIdentifyingInfo="user,passwd,ip,alias,kg,databuf,sptype"
For example, to add server 172.26.25.64 with the username "root" and password "calvin":
/admin1-> create system*
OtherIdentifyingInfo="root,calvin,172.26.25.64,test,,0,3"
NOTE: The valid "sptype" value and the service processor type which it stands for are:
sptype = 1 means IPMI
sptype = 2 means iLO
sptype =3 means DRAC
sptype = 4 means HP IPMI
sptype = 6 means DRAC/MC
sptype = 7 means IBM BladeCenter
sptype = 8 means SPs which can only be access by Telnet or SSH
sptype = 9 means ILOM
sptype = 10 means RSAII
sptype = 12 means HPBladeSsytemr
To set an unmanaged server as a managed server:
Enter the set command with OtherIdentifyingInfo property: set system[n]
OtherIdentifyingInfo="user,passwd, ,alias,kg,databuf,sptype"
For example, to add server 172.26.26.16 with the username "USERID" and password
"PASSW0RD":
Chapter 8: Using SMASH Command Line Management 135
