50 MergePoint Service Processor Manager SP53XX Installer/User Guide
2. Click the Configuration tab.
3. In the top navigation bar, click Event Destination. The PET Setting window appears.
4. Select Enable or Disable for sending or not sending alerts when specific events occur.
5. In the Community String field, enter the value to be displayed in the community string field of
the PET trap.
6. Enter up to four IP addresses in the Alert Destination IP Address fields.
7. Click Apply.
NOTE: To configure the MergePoint SP manager to receive alerts for the target device, make sure to enter the
IP address of the MergePoint SP manager in one of the Alert Destination IP Address fields.

Schedules

Tasks can be scheduled to simultaneously turn on or off or reset the power on all target devices in
a group. The results of each scheduled task display in the Schedule Task Result list in the Schedule
Task window. To clear this list, click Clear All.

Schedule a task (Admin users only)

To schedule a task:
1. Click System - Schedules.
2. Click Add and select Group to display all device groups or Targets to display all target devices.
3. Specify the following information:
a. Select the group(s) or target(s) for which you wish to schedule tasks.
b. Type the task name into the Task Name field.
c. From the Operate drop-down menu, select: Power On, Power Off or Power Reset.
d. From the Schedule Task drop-down menu, select: Once, Daily, Weekly or Monthly.
e. From the Time menu(s), select the day, hour and minute for the task to occur. Options in
the Time menus vary according to your selections.
f. Choose Once, Daily, Weekly or Monthly, then specify the task schedule accordingly.
4. Click Apply.
To edit a scheduled task:
1. Click System - Schedules.
2. Click Edit next to the task you wish to edit and follow the on-screen instructions.
To delete a scheduled task:
1. Click System - Schedules.
2. Select the task to delete and click Delete.
