44 MergePoint Service Processor Manager SP53XX Installer/User Guide
2. In the Group list, select the group(s) you wish to modify and click PET Setting.
- or -
Click a group name from the explorer tree in the side navigation bar, click Action in the top
navigation bar, then click PET Setting.
3. Perform any of the following steps:
a. Enable or disable Send Alerts. Enabling this function allows the BMC to send alerts when
events occur.
b. In the Community String field, type the value that will be displayed in the PET trap
community string field.
c. Type up to four IP addresses in the Alert Destination IP Address fields.
NOTE: To allow the MergePoint SP manager to receive alerts from the target device, one field should contain the
IP address of the MergePoint SP manager.
4. Click Apply.
To set a user and password for all target devices in a group:
1. Click Targets - Group.
2. In the Group list, select the group(s) you wish to modify and click Set User and Password.
- or -
Click a group name from the explorer tree in the side navigation bar, click Action in the top
navigation bar, then click Set User and Password.
3. Enter the requested information and click Apply.
To manage target device groups:
1. Click a group name from the explorer tree in the side navigation bar.
2. Select the desired target device(s) you wish to copy/move to the group, or remove from the
group.
3. Click the corresponding button and follow the on-screen instructions.

Monitoring and Management

Viewing sensor status

The MergePoint SP manager can detect the status of fan, temperature and voltage sensors on
managed target devices. By clicking the Sensor tab, you may view a detailed report of a device's
sensors that includes the sensor name, type, current reading and status.
NOTE: For some types of target devices, you can change a temperature scale to view sensor information.
